Image preview - the first page of the document
>> Download 08_Exploded View & Part List documenatation <<
Text preview - extract from the document
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-1 System Overall Exploded View
78 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-2 System Parlist
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
1 BA97-02521A ASSY MECHA-LCD;HABANA-C,HOME,-,-,ASSY ME 1 SNA
2 BA75-01768A UNIT-HOUSING_BOTTOM;HABANA-C,DOMESTIC,PC 1 SA
3 BA92-04149A ASSY MOTHER BD-TOP;HABANA-C,1.73Ghz,DDR2 1 SA
4 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 1 SA
5 0902-001864 IC-MICROPROCESSOR;SL86J,1.5GHz,64Bit,uFC 1 SA
BA62-00393A HEAT SINK-CPU;HABANA-C,CU,T15,W90,L150mm 1 SA
6
BA62-00395A HEAT SINK-CPU;HABANA-C,CU,T15,W90,L150mm 1 SA
BA31-00025A FAN;MCF-908AM05,Sedona,Plastic,-,Leadfre 1 SA
7
BA31-00026A FAN;HY60A-05A-007,Sedona,Plastic,-,Leadf 1 SA
8 6001-001651 SCREW-MACHINE;BH,+,-,M2,L6,NI PLT,SWRCH1 2 SA
BA62-00394A HEAT SINK-GMCH;HABANA-C,CU,T5,W29,L37mm, 1 SA
9
BA62-00397A HEAT SINK-GMCH;HABANA-C,CU,T5,W29,L37mm, 1 SA
11 BA81-00524A GASKET-SIDE_TVOUT;OSCAR,PU SPONGE,W10*L1 1 SNA
12 BA92-04213A ASSY ETC-SIO_BOARD;HABANA-C,USB_SIO,2POR 1 SA
13 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 1 SA
14 BA92-04214A ASSY ETC-1394IR_BOARD;HABANA-C,DUMMY,NO 1 SNA
15 6001-001626 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(YEL),SWRC 1 SA
BA39-00533A WIRE HARNESS-USB;HABANA,Wire,UL1571,10PI 1 SA
17
BA39-00540A WIRE HARNESS-USB;HABANA,wire,DA-1571,10P 1 SA
19 BA73-00396A RUBBER-COVER_1394;HABANA-C,Silicon,L22*W 1 SA
20 BA75-01770A UNIT-HOUSING_TOP;HABANA-C,DOMESTIC,PC/GF 1 SA
21 6001-001625 SCREW-MACHINE;BH,+,-,M2.6,L8,ZPC(BLK),SW 17 SA
22 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 1 SA
BA96-03010A ASSY DVD-COMBO;HAINAN,TSST TS-L462C,COMB 1 SA
23
BA96-03011A ASSY DVD-COMBO;HAINAN,DW-224E-C,TEAC,DVD 1 SA
24 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 1 SA
25 6001-001625 SCREW-MACHINE;BH,+,-,M2.6,L8,ZPC(BLK),SW 2 SA
27 BA75-01726A UNIT-BRKT_SUPPORT-KBD;HABANA,SEC,AL,W107 1 SA
28 BA59-01849A KEYBOARD;Habana-C,88Key,M/B,-,US,-,Black 1 SA
1105-001609 IC-DRAM MODULE;M470T3354BG0,32Mx64Bit,SO 1 SA
29
1105-001614 IC-DRAM MODULE;HYS64T32000HDL,-,256MByte 1 SA
SAMSUNG R45 79
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
