Image preview - the first page of the document
>> Download Samsung+NP-N310+-+PEBBLE+PV+-+REV+0.3_2 documenatation <<
Text preview - extract from the document
4 3 2 1
8-1
SAMSUNG PROPRIETARY
SAMSUNG PROPRIETARY
SAMSUNG PROPRIETARY
THIS DOCUMENT CONTAINS CONFIDENTIAL
PROPRIETARY INFORMATION THAT IS
SAMSUNG ELECTRONICS CO'S PROPERTY.
DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
EXCEPT AS AUTHORIZED BY SAMSUNG.
D Table of Contents D
PEBBLE
Page. 1 COVER
Page. 2~7 INFORMATION
Page. 8 CLOCK GENERATOR (CK-505M)
g
Page. 9 THERMAL SENSOR
Page. 10~11 DIAMONDVILLE (N270)
un al
Page. 12~15 CALISTOGA (INTEL945GSE)
Page. 16~19 ICH7-M
CPU : INTEL DIAMONDVILLE Page. 20 BIOS CODE
Page. 21 DDR2 SODIMM
Chip Set : INTEL 945GSE Page. 22 GRAPHIC I/F
ms nti
Page. 23~26 AUDIO
C
C
C Remarks : Page. 27 LAN C
C
C
Page. 28 SATA HDD
Page. 29 MINI-CARD (Wireless/HSDPA
Page. 30~31 USB
Model Name : PEBBLE Page. 32 MMC
Sa de
Page. 33~34 MICOM & GLUE LOGIC
- This Document can not be used without Samsung's authorization -
PCB Part No : BA41-01066A (GCE)
- -
Page. 35 LED-Switch
BA41-01067A (NY) Page. 36~42 POWER
8. Block Diagram and Schematic
nfi
Page. 43 SUB-BOARD (SIM CARD)
BA41-XXXXXX (HS) Page. 44 MOUNT HOLE
Page. 45 Test Points
Dev. Step : PV
Revision : 0.3
Co
B B
T.R. Date : 2009.02.12
DRAW CHECK APPROVAL
A A A
SAMSUNG
ELECTRONICS
N310
4 3 2 1
4 3 2 1
N310
SAMSUNG PROPRIETARY
THIS DOCUMENT CONTAINS CONFIDENTIAL
PROPRIETARY INFORMATION THAT IS
OPERATION BLOCK DIAGRAM
SAMSUNG ELECTRONICS CO'S PROPERTY.
DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
EXCEPT AS AUTHORIZED BY SAMSUNG.
D D
437 uFCBGA Type
THERMAL
CPU MONITOR
CLOCK DIAMONDVILLE
CPU2_THERMDA/DC EMC2102
GENERATOR TFT_LCD Page8(block)
Page11~12
CK-505 8.9"/10.2" WIDE
g
g
g
Page26
Page8(block)
533MHz FSB
LVDS 998 uFCBGA Type
option
un al
un al
un al
VGA P3 Bluetooth
GMCH 533 MHz
200P
DDR2-SODIMM
Module
CRT MAX 1 GB
Page8(block) 945GSE Page9(block)
P0 USB (1):debug port
ms nti
ms nti
ms nti
Page 13~16
P4
C USB (2) C
P5
652 FCBGA Type
USB (3)
HDD SATA P7
Sa de
Sa de
Sa de
1.3M Camera
2.5inch
- This Document can not be used without Samsung's authorization -
- -
ICH USB2.0 P1
ICH7-M CardBus
8. Block Diagram and Schematic
nfi
nfi
nfi
3in1 B'd
AU6371
82801 GBM
Page 17~20 P2
MINI CARD1
HDAUDIO PCI_ EXP PCI_ EXP1
High Definition Audio Wireless LAN
Co
Co
Co
Page9(block)
B Aud. Audio SPI B
AMP
ALC272 RTC P6
Batt. PCI_ EXP2
MINI CARD2
Page 22~25 option HSDPA/Wibro
SIMM Card
SPI ROM
Page9(block)
2P
Page 21
HP Page
PCI_ EXP3
RJ45
MIC-IN 2P 2P Power S/W LAN CONTROLLER LAN
LPC 88E8040 Transformer
MICOM SYNAPTICS
SPKR R
H8S-2110B P/S2 TOUCHPAD
A SPKR L A
Space bar
SAMSUNG
ELECTRONICS
KEYBOARD
8-2
4 3 2 1
8-3
4 3 2 1
SAMSUNG PROPRIETARY
BOARD INFORMATION
THIS DOCUMENT CONTAINS CONFIDENTIAL
PROPRIETARY INFORMATION THAT IS
SAMSUNG ELECTRONICS CO'S PROPERTY.
DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
EXCEPT AS AUTHORIZED BY SAMSUNG.
D
SCHEMATIC ANNOTATIONS AND BOARD INFORMATION D
PCI Devices
Voltage Rails
Devices IDSEL# REQ/GNT# Interrupts
Power Rail Descriptions
PRTC_BAT 3.3V (can drop to 2.0V min. in G3 state) supply for the RTC well.
g
g
g
USB AD29(internal) VDC Primary DC system power supply (9 to 19V)
Hub to PCI AD30(internal) P1.05V(VCCP) VTT for CPU, Calistoga & ICH7-M
LPC Bridge/IDE/AC97/SMBUS AD31(internal) Programable P3.3V_MICOM 3.3V always power rail(for Micom)
Internal MAC AD24(internal) P1.5V 1.5V switched power rail (off in S3-S5)
P1.8V_AUX 1.8V power rail for DDR (off in S4-S5)
un al
un al
un al
P0.9V 0.9V power rail for DDR (off in S4-S5)
P5V_AUX 5.0V power rail (off in S4-S5)
P3.3V_AUX 3.3V power rail (off in S4-S5)
P5V 5.0V switched power rail (off in S3-S5)
P3.3V 3.3V switched power rail (off in S3-S5)
CPU_CORE Core voltage for Atom CPU
I2C / SMB Address
ms nti
ms nti
ms nti
Devices Address Hex Bus
ICH7M Master SMBUS Master
C CK-505M (Clock Generator) 1101 001X D2h Clock, Unused Clock Output Disable
C
SODIMM0 1010 000X A0h -
CPU Thermal Sensor 0111 101X 7Ah Thermal Sensor
Sa de
Sa de
Sa de
- This Document can not be used without Samsung's authorization -
- -
USB PORT Assign
8. Block Diagram and Schematic
nfi
nfi
nfi
Port Number ASSIGNED TO Port Number ASSIGNED TO
0 USB PORT 4 USB PORT
UHCI_0 UHCI_2
1 3-IN-1 5 USB PORT
2 Wireless LAN 6 HSDPA
UHCI_1 3 BLUETOOTH UHCI_3 7 CAMERA
Co
Co
Co
B B
PCI Express Assign
Port Number ASSIGNED TO
1 Mini Card 1(Wireless LAN)
2 Mini Card 2 (HSDPA/Wibro)
3 LOM
A A
SAMSUNG
ELECTRONICS
N310
4 3 2 1
N310
4 3 2 1
SAMSUNG PROPRIETARY
THIS DOCUMENT CONTAINS CONFIDENTIAL
POWER DIAGRAM
PROPRIETARY INFORMATION THAT IS
SAMSUNG ELECTRONICS CO'S PROPERTY.
DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
EXCEPT AS AUTHORIZED BY SAMSUNG. Rev 0.1
D
KBC3_SUSPWR KBC3_PWRON D
(CHP3_S4_STATE*) (CHP3_SLPS3*) VCCP3_PWRGD
AC Adapter DIAMONDVILLE
P1.05V CALISTOGA CPU_CORE DIAMONDVILLE
ICH7-M
g
g
g
Battery DC VDC
un al
un al
un al
P1.8V_AUX SODIMM (DDR III)
CALISTOGA
DDR II-Termination
P0.9V
ms nti
ms nti
ms nti
C C
ICH7-M HDD
USB M_PCI
P3.3V_MICOM P5.0V CRT FAN CIRCUIT
P5V_AUX MICOM AUX DISPLAY
MICOM
Sa de
Sa de
Sa de
- This Document can not be used without Samsung's authorization -
- -
8. Block Diagram and Schematic
CRESTLINE
nfi
nfi
nfi
P1.5V ICH8-M
P3.3V_AUX
ICH7-M LAN
MDC BT Thermal Sensor MICOM
Co
Co
Co
ICH7-M SODIMM
B P5.0V_ALW P3.3V SPI PCMCIA B
LCD LEDs
M_PCI
ICH7-M
P1.2V_LAN P2.5V
P12.0V_ALW
LAN
Power On/Off Table by S-state P1.8V_LAN
Rail P2.5V_LAN
State S0 S3 S4 S5 LAN
+V*A(LWS)
ON ON ON ON
+V*LAN ON ON S5-S4 S3 S0
+1.8V_AUX ON ON
+0.9V
A +V*AUX
A
ON ON
+V ON
