Image preview - the first page of the document
>> Download Electrical Part List documenatation <<
Text preview - extract from the document
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
ADAPTER BA44-00244A ADAPTOR PA-1900-08S,AD-9019S,-90to264Vac,47to63Hz,19VDC,4.74A,- 1 SA
ADAPTER BA44-00233A ADAPTOR SADP-90FH B,AD-9019S,-,100to240V,50to60Hz,19V,4.74A,- 1 SA
ADAPTER BA44-00210A ADAPTOR API5AD10,AD-9019S,-,90to264Vac,47to63Hz,19VDC,4.74A,- 1 SA
ADAPTER BA44-00215A ADAPTOR 0455A1990,AD-9019S,-,90to264Vac,47to63Hz,19VDC,4.74A,- 1 SA
BIOS BA46-07860A BIOS OSLO2,-,SYSTEM,ALL,00LA,-,- 1 SNA
XP HOME RYT BA46-02602B S/W APPLICATION-RTY WINXP_HOME RTY,SHK,-,-,1.0,-,TAURUS2 1 SNA
XP PRO RYT BA46-02603B S/W APPLICATION-RTY WINXP_PRO RTY,SHK,-,-,1.0,-,TAURUS2 1 SNA
H_PREMIUM RTY BA46-05873A S/W APPLICATION-RTY H_PREMIUM RTY,-,-,ALL(W/O RUS),1.0,-,H_PREMIUM 1 SNA
BUSINESS RTY BA46-05877A S/W APPLICATION-RTY BUSINESS RTY,-,-,ALL(W/O RUS),1.0,-,BUSINESS 1 SNA
RECOVERY_3 RTY BA46-08356A S/W APPLICATION-RTY Recovery_3 RTY,-,-,ALL,1.0,-,NP/DT 1 SNA
H_BASIC RTY BA46-05875A S/W APPLICATION-RTY H_BASIC RTY,-,-,ALL(W/O RUS),1.0,-,H_BASIC 1 SNA
BATTERY(SDI_6C) BA43-00149A BATTERY P32R07-02-H01,SEDONA,LI-ION,2P3S,5200mAh,Cylinder 1 SC
BATTERY_SANYO BA43-00150A BATTERY 3UR18650F-2-SDN-12,Sedona,Li-ion,2P3S,5200mAh,- 1 SC
BT CABLE BA39-00701A WIRE HARNESS-BLUETOOTH LYON,Wire,UL1571,4P,160+-5mm,GRY,AWG32,51021- 1 SA
BT CABLE BA39-00702A WIRE HARNESS-BLUETOOTH LYON,Wire,UL1571,4P,160+-5mm,GRY,AWG32,51021- 1 SA
S/120G(5400R_HGST) BA59-02202A HDD 120G,HTS542512K9A300,S63,H16,D16385,H9.5mm,2.5INCH, 1 SC
S/120GB(5400R_FJTS) BA59-02208A HDD 120G,MHY2120BH,S63,H16,D16385,9.5mm,2.5INCH,SATA,12 1 SA
S/120G(5400R_SEC) BA59-02189A HDD 120G,HM121HI,S63,H16,D16385,H9.5mm,2.5INCH,Sata,160G 1 SA
S/120GB(5400R_TOSH) BA59-02215A HDD 120G,MK1237GSX,S63,H16,D16385,9.5mm,2.5INCH,SATA,80 1 SA
120GB 5400 WD BA59-02226A HDD 120G,WD1200BEVS- 1 SC
S/160GB(5400R_HGST) BA59-02203A HDD 160G,HTS542516K9A300,S63,H16,D16385,H9.5mm,2.5INCH, 1 SC
S/160GB(5400R_FJTS) BA59-02209A HDD 160G,MHY2160BH,S63,H16,D16385,9.5mm,2.5INCH,SATA,12 1 SC
S/160GB(5400R_SEC) BA59-02187A HDD 160G,HM160HI,S63,H16,D16385,H9.5mm,2.5INCH,Sata,160G 1 SC
160GB 5400 WD BA59-02227A HDD 160G,WD1600BEVS- 1 SC
320G 5400 WD BA59-02280A HDD 320G,WDC-WD3200BEVT- 1 SA
200G 5400 HGSTAL BA59-02204A HDD 200G,HTS542520K9A300,S63,H16,D16385,H9.5mm,2.5INCH, 1 SC
200GB 5400 FJS BA59-02210A HDD 200G,MHY2200BH,S63,H16,D16385,9.5mm,2.5INCH,SATA,12 1 SC
250GB 5400 HIT BA59-02205A HDD 250G,HTS542525K9A300,S63,H16,D16385,H9.5mm,2.5INCH, 1 SC
250GB 5400 FJS BA59-02211A HDD 250G,MHY2250BH,S63,H16,D16385,9.5mm,2.5INCH,SATA,12 1 SA
250GB 5400 SEC BA59-02190A HDD 250G,HM250JI,S63,H16,D16385,H9.5mm,2.5INCH,Sata,160G/ 1 SA
S/250GB(5400R_WD) BA59-02228A HDD 250G,WD2500BEVS- 1 SA
160G (5400 WD) BA59-02279A HDD 160G,WDC-WD1600BEVT- 1 SA
160G (5400RPM TSB) BA59-02287A HDD 160G,MK1646GSX,S63,H16,D16385,H9.5mm,2.5INCH,SATA,1 1 SA
120G HDD TSB2 BA59-02286A HDD 120G,MK1246GSX,S63,H16,D16385,H9.5mm,2.5INCH,SATA,1 1 SA
200G HDD TSB BA59-02290A HDD 200G,MK2046GSX,S63,H16,D16385,H9.5mm,2.5INCH,SATA,1 1 SA
250G HDD TSB BA59-02288A HDD 250G,MK2546GSX,S63,H16,D16385,H9.5mm,2.5INCH,SATA,1 1 SA
SUB MATERIAL BA99-00100L ASSY SUB/MATERIAL-NP_D N/P COMMON,Delivery Sub/Matrl,Barcode Ribbon, Tape,- 1 SNA
QMS BARCODE BA68-01297A LABEL CAUTION MATRIX,-,-,-,W60,L35mm,SIL,-,-,LABEL BARCODE 1 SNA
PAPER 0203-000223 PAPER-CARBON BARCODE GEN,T0.25,W60,L300,NTR 3 SNA
TAPE-INSULATION BA02-00004A TAPE-POLY PE/AL METALLIC,T0.08,W25,L55000,-,ANTENNA 4 SNA
TAPE-INSULATION BA02-00004A TAPE-POLY PE/AL METALLIC,T0.08,W25,L55000,-,ANTENNA 4 SNA
AGN3R BA59-02273A MODULE-WLAN N/P,533AN_MMWG,-,802.11AGN,mini card,3TX 3RX,-,- 1 SA
AGN1R BA59-02297A MODULE-WLAN N/P,512ANXMMWG,-,802.11AGN,mini card,1TX 2RX,-,- 1 SA
BLUETOOTH BA59-01916A MODULE-BLUETOOTH Bluetooth Version 2.0,BTO2P0B2SA,Bluetooth 1 SA
BLUETOOTH BA59-01691A MODULE-BLUETOOTH Bluetooth V2.0,T60H928.01,Bluetooth Module,USB I/ 1 SA
COMBO TS-L463A BA96-03600A ASSY DVD-COMBO Oslo2,TS-L463A,24/24/8/24,DVD-COMBO 1 SA
COMBO TS-L463A BA59-02265A DVD-COMBO TS-L463A,8x,150ms,SATA,2MB,6.5W,5V 1 SA
DVD-COMBO BA97-02829A ASSY MECHA-DVD_COM OSLO2,TEAC,MECHA,- 1 SNA
ODD+BRKT 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
BEZEL-ODD BA75-01863A UNIT-BEZEL_ODD HAINAN2,DOMESTIC,PC/ABS,T1.8,TEXTURE,UNIT- 1 SA
BEZEL-ODD BA81-03451A BEZEL-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
KNOB-ODD BA81-03426A KNOB-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
6-1
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
LENS-ODD BA81-01761A LENS-ODD FIRENZE,PC,W2.1*L7.3*T0.6mm,CLEAR,GBAS Type,-,- 1 SNA