30 BA75-01725A UNIT-DOOR_MEMORY;HABANA,SEC,AL,W84*L124. 1 SA
BA59-01471A HDD;80G,HTS541080G9AT00,S63,H16,C16383,9 1 SA
BA59-01865A HDD;80GB,MHV2080AH-PL,S63,H16,C16383,H9. 1 SA
33
BA59-01651A HDD;80GB,MHV2080AH,S63,H16,C16383,H9.5,W 1 SA
BA59-01745A HDD;80G,MP0804H,S63,H16,C77622,9.5mm,2.5 1 SA
BA41-00568A FPC-HDD;Habana,Y00,gold,50P,T0.15mm,- 1 SA
34
BA41-00569A FPC-HDD;Habana,Y00,gold,50P,T0.15mm,PATA 1 SA
35 BA61-01043A BRACKET-HDD;SEDONA,STS304,T0.15mm,-,-,NT 1 SA
36 6001-001480 SCREW-MACHINE;CH,+,M3,L4.0,ZPC(BLK),SWRC 2 SA
37 BA75-01724A UNIT-DOOR_HDD;HABANA,SEC,PC/GF,W75.73*L1 1 SA
38 BA75-01773A UNIT-CAP_TOP;HABANA-C,DOMESTIC,PC/ABS,W4 1 SA
39 BA61-01045A DUMMY CARD-EXPRESS;SEDONA,PC,T5.0,W54,L7 1 SA
40 BA61-01050A DUMMY CARD-PCMCIA;HABANA,PC/ABS,T1.5,W54 1 SA
41 BA68-00793D LABEL-LOGO_WINXP;OSCAR,-,PETRON,T0.075,W 1 SA
42 BA68-02502A LABEL-INTEL_CELERON-M;CETUS,ALL,-,-,W19. 1 SA
44 BA43-00155A BATTERY;3UR18650Y-2-SDN-14,HABANA-C,Li-i 1 SA
80 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-3 LCD Exploded View
SAMSUNG R45 81
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-4 LCD Partlist
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
1-1 BA75-01771A UNIT-HOUSING_BACK;HABANA-C,DOMESTIC,PC/G 1 SA
1-4 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 2 SA
1-5 BA59-01811A LCD PANEL-15XGA;LTN150XG-L05-V,15XGA,N/G 1 SA
1-6 BA75-01757A UNIT-BRKT_LCD_L;HABANA,YIHSIN,SUS304,W15 1 SA
1-7 BA75-01758A UNIT-BRKT_LCD_R;HABANA,YIHSIN,SUS304,W15 1 SA
1-8 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 14 SA
BA39-00527A CABLE FORM CONN.COAX;Habana,Twin coaxial 1 SA
1-9
BA39-00528A CABLE FORM CONN.COAX;Habana,Twin coaxial 1 SA
1-10 BA81-02325A HINGE-L;HABANA,ZINC/STS304,W12.7*L36.0mm 1 SA
1-11 BA81-02326A HINGE-R;HABANA,ZINC/STS304,W12.7*L36.03m 1 SA
BA44-00209A INVERTER;Habana,V209-001GP,210Hz,8.5to20 1 SA
1-12
BA44-00211A INVERTER;SEDONA,DAC-09N014,-,8.5to20V,1. 1 SA
1-13 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 2 SA
1-14 6001-001651 SCREW-MACHINE;BH,+,-,M2,L6,NI PLT,SWRCH1 4 SA
1-15 BA75-01772A UNIT-HOUSING_FRT;HABANA-C,DOMESTIC,PC/AB 1 SA
1-16 6001-001651 SCREW-MACHINE;BH,+,-,M2,L6,NI PLT,SWRCH1 5 SA
1-17 BA73-00381B RUBBER-LCD_CAP;FIRENZE,THERMO POLYURETHA 5 SA
1-18 BA64-00700C LOGO-SAMSUNG;CICHLID2,NI,T0.95(W/Tape),W 1 SA
