                                                                                       3. Disassembly and Reassembly

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED/LCD TV.
    WARNING: This LED/LCD TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
   Cautions: 1. Disconnect the LED/LCD TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

 LE32D400

                  Description                                   Picture Description                         Screws

  1     Place the TV face down on cushioned table.




        Remove 4 screws from the Stand.




                                                                                                           6003-001785



        Remove Stand.




  2     Remove the screws of Rear-Cover.