ODD BA81-03428A BRACKET-ODD OSLO,SUS304,W27*L10*T1.0mm,NTR,-,-,- 1 SA
S-MULTI TS-L633A BA96-03602A ASSY DVD-SUPERMULTI Oslo2,TS-L633A,5/8(DL6)/8/8(DL6)/8,24/24/8/24x,SUPER 1 SA
SUPERMULTI_DL BA97-02755A ASSY MECHA- PRAHA,LITEON,MECHA,- 1 SNA
DVD BA75-01863B UNIT-BEZEL_ODD-MULTI_DL HAINAN2,DOMESTIC,PC/ABS,T1.8,BLACK,TEXTURE,-,- 1 SA
BEZEL-ODD_MULT BA81-03451B BEZEL-ODD_MULTI HAINAN2,DOMESTIC,PC/ 1 SNA
KNOB-ODD BA81-03426A KNOB-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
LENS-ODD BA81-01761A LENS-ODD FIRENZE,PC,W2.1*L7.3*T0.6mm,CLEAR,GBAS Type,-,- 1 SNA
DVD BA81-03428A BRACKET-ODD OSLO,SUS304,W27*L10*T1.0mm,NTR,-,-,- 1 SA
DVD+BRKT 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
TS-L633A BA59-02234A DVD-SUPERMULTI TS-L633A,8x,130ms,SATA,2M,4W,5V 1 SA
S-MULTI DV-W28S-R BA96-03603A ASSY DVD-SUPERMULTI Oslo2,DV-W28S-R,5/8(DL6)/8/8(DL6)/6, 24/24/ 1 SA
S-MULTI DV-W28S BA59-02266A DVD-SUPERMULTI DV-W28S-R,8X,150ms,SATA,2MB,4.5W,5V 1 SA
SUPERMULTI_DL BA97-02755A ASSY MECHA- PRAHA,LITEON,MECHA,- 1 SNA
DVD BA75-01863B UNIT-BEZEL_ODD-MULTI_DL HAINAN2,DOMESTIC,PC/ABS,T1.8,BLACK,TEXTURE,-,- 1 SA
BEZEL-ODD_MULT BA81-03451B BEZEL-ODD_MULTI HAINAN2,DOMESTIC,PC/ 1 SNA
KNOB-ODD BA81-03426A KNOB-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
LENS-ODD BA81-01761A LENS-ODD FIRENZE,PC,W2.1*L7.3*T0.6mm,CLEAR,GBAS Type,-,- 1 SNA
DVD BA81-03428A BRACKET-ODD OSLO,SUS304,W27*L10*T1.0mm,NTR,-,-,- 1 SA
DVD+BRKT 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
S-MULTI SC TS-L633L BA96-03604A ASSY DVD- Oslo2,TS-L633L,5/8(DL6)/8/8(DL6)/8,24/24/8/ 1 SA
SUPERMULTI_LS BA97-02664A ASSY MECHA- OSLO,TEAC,MECHA,SUPER-MULTI_LS 1 SNA
ODD BA75-01863C UNIT-BEZEL_SUPERMULT-LS OSLO,SEC,PC+ABS,T1.8,W129*L6.8*H15.2mm,BLACK,-,-,- 1 SA
ODD BEZEL BA81-03451C BEZEL-SUPERMULTI_LS OSLO,PC+ABS,T1.8,W129*L6.8*H15.2mm,BLACK,-,-,- 1 SNA
ODD BEZEL BA81-03426A KNOB-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
ODD BEZEL BA81-01761A LENS-ODD FIRENZE,PC,W2.1*L7.3*T0.6mm,CLEAR,GBAS Type,-,- 1 SNA
DVD+BRKT 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
DVD BA81-03428A BRACKET-ODD OSLO,SUS304,W27*L10*T1.0mm,NTR,-,-,- 1 SA
SUPERMULTI_LS BA59-02264A DVD-SUPERMULTI TS-L633L,8x,130ms,SATA,2MB,6.5W,5V 1 SA
COMBO DW-224S-V BA96-03601A ASSY DVD-COMBO Oslo2,DW-224S-V,24/24/8/24,DVD-COMBO 1 SA
DW-224S-V BA59-02267A DVD-COMBO DW-224S-V,8X,110ms,SATA,2MB,4.5W,5V 1 SA
DVD-COMBO BA97-02829A ASSY MECHA-DVD_COM OSLO2,TEAC,MECHA,- 1 SNA
ODD+BRKT 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
BEZEL-ODD BA75-01863A UNIT-BEZEL_ODD HAINAN2,DOMESTIC,PC/ABS,T1.8,TEXTURE,UNIT- 1 SA
BEZEL-ODD BA81-03451A BEZEL-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
KNOB-ODD BA81-03426A KNOB-ODD HAINAN2,DOMESTIC,PC/ 1 SNA
LENS-ODD BA81-01761A LENS-ODD FIRENZE,PC,W2.1*L7.3*T0.6mm,CLEAR,GBAS Type,-,- 1 SNA
ODD BA81-03428A BRACKET-ODD OSLO,SUS304,W27*L10*T1.0mm,NTR,-,-,- 1 SA
POWER CORD_KOR 3903-000140 CBF-POWER CORD DT,KR,CP3,IEC320 C5,250/250V,7/3A,BLK,1830mm,-,H05VV-F 1 SC
KEYBOARD OKI BA59-02295B KEYBOARD LYON,88K,Membrane,-,KOR,-,BLACK,- 1 SA
KEYBOARD MON BA59-02295F KEYBOARD LYON,88K,Membrane,-,KOR,-,BLACK,- 1 SA
RHE+FAN BA96-03224B ASSY COOLER-CPU OSLO,CPU,KDB0705HA-7F66,30mm,DELTA Fan 1 SA
RHE BA81-03505B FAN OSLO,KDB0705HA-7F66,PET,2200rpm,5V,DELTA,-,- 1 SA
RHE_T7800_NB8P-GS BA96-03224B ASSY COOLER-CPU OSLO,CPU,KDB0705HA-7F66,30mm,DELTA Fan 1 SA
RHE BA81-03505B FAN OSLO,KDB0705HA-7F66,PET,2200rpm,5V,DELTA,-,- 1 SA
RHE+FAN BA96-03336A ASSY COOLER-CPU OSLO,CPU,KDB0705HA-7F66,L30mm,TOSHIBA Fan 1 SA
FAN BA81-03505B FAN OSLO,KDB0705HA-7F66,PET,2200rpm,5V,DELTA,-,- 1 SA
RHE_T7800_NB8P-GS BA96-03336A ASSY COOLER-CPU OSLO,CPU,KDB0705HA-7F66,L30mm,TOSHIBA Fan 1 SA
FAN BA81-03505B FAN OSLO,KDB0705HA-7F66,PET,2200rpm,5V,DELTA,-,- 1 SA
6-2
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
NB9PGS_W/ ITM BA92-04947A ASSY MOTHER BD-TOP OSLO2,PGA,DDR3,3MB / 6MB,NB9PGS,1G_LAN_ITM,-,- 1 SA
ODD CONN SCREW 6001-001570 SCREW-MACHINE CH,+,-,M2,L4,ZPC(BLK),SWRCH18A,FP,NYLOCK,T1.0 2 SA
JEXP1 3709-001491 CONNECTOR-CARD SLOT 26P,1.0mm,ANGLE,AU,EXPRESS CARD 1 SA
RUBBER-PCB BA81-04900A RUBBER-PCB OSLO2,SILICON,W5.5*L5.5*H3.2mm,GRAY,HS80,-,- 3 SNA
BRACKET-CPU BA61-01060B BRACKET-SUPPORT_CPU OSLO,AL,T1.5,W24,L43.5mm,Silver,Mylar 1 SA
PBA SN LABEL BA68-40005L LABEL-BARCODE NOTE PC,-,WHITE PET,-,W40.0,L6.0MM,-,-,-,- 1 SNA
INSULATOR-ITM BA81-03488A INSULATOR-DVBT OSLO,PC,T0.1,W47*L30mm,BLACK,-,- 1 SA
INSULATOR-WLAN BA81-03488A INSULATOR-DVBT OSLO,PC,T0.1,W47*L30mm,BLACK,-,- 1 SA
INSULATOR-LAN BA81-03672A INSULATOR-PCB OSLO,PC,T0.1,W22*L14mm,BLACK,-,- 1 SNA
INSULATOR-PCB BA81-03672A INSULATOR-PCB OSLO,PC,T0.1,W22*L14mm,BLACK,-,- 1 SNA
RUBBER-MINICARD BA81-03525A RUBBER-MINICARD OSLO,SILICON,W5*L5*T4.0mm,BLACK,HS80,-,- 1 SNA