1-19 BA68-03241A LABEL-R45;HABANA-C,SEC,PC,T0.3,W5.76,L24 1 SA
1-20 BA64-00700E LOGO-SAMSUNG;CICHLID2,NI,T0.95(W/Tape),W 1 SA
82 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-5 TOP Ass'y Exploded View(1)
SAMSUNG R45 83
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
TOP Ass'y Exploded View(2)
84 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-6 TOP Ass'y Partlist
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
1 BA81-02742A HOUSING-TOP;HABANA-C,DOMESTIC,PC/GF,W269 1 SNA
2 BA81-01782A TAPE-TOP_PLATE;FIRENZE,POLYESTER,W188.0* 2 SNA
3 BA81-02313A BRACKET-TOP_PLATE;HABANA,SUS304,W37.85*L 1 SNA
4 BA81-02308A LENS-INDICATOR_POWER;HABANA,PC,W13.7*L37 1 SNA
5 BA81-00773A KEYBOARD-LOCK;NEON,POM,W17.0*L18.6*H2.8, 3 SNA
6 BA81-02310A KNOB-TOUCHPAD;HABANA,PC/ABS,W29.8*L74.0* 1 SNA
7 BA81-02358A COVER-DC;HABANA,PC/ABS,L14*W15*T1.0mm,NT 1 SNA
8 BA81-02312A BRACKET-SHIELD_ONTOP;HABANA,SUS304,W10.8 1 SNA
9 BA81-02330A BRACKET-STIFFENER_R;HABANA,Mg,W31.6*L228 1 SNA
10 BA81-02329A BRACKET-STIFFENER_L;HABANA,Mg,W31.68*L25 1 SNA
11 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 11 SA
12 BA96-02990A ASSY SPEAKER;HABANA,X03931RS01-52-P,190/ 1 SA
13 BA73-00354A RUBBER-WOOFER;ARGO,SR,L7.5*W7.5*T1.0,-,H 4 SA
14 BA81-00729A SUPPORTER-SPEAKER;CYGNUS,M2,L8.5mm,SPEAK 2 SA
15 BA81-01780A INSULATOR-TOUCHPAD_TOP;FIRENZE,PC SHEET, 1 SNA
16 BA81-02381A RUBBER-TOP;SEDONA,THERMO POLYURETHANE,W6 2 SNA
20 BA81-02247A CAP-FINGER_DUMMY;SEDONA,Ni,T0.15mm,NTR,- 1 SA
21 BA81-02410A INSULATOR-PROTECT_TOP;HABANA,PET,W312*L8 1 SNA
25 BA59-01791A BOARD-ONTOP;HABANA,-,SEC,ONTOP,10pin,W12 1 SA
BA39-00529A WIRE HARNESS-ONTOP;HABANA,Wire,UL1571,10 1 SA
26
BA39-00544A WIRE HARNESS-ONTOP;HABANA,wire,DA-1571,1 1 SA
27 BA81-01106A TAPE-TOUCHPAD;CYGNUS,POLYESTER,W76*L39*T 1 SNA
28 BA59-01340A BOARD-TOUCHPAD;CICHLID,TM51P-378,BONGWOO 1 SA
29 BA59-01840A BOARD-TOUCHPAD;HABANA-C,-,SESC,TOUCHPAD, 1 SA
30 BA41-00467A FFC-TOUCHPAD;CYGNUS,1.0,Film,12Pin,T0.01 1 SA
31 BA39-00573A WIRE HARNESS-TOUCHPAD;HABANA-C,Wire,UL15 1 SA
32 BA75-01744A UNIT-BRKT_TOUCHPAD;HABANA,SEC,STS304,W70 1 SA
SAMSUNG R45 85
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-7 BOTTOM Ass'y Exploded View
86 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-8 BOTTOM Ass'y Partlist
