Image preview - the first page of the document



>> Download Disassembly documenatation <<

Text preview - extract from the document

-          -
- This Document can not be used without Samsung's authorization -



3. Disassembly and Reassembly


3-1. Disassembly and Reassembly R560
                                                                                  [Caution] Attention to red sentence.

   Part                      Picture                                             Description

                                                         1. Make sure to separate the AC adapter and battery before
                                                            disassembling the system.
                                                         2. Slide the knob all the way to the end in the direction of
                                                            the arrows (1) and push the battery in the direction of the
                               2                            arrows (2).



               1                           1




                                                         3. If you push the battery upwards, the battery is separated.




  Main
 System                                                  4. emove the screws from the bottom.
                                                           - Screw
                                                             Red ( ): M2.6 X L8, Black (16EA)
                                                             Yellow ( ): M2 X L4, Black (7EA)
                                                             Sky blue ( ): M2 X L6, Black (2EA)




                                                         5. Remove DOOR-HDD and DOOR-MEMORY.




                                                  3-1
-          -
- This Document can not be used without Samsung's authorization -



3. Disassembly and Reassembly

   Part                      Picture                                            Description

                                                         6. HDD is under the DOOR-HDD.
                                                            Seizing INSULATOR, lift up HDD by 70