INSULATOR-STIFFENER BA81-03930A INSULATOR-STIFFENER OSLO,PC,W7.8*L6.4*T0.5mm,BLACK,-,- 1 SNA
INSULATOR-COMPONANT BA62-00275A INSULATION-COMPONENT BLADE,PC,T0.15,W5.5,L16,BLACK,-,-,COMPONENT 1 SNA
SPONGE-THERMAL_TOP BA81-04889A SPONGE-THERMAL_TOP OSLO,PORON SPONGE,W10*L10*T0.8mm,BLACK,HS50,-,- 1 SNA
RUBBER-SUPPORT_KBD BA81-03489A RUBBER- OSLO,NBR,HS80,W7.5*L7.5*H2.7mm,BLACK,-,- 1 SNA
INSULATOR-EXPRESS BA81-05187A INSULATOR-EXPRESS OSLO2,PC,W58.96,L51.5,T0.1mm,BLACK 1 SNA
INSULATION-MEMORY BA81-04474A INSULATOR-MEMORY OSLO-R,PC,W64*L30*T0.2mm,BLACK,DDR3 ONLY,- 1 SNA
PBA SUB MATERIAL BA99-07566A ASSY SUB/MATERIAL-NP_PBA N/P,PBA SUB/MATERIAL,WIRE,FLUX,- 1 SNA
1.0 PBA 0202-001498 SOLDER-WIRE FLUX SR34 SUPER LFM-48,-,D1,96.5Sn/3Ag/0.5Cu,Flux_3.5% 1 SNA
SOLDERING MACHINE 0204-001105 FLUX RF800KN,-,-,- 0.001 SNA
PBA CLEANING 0204-000124 ETHANOL ISO-PPROPYLENE,C2H50H,-,- 0.017 SNA
INSULATOR-RING_L BA81-01569A INSULATOR-RING_L MALIBU,PC,T0.1,W5.3*L12.5mm,BLACK,- 1 SNA
BRACKET-CPU BA75-01937A UNIT-BRACKET_CPU PALAU,SEC,SPCC,W50*L40*T1.5mm,-,-,-,PBA 1 SA
EXPRESS SCREW 6001-001532 SCREW-MACHINE CH,+,M2,L3,ZPC(BLK),SWRCH18A,FP,NYLOCK 2 SA
INSULATOR-DC BA81-03671A INSULATOR-DC OSLO,PC,T0.5,W4*L5.5mm,BLACK,-,- 1 SNA
RTC BATTERY 4301-000108 BATTERY-LI 3V,220mAH,BUTTON,20x3.2mm,NO 1 SC
GASKET-HDMI BA81-03765A GASKET-HDMI OSLO,CONDUCTIVE FABRIC,W10*L5*T0.5mm,NTR,-,-,- 1 SNA
SMT BA92-04951B ASSY MOTHER BD-SMT OSLO2,PGA,DDR3,3MB / 6MB,NB9PGS,1G+MODEM_ITM,-,- 1 SNA
SMT_U BA92-04951C ASSY MOTHER BD-SMT_U OSLO2,PGA,DDR3,3MB / 6MB,NB9PGS,1G+MODEM_ITM,-,- 1 SNA
B1 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B100 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B12 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B13 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B14 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B15 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B16 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B17 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B18 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B19 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B2 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B20 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B21 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B23 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B24 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B25 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B26 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B27 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B28 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B29 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
6-3
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
B30 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B31 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B32 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B33 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B34 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B35 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B36 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B38 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B41 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B42 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B43 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B5 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B6 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B7 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B8 3301-001649 BEAD-SMD 180ohm,1608,-,TP,-,226ohm/389MHz,- 1 SNA
B3 3301-001272 BEAD-SMD 120ohm,2x1.25x1mm,-,TR,-,-,- 1 SNA
B4 3301-001272 BEAD-SMD 120ohm,2x1.25x1mm,-,TR,-,-,- 1 SNA
C1 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C10 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C11 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C12 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C13 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C14 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C17 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C188 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C189 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C190 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C191 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C194 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C195 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C196 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C197 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C198 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C199 