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
1 BA81-02295A HOUSING-BOTTOM;HABANA,PC/GF,W296.97*L325 1 SNA
2 BA81-02227A KNOB-BATTERY_L;SEDONA,PC+ABS,T1.0mm,BLAC 1 SA
3 BA81-02228A KNOB-BATTERY_R;SEDONA,PC+ABS,T1.0mm,BLAC 1 SA
4 BA81-02298A LINK-BATTERY_L;HABANA,POM,W8.5*L26.4*H3. 1 SA
5 BA81-02299A LINK-BATTERY_R;HABANA,POM,W8.5*H4.0*L26. 1 SA
6 BA81-02813A LENS-IRDA;HABANA-C,PC+ABS,W5.54*L13.54*H 1 SA
8 BA81-02300A COVER-DUMMY_5IN1;HABANA,PC,W5.92*L41.39* 1 SNA
10 BA67-00291A CAP-DOCKING;HABANA-C,PC+ABS,T1.5,W61,L10 1 SA
11 BA81-02301A SHIELD-DOCKING_L;HABANA,STS304,W5.5*L39. 1 SNA
12 BA81-02302A SHIELD-DOCKING_R;HABANA,STS304,W5.5*L36. 1 SNA
13 BA81-02303A SHIELD-DOCKING_C;HABANA,STS304,W5.5*L28. 1 SNA
14 BA81-02306A COVER-DUMMY_SIO;HABANA,PC/ABS,W11.87*L32 1 SA
16 BA61-00780A SPRING ETC-BATT;AQUILA-P,STS304,CD0.3,ID 2 SA
17 BA81-01774A RUBBER-FOOT;FIRENZE,VIBRATHANE,W17.0*L6. 3 SA
18 BA81-02243A RUBBER-FOOT_REAR;SEDONA,SR,W6*L11*H2.4mm 3 SA
19 BA81-02045A RUBBER-HDD;FIRENZE,PORON,W8.0*L8.0*T2.3m 4 SA
20 BA73-00262A RUBBER-HDD_SUPPORT;AQUILA,PORON,W6*L10*T 8 SA
21 BA81-01958A GASKET-HDD;FIRENZE,Cu+Ni, PU SPONGE,W5.0 1 SNA
22 BA81-01957A GASKET-COMBO;FIRENZE,Cu+Ni, PU SPONGE,W7 1 SNA
23 BA63-00029A GASKET-CPU;BLADE,71TS,T1.5,W4.0,L9.0mm,N 2 SA
24 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 9 SA
25 BA81-02506A INSULATOR-BOTTOM;HABANA,PC,W59*L36*T0.15 2 SNA
SAMSUNG R45 87
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-9 ODD Ass'y Exploded View
88 SAMSUNG R45
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
6-10 ODD Ass'y Partlist
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
BA59-01687A DVD-COMBO;DW-224E-C,24X,110ms,EIDE,2M,6W 1 SA
1
BA59-01565A DVD-COMBO;TS-L462C,8X,190ms,EIDE,2M,8W,5 1 SA
2 BA81-02262A BRACKET-ODD;SEDONA,STS304 1/2H,W20*L8.7* 1 SA
3 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 2 SA
4 BA81-02253A UNIT-BEZEL_DVDCOMBO;SEDONA,PC+ABS,W15.2* 1 SA
4-1 BA81-01761A LENS-ODD;FIRENZE,PC,W2.1*L7.3*T0.6mm,CLE 1 SNA
4-2 BA81-02231A BEZEL-DVDCOMBO;SEDONA,PC+ABS,W15.2*L128. 1 SNA
4-3 BA81-02232A KNOB-DVDCOMBO;SEDONA,PC+ABS,-,BLACK,-,-, 1 SNA
5 BA81-02272A INSULATOR-ODD;FIRENZE,PC,W6*L20*T0.3mm,B 1 SNA
SAMSUNG R45 89
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
0401-000132 DIODE-SWITCHING;BAV99,70V,50MA,SOT-23,TP 1 SA
