Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                              2. Product specifications

2. Product specifications
2-1. Specifications
2-1-1. Model Comparison
                    Model                                      UD5500




     Front View                All




     Detail View               All




     Front Color               All                          ToC RED BLK
                              With Stand      30.2               9.4                    20.9
                        32"
    Dimensions                Without Stand   30.2               1.2                    18.4
  W x D x H (inches)          With Stand      37.6               10.0                   25.1
                        40"
                              Without Stand   37.6               1.2                    22.6
                              With Stand                     9.96 / 21.91
                        32"
       Weight                 Without Stand                  7.22 / 15.88
      (kg / lbs)              With Stand                     14.36 / 31.59
                        40"
                              Without Stand                  11.08 / 24.38
     Panel Type                All                            Anti Glare
  Internal Memory              All                              None
        DDR                    All                            384 Mbtye
       Feature                 All                   Media Play(MOVIE), HDD, DLNA




                                                                                                   2-1
2. Product specifications

2-1-2. Feature & Specifications
               Model                                                 UN32D5500RF

                                                       Feature

 Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 2-USB2.0, D-SUB
 Brightness : 450 cd/m2 (Marketing spec : 500 cd/m2)
 High Contrast Ratio : 5,000:1 (Marketing spec : 3,000,000:1)
 Response Time : 8 ms (Marketing spec : 8 ms)

                                                  Specifications

               Item                                                  Description
LCD Panel                      32 inch FHD 60 Hz
Scanning Frequency             Horizontal : 60 kHz ~ 73 kHz (Automatic)
                               Vertical : 47 Hz ~ 63 Hz (Automatic)
Display Colors                 16.7 M color
Maximum resolution             Horizontal : 1920 Pixels
                               Vertical : 1080 Pixels
Input Signal                   Analog 0.7 Vp-p