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C2 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C200 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C201 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C219 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C223 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C224 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C226 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C227 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C231 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C235 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C240 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C244 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C245 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C248 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C251 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C260 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
6-4
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C27 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C28 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C283 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C284 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C285 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C286 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C287 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C288 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C289 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C293 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C294 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C295 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C297 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C299 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C309 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C314 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C318 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C32 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C320 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C323 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C324 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C325 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C326 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C327 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C328 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C329 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C33 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C330 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C34 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C35 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C354 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C356 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C359 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C36 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C361 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C362 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C363 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C364 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C366 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C367 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C368 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C369 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C370 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C371 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C372 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C373 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C374 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C375 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C38 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
6-5
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C396 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C398 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C4 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C401 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C402 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C403 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C404 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C405 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C406 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C407 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C41 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C411 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C412 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C413 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C414 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C415 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C416 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA robson
C42 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C420 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA robson
C423 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C426 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C431 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C433 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C439 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA MDC-model
C447 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C461 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C462 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C466 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C467 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C468 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C469 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C470 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C473 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C7 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C8 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C83 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C88 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C89 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C9 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C94 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
C95 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,1005 1 SA
D4 0404-001017 DIODE-SCHOTTKY BAT54,30V,200MA,SOT-23,TP 1 SNA
D7 0404-001017 DIODE-SCHOTTKY BAT54,30V,200MA,SOT-23,TP 1 SNA
J6 3711-000922 HEADER-BOARD TO CABLE BOX,4P,1R,1.25mm,SMD-A,SN,WHT 1 SNA
J5 3708-002402 CONNECTOR-FPC/FFC/PIC 6P,1.0mm,SMD-A,SnBi,Y,SLIDE,BOTTOM 1 SA
J4 3711-002050 CONNECTOR-HEADER BOX,10P,1R,1.25mm,SMD-A,SN,WHT 1 SNA
J2 3711-003609 HEADER-BOARD TO CABLE BOX,2P,1R,1.25MM,SMD-A,SN,BEG 1 SA MDC-model
J3 3711-003609 HEADER-BOARD TO CABLE BOX,2P,1R,1.25MM,SMD-A,SN,BEG 1 SA MDC-model
J1 3711-000456 HEADER-BOARD TO CABLE BOX,4P,1R,1.25mm,SMD-S,SN,NTR 1 SA
6-6
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
J9 3711-000456 HEADER-BOARD TO CABLE BOX,4P,1R,1.25mm,SMD-S,SN,NTR 1 SA
D8 0401-000132 DIODE-SWITCHING BAV99,70V,50mA,SOT-23,TP 1 SNA
D9 0401-000132 DIODE-SWITCHING BAV99,70V,50mA,SOT-23,TP 1 SNA
Q16 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q17 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q18 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q21 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q28 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q29 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q3 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q36 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q37 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q41 0505-001883 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323 1 SNA
Q2 0505-001861 FET-SILICON SI2315BDS,P,-12V,-3A,0.100OHM,0.75W,SOT-23 1 SNA
Q1 0502-001226 TR-POWER BCP69,PNP,1350MW,SOT-223,TP,100-250 1 SNA
Q4 0502-001226 TR-POWER BCP69,PNP,1350MW,SOT-223,TP,100-250 1 SNA
M3 BA61-00963A SUPPORT-VIDEO_BOARD-LF VENICE,CU ALLOY,T3.5,W3.5,L3.9mm,-,LEAD FREE 1 SA
M1 BA61-00955A SUPPORT-3IN1_BD NEON,Cu,T2,W3.5,L3.5mm,WHITE,- 1 SNA
M2 BA61-00955A SUPPORT-3IN1_BD NEON,Cu,T2,W3.5,L3.5mm,WHITE,- 1 SNA
L8 2703-003233 INDUCTOR-SMD 3.9uH,20%,10x10mm 1 SNA
L7 2703-003135 INDUCTOR-SMD 4.7uH,20%,6965 1 SNA
L6 2703-002646 INDUCTOR-SMD 10uH,20%,2012 1 SNA
U2 1203-003898 IC-POWER SUPERVISOR SC452IMLTRT,MLP,44P,7x7mm,PLASTIC,0.3/6.5V,-,- 1 SNA
U1 1009-001010 IC-HALL EFFECT S/W A3212ELH/HED55XXU12,SC- 1 SNA
R10 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R100 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R111 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA GDDR3_1Gb
R146 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R179 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R200 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA GDDR3_1Gb
R223 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R257 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R285 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R286 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R334 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R336 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R52 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R54 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R7 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R73 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R8 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R81 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R9 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 1 SNA