0401-000191 DIODE-SWITCHING;MMBD4148,75V,200MA,SOT-2 1 SA
0402-001405 DIODE-RECTIFIER;B340A,40,3A,SMA,TP 1 SA
0406-001141 DIODE-TVS;PGB1010603NR,-/-/1000V,0W,EIA- 1 SA
0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 1 SA
0505-001049 FET-GAAS;BSS84,-50V,20V,-130mA,360mW,SOT 1 SA
0505-001341 FET-SILICON;SI2307DS,P,-30V,-3A,0.08/0.1 1 SA
0505-001386 FET-SILICON;FDS6680A,N,30V,12.5A,0.0095o 1 SA
0505-001516 FET-SILICON;SI2315DS,P,-12V,+-3.5A,0.118 1 SA
0601-000189 LED;SMD,P-GRN,3.2X1.6X1.1MM,557NM,3.2X1. 1 SA
0801-002252 IC-CMOS LOGIC;7S14,INVERTER,SOT-25,5P,63 1 SA
0801-002981 IC-CMOS LOGIC;7SZ08,2-INPUT AND GATE,SC7 1 SA
0801-002998 IC-CMOS LOGIC;74AHCT1G125,Single buffer, 1 SA
0904-002043 IC-I/O CONTROLLER;SB450,32Bit,BGA,564P,3 1 SA
0904-002063 IC-BUS CONTROLLER;R5C843,32Bit,CSP,208P, 1 SA
1103-001244 IC-EEPROM;93LC46B,1Kbit,64x16Bit,SOP,8P, 1 SA
1201-001559 IC-AUDIO AMP;4863,TSSOP,20P,173MIL,DUAL, 1 SA
1203-002746 IC-SWITCH REG.;LTC3735EG,SSOP,36P,12.8X5 1 SA
1203-003476 IC-PWM CONTROLLER;ISL6227,SSOP,28P,9.9x3 1 SA
1203-003477 IC-PWM CONTROLLER;MAX8550,TQFN,28P,5x5mm 1 SA
1203-003905 IC-SWITCH VOL. REG.;SC338IMSTR,MSOP,10P, 1 SA
1205-002596 IC-SWITCH;TPS2062,SOIC,8P,5x6x1.65mm,PLA 1 SA
1205-002789 IC-ETHERNET CONTROLLER;BCM4401EKFBG,FBGA 1 SA
1205-002806 IC-SWITCH;R5534V-E2-FB,SSOP,20P,6.7x4.4m 1 SA
1205-002807 IC-SWITCH;R5538D001-TR-F,QFN,20P,4x4mm,P 1 SA
1205-002813 IC-CODEC;AD1986AJSTZ_R0.2,LQFP,48P,7x7mm 1 SA
1205-002863 IC-CLOCK GENERATOR;ICS951411BG,TSSOP,56P 1 SA
1209-001531 IC-TEMP. TRANSDUCER;EMC6N300,SSOP,24P,8. 1 SA
2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 SA
2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
2007-000129 R-CHIP;27Kohm,5%,1/10W,TP,1608 1 SA
2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
SAMSUNG R45 89
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
2007-000972 R-CHIP;5.1ohm,5%,1/4W,TP,3216 1 SA
2007-002910 R-CHIP;30.1Kohm,1%,1/10W,TP,1608 1 SA
2007-007468 R-CHIP;121KOHM,1%,1/16W,TP,1005 1 SA
2203-001201 C-CER,CHIP;0.0070nF,0.5pF,50V,NP0,1005 1 SA
2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
2203-006090 C-CER,CHIP;10000nF,10%,6.3V,X5R,2012 1 SA
2203-006093 C-CER,CHIP;1000nF,+80-20%,6.3V,Y5V,1005 1 SA
2402-001122 C-POLYMER AL CHIP;100uF,0.2,6.3V,-,TP,7. 1 SA
2801-000111 CRYSTAL-SMD;0.032768MHZ,20PPM,28-AAW,12. 1 SA
3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,150mA,,,,4 1 SA
3301-001148 BEAD-SMD;60ohm,1608,TP,-,- 1 SA
3301-001594 BEAD-SMD;90ohm,2.0*1.2*1.3mm,-,TP,-,-,- 1 SA
3701-001305 CONNECTOR-DSUB;15P,2R,FEMALE,ANGLE,AU 1 SA
3704-001153 SOCKET-IC;479P,PGA,AU,- 1 SA
3708-002166 CONNECTOR-FPC/FFC/PIC;25P,0.5mm,SMD-A,AU 1 SA
3708-002167 CONNECTOR-FPC/FFC/PIC;50P,0.5mm,SMD-A,AU 1 SA
3709-001124 CONNECTOR-CARD EDGE;124P,0.8mm,SMD-A,AUF 1 SA
3709-001325 CONNECTOR-CARD EDGE;200P,0.6mm,SMD-A,AU, 1 SA
3709-001327 CONNECTOR-CARD EDGE;200P,0.6mm,SMD-A,AUF 1 SA
3709-001399 CONNECTOR-CARD SLOT;94P,1.27mm,SMD-A,AU, 1 SA
3710-002130 SOCKET-BOARD TO CABLE;30P,1R,0.5mm,SMD-S 1 SA
3710-002133 SOCKET-BOARD TO BOARD;12P,2R,0.8mm,SMD-A 1 SA
3710-002160 SOCKET-BOARD TO CABLE;8P,1R,1mm,SMD-S,SN 1 SA
3710-002289 SOCKET-BOARD TO BOARD;50P,2R,0.8mm,ANGLE 1 SA
3711-000386 HEADER-BOARD TO CABLE;BOX,10P,1R,1.25MM, 1 SA
3711-005752 HEADER-BOARD TO CABLE;BOX,2P,1R,1.25mm,S 1 SA
3711-005993 HEADER-BOARD TO CABLE;BOX,94P,2R,0.635,1 1 SA
3711-005997 CONNECTOR-BATTERY;NOWALL,7P,1R,2.5mm,BAT 1 SA
3722-001641 JACK-USB;4P/2C,AUF,BLK,ANGLE-OFFSET,A TY 1 SA
3722-002191 JACK-DC POWER;3P,5.6pi,Sn-P,Black 1 SA
3722-002226 JACK-VHS;7P,NICKEL,BLK,ANGLE-OFFSET 1 SA
3722-002291 JACK-MODULAR;8P+2P,STANDARD,BRASS,DIP,-, 1 SA
3722-002365 JACK-PHONE;6P,AUF,PINK 1 SA
3722-002416 JACK-PHONE;6P,AUF,LIME,ANGLE 1 SA
6001-001420 SCREW-INCH MACH;CH,+,UNC4-40,L4,NI PLT,S 2 SA
SAMSUNG R45 89
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
BA39-00531A WIRE HARNESS-MDC;HABANA,wire,DA-1571,2PI 1 SA
BA39-00534A WIRE HARNESS;TC05D37,AWG28,UL 1061,2PIN, 1 SA
BA39-00537A WIRE HARNESS-MDC;HABANA,Wire,UL1571,2PIN 1 SA
BA44-00162A ADAPTOR;AD-6019(API1AD02),CORONA,-,90TO2 1 SA
BA44-00205A ADAPTOR;0335C1960,AD-6019,AC/DC,90to264V 1 SA
BA46-04725A S/W CD;CDS/NERO EXP.,-,WIN2K/XP/MCE,1.0, 1 SA
BA59-01577A MODEM;T60M893.07,56kbps,2EA,-,W27.45*L35 1 SA
BA59-01578A MODEM;1456VQL-T1(INT-LF),56kbps,2EA,-,W2 1 SA
BA61-00631A SPRING ETC-KNOB_LCD;AQUILLA,STS304,T0.25 1 SA
BA61-00963A SUPPORT-VIDEO_BOARD-LF;VENICE,CU ALLOY,T 1 SA
BA61-01051A BRACKET-SUPPORT_CPUPGA;Habana/Sedona,Zn( 2 SA
BA62-00364A INSULATION-PCMCIA;FIRENZE,PC,W70.0*L49.4 1 SA
BA62-00396A INSULATION-COMBO_JACK;HABANA,PC,T0.15,W2 1 SA