R3 2007-008015 R-CHIP 75ohm,1%,1/16W,TP,1005 1 SNA
R4 2007-008015 R-CHIP 75ohm,1%,1/16W,TP,1005 1 SNA
R5 2007-008015 R-CHIP 75ohm,1%,1/16W,TP,1005 1 SNA
R6 2007-008015 R-CHIP 75ohm,1%,1/16W,TP,1005 1 SNA
Y3 2801-003856 CRYSTAL-SMD 0.032768MHz,20ppm,28-ACP,7pF,65000ohm,TP 1 SA
C19 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
6-7
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C20 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
C21 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
C22 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
C23 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
C24 2203-000627 C-CER,CHIP 0.022nF,5%,50V,C0G,1005 1 SNA
C18 2203-005509 C-CER,CHIP 330nF,+80-20%,10V,Y5V,1005 1 SNA
C474 2203-005509 C-CER,CHIP 330nF,+80-20%,10V,Y5V,1005 1 SNA
C105 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C106 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C108 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C109 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C110 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C111 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C112 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C113 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C16 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C192 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C204 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C205 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C209 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C211 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C228 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C243 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C250 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C254 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C270 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C342 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C388 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C393 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C397 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C399 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C434 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C450 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C451 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C455 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C74 2203-005918 C-CER,CHIP 1000nF,10%,6.3V,X7R,1608 1 SA
C100 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C104 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C132 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C136 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C137 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C138 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C145 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C149 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C15 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C151 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C153 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C157 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C158 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
6-8
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C164 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C169 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C170 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C171 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C172 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C177 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C180 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C181 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C183 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C213 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C229 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C230 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C261 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C265 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C266 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C268 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C271 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C272 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C331 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C332 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C333 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C334 