BA62-00402A INSULATION-FAN;SEDONA,PC,T0.1,W65,L17mm, 1 SA
BA62-00411A INSULATION-MEMORY;HABANA-C,PC,T0.2,W24,L 2 SA
BA62-00412A INSULATION-PCB;HABANA-C,PC,T0.1,W21.05,L 1 SA
BA63-00367A PROTECTOR-FILM_PALOMINO;PALOMINO,PET,T0. 1 SA
BA64-00712A KNOB-WLAN_DUMMY;HABANA-C,PC/ABS,T1.1,W3. 1 SA
BA68-20039A LABEL-PPID_E;BLADE,-,PET,-,W50.8,L12.7mm 1.2 SA
BA70-00388A BRACKET-VGA;FIRENZE,STS304,T0.15mm,-,-,N 1 SA
BA81-02045A RUBBER-HDD;FIRENZE,PORON,W8.0*L8.0*T2.3m 4 SA
BA81-02332A KNOB-LATCH;HABANA,ABS,W6.8*L143.58mm,PLA 1 SA
BA46-04725A S/W CD;CDS/NERO EXP.,-,WIN2K/XP/MCE,1.0, 1 SA
3711-002050 CONNECTOR-HEADER;BOX,10P,1R,1.25mm,SMD-A 1 SA
0403-001047 DIODE-ZENER;BZX84C12L,5%,225mW,SOT-23,TP 1 SA
0404-000114 DIODE-SCHOTTKY;MMBD301,30V,200MA,SOT-23, 1 SA
0505-001648 FET-SILICON;IRF7811AV,N,30V,10.8A,11mohm 1 SA
0505-001955 FET-SILICON;Si4835DY,P,-30V,-8A,0.02ohm, 1 SA
0601-001130 LED;SMD,RED/GRN,3.0X2.5MM,660/570NM,3.0X 1 SA
0801-002195 IC-CMOS LOGIC;7S08,AND GATE,SOT-25,5P,63 1 SA
2007-007233 R-CHIP;61.9ohm,1%,1/10W,TP,1608 1 SA
2007-007328 R-CHIP;4.12Kohm,0.1%,1/10W,TP,1608 1 SA
2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608 1 SA
2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,1005 1 SA
2203-005052 C-CER,CHIP;0.0033nF,0.25pF,50V,NP0,1005 1 SA
SAMSUNG R45 89
- This Document can not be used without Samsung's authorization -
6 MECHANICAL EXPLODED VIEW AND PARTLIST
NP-R45K003/CHN
No Part Code Part Name & Specification Q'ty SA/SNA Note
2203-005172 C-CER,CHIP;47nF,+80-20%,25V,Y5V,1005 1 SA
2203-006000 C-CER,CHIP;1NF,10%,3KV,X7R,TP,4520 1 SA
2203-006166 C-CER,CHIP;100nF,10%,25V,X5R,1005 1 SA
2203-006382 C-CER,CHIP;10000nF,10%,25V,X7R,3225 1 SA
2402-001120 C-POLYMER AL CHIP;330uF,0.2,6.3V,-,TP,7. 1 SA
BA61-00931A SUPPORT-DMB;NEON,Cu,T4.9,W3.5,L3.5,WHITE 1 SA
3903-000131 CBF-POWER CORD;DT,CN,EP2,IEC320 C7,250/2 1 SA
BA68-03279A LABEL-ZAIGEN;HABANA-C,ENG,PET,-,W90,L38m 1 SA
BA68-20323A LABEL CAUTION;NOTE PC,-,PET,T0.07,W30.0, 1 SA
0904-002105 IC-MEMORY CONT.;RC410MB,64Bit,FCBGA,707P 1 SA
BA46-03755A S/W CD;RCD,NP/DT,WINXPH SP2 OSCD,1.0,CHS 1 SA
BA46-04815A S/W CD;UTILITY,NR45,WINXP H/P,1.0,CHS/CH 1 SA
BA46-05039B S/W CD;UTILITY,HABANA-C,WINXP H/P,1.0,CH 1 SA
3301-001772 BEAD-SMD;27ohm,1608,-,TP,30ohm/120MHz,48 1 SA
SAMSUNG R45 89
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