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C335 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C336 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C337 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C338 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C346 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C347 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C376 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C377 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C378 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C379 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C380 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C381 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C382 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C383 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C384 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C385 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C400 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C417 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C418 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C419 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C421 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C429 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C98 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C99 2203-005482 C-CER,CHIP 100nF,10%,10V,X5R,1005 1 SNA
C107 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C142 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C146 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
6-9
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C147 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C150 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C152 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C154 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C155 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C159 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C178 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C179 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C182 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C184 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C185 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C238 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C29 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C296 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C31 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C310 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C353 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C386 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C39 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C390 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C409 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C410 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C424 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C425 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C428 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C440 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA MDC-model
C442 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C460 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C84 2203-006090 C-CER,CHIP 10000nF,10%,6.3V,X5R,TP,2012 1 SA
C167 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C206 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C212 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C241 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C25 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C252 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C253 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C257 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C258 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C291 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C30 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C305 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C312 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C316 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C321 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C360 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C365 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C37 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C387 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C422 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C43 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
6-10
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C456 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
C472 2203-006824 C-CER,CHIP 4700NF,10%,10V,X5R,1608 1 SA
Q27 0505-001049 FET-GAAS BSS84,-50V,20V,-130mA,360mW,SOT-23,TP 1 SNA
Q38 0505-001049 FET-GAAS BSS84,-50V,20V,-130mA,360mW,SOT-23,TP 1 SNA
Q39 0505-001049 FET-GAAS BSS84,-50V,20V,-130mA,360mW,SOT-23,TP 1 SNA
Q35 0505-001173 FET-SILICON PHKD13N03LT,N,30V,10.4A,0.02ohm,3.57W,SO-8 1 SNA
Q5 0505-001173 FET-SILICON PHKD13N03LT,N,30V,10.4A,0.02ohm,3.57W,SO-8 1 SNA
Q13 0505-002189 FET-SILICON AP6680AGM,N,30V,12A,0.0165ohm,2.5W,SO-8 1 SNA
Q31 0505-002189 FET-SILICON AP6680AGM,N,30V,12A,0.0165ohm,2.5W,SO-8 1 SNA
Q32 0505-002189 FET-SILICON AP6680AGM,N,30V,12A,0.0165ohm,2.5W,SO-8 1 SNA
Q40 0505-002189 FET-SILICON AP6680AGM,N,30V,12A,0.0165ohm,2.5W,SO-8 1 SNA
Q14 0501-000465 TR-SMALL SIGNAL MMBT3904,NPN,350mW,SOT-23,TP,30-300 1 SA
Q10 0505-002183 FET-SILICON AP4435GM,P,-30V,-8A,0.015ohm,2.5W,SO-8 1 SNA
Q11 0505-002183 FET-SILICON AP4435GM,P,-30V,-8A,0.015ohm,2.5W,SO-8 1 SNA
J10 3710-002133 SOCKET-BOARD TO BOARD 12P,2R,0.8mm,SMD-A,SN,NTR 1 SNA
EC17 2402-001316 C-AL,SMD 330F,20%,2.5V,-,TP,7.3*4.3*1.9mm 1 SNA
EC18 2402-001316 C-AL,SMD 330F,20%,2.5V,-,TP,7.3*4.3*1.9mm 1 SNA
EC19 2402-001316 C-AL,SMD 330F,20%,2.5V,-,TP,7.3*4.3*1.9mm 1 SNA
EC9 2402-001316 C-AL,SMD 330F,20%,2.5V,-,TP,7.3*4.3*1.9mm 1 SNA
EC5 2402-001306 C-AL,SMD 330F,20%,2V,-,Tape and Reel,7.3x4.3x1.9mm 1 SNA
EC6 2402-001306 C-AL,SMD 330F,20%,2V,-,Tape and Reel,7.3x4.3x1.9mm 1 SNA
EC7 2402-001306 C-AL,SMD 330F,20%,2V,-,Tape and Reel,7.3x4.3x1.9mm 1 SNA
EC8 2402-001306 C-AL,SMD 330F,20%,2V,-,Tape and Reel,7.3x4.3x1.9mm 1 SNA
EC4 2402-001144 C-AL,SMD 68uF,20%,25V,LZ,TP,6.3*5.8mm 1 SNA
EC1 2409-001117 C-ORGANIC,SMD 10uF,20%,25V,CAN,TP,6.8*6.8*6.0mm,- 1 SNA
EC2 2409-001117 C-ORGANIC,SMD 10uF,20%,25V,CAN,TP,6.8*6.8*6.0mm,- 1 SNA
EC3 2409-001117 C-ORGANIC,SMD 10uF,20%,25V,CAN,TP,6.8*6.8*6.0mm,- 1 SNA
D17 0404-001020 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP 1 SNA
D11 0404-001084 DIODE-SCHOTTKY BAT54A,30V,200MA,SOT-23,TP 1 SNA
D12 0404-001084 DIODE-SCHOTTKY BAT54A,30V,200MA,SOT-23,TP 1 SNA
D16 0404-001084 DIODE-SCHOTTKY BAT54A,30V,200MA,SOT-23,TP 1 SNA
D10 0404-001382 DIODE-SCHOTTKY CRS06,20V,1000mA,3-2A1A,TP 1 SNA
C101 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C118 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C119 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C120 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C121 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C122 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C123 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C124 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C125 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C126 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C127 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C135 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C139 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C144 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C255 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C26 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C267 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
6-11
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Main System
Location SEC CODE NAME Description Qt'y SA/SNA Option
C269 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C319 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C340 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C97 2203-006474 C-CER,CHIP 22000nF,20%,6.3V,X5R,2012 1 SA
C141 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C160 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C161 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C174 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C176 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C220 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C222 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C225 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C233 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C242 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C278 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C302 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C303 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C304 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C307 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C308 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C311 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C313 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C315 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 1 SNA
C349 2203-000438 C-CER,CHIP 1nF,10%,50V,X7R,1005 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
