Image preview - the first page of the document
>> Download Part List documenatation <<
Text preview - extract from the document
- -
- This Document can not be used without Samsung's authorization -
5. Part List
NP-R560-ASS0RU
Location Part Number Parts Name & Specification Q'ty SA/SNA
A0010 3903-000115 CBF-POWER CORD;DT,EU,CP3,IEC320 C5,250/2 1 SA
A1001 BA46-05864A S/W CD;UTILITY,POPLAR-H,WinVista,1.0,K/E 1 SA
A1001 BA46-08031A S/W CD;RCD,NP/DT,VISTAHP SP1,1.0,RUS,DVD 1 SA
A1001 BA46-08439A S/W CD;UTILITY,OSLO2,WINVISTASP1,-,Expor 1 SA
B0001 BA75-02018A UNIT-HOUSING_BOTTOM;OSLO2,SEC,PC+ABS, T1 1 SA
B0003 BA81-03380A DOOR-MEMORY;OSLO,PC+ABS,W64.5*L160.5*H9, 1 SA
B0009 BA81-03443B RUBBER-FOOT;OXFORD,HS60,L19*W6.5*H3.9mm, 5 SA
B0010 BA81-03458A RUBBER-FOOT_CENTER;OSLO,SILICON,HS70,W3. 1 SA
B0013 BA61-01138A DUMMY CARD-EXPRESS;OSLO,PC+ABS,H4.7,W55, 1 SA
B0100 BA75-01860B UNIT-DOOR_HDD;OSLO2,SEC,PC+ABS,1.5T,W114 1 SA
B0150 BA75-01788A UNIT-BRKT_HDD;FIRENZE2,SESC,SUS T0.3,W10 1 SA
B0302 BA81-02795A LINK-BATTERY_L;FIRENZE2,POM,L26.4*W10.8* 1 SA
B0303 BA81-02794A LINK-BATTERY_R;FIRENZE2,POM,L26.4*W10.8* 1 SA
B0402 BA81-03382A KNOB-BATTERY_R;OSLO,PC+ABS,W25*L6.5*H7.8 1 SA
B0403 BA81-03383A KNOB-BATTERY_L;OSLO,PC+ABS,W25*L6.5*H7.8 1 SA
B0501 BA61-00780A SPRING ETC-BATT;AQUILA-P,STS304,CD0.3,ID 2 SA
D0001 BA96-03602A ASSY DVD-SUPERMULTI;Oslo2,TS-L633A,5/8(D 1 SA
D1002 BA59-02234A DVD-SUPERMULTI;TS-L633A,8x,130ms,SATA,2M 1 SA
D2000 BA81-03428A BRACKET-ODD;OSLO,SUS304,W27*L10*T1.0mm,N 1 SA
D3000 BA75-01863B UNIT-BEZEL_ODD-MULTI_DL;HAINAN2,DOMESTIC 1 SA
G0003 BA59-02321A MODULE-WLAN;N/P,512AGXMMWG,-,802.11AG,mi 1 SA
G0011 BA59-01691A MODULE-BLUETOOTH;Bluetooth V2.0,T60H928. 1 SA
G0011 BA59-01916A MODULE-BLUETOOTH;Bluetooth Version 2.0,B 1 SA
I0001 0902-002341 IC-MICROPROCESSOR;AW80577SH0513M,2.26GHz 1 SA
I0002 1105-001923 IC-DRAM MODULE;M471B2874DZ1-CF8,DDR3 SDR 2 SA
I0003 BA59-02278A LCD PANEL-154WXGA_G;CLAA154WB03AN,154WXG 1 SA
I0005 BA59-02190A HDD;250G,HM250JI,S63,H16,D16385,H9.5mm,2 1 SA
I0005 BA59-02205A HDD;250G,HTS542525K9A300,S63,H16,D16385, 1 SA
I0005 BA59-02211A HDD;250G,MHY2250BH,S63,H16,D16385,9.5mm, 1 SA
I0005 BA59-02288A HDD;250G,MK2546GSX,S63,H16,D16385,H9.5mm 1 SA
I0005 BA59-02354A HDD;250G,HM251JI,S63,H16,D16385,9.5mm,2. 1 SA
I0006 BA59-02295C KEYBOARD;LYON,88K,Membrane,-,RUSSIA,-,BL 1 SA
I0006 BA59-02295G KEYBOARD;LYON,88K,Membrane,-,RUSSIA,-,BL 1 SA
I0007 BA44-00210A ADAPTOR;API5AD10,AD-9019S,-,90to264Vac,4 1 SA
I0007 BA44-00215A ADAPTOR;0455A1990,AD-9019S,AC/DC,90to264 1 SA
I0007 BA44-00233A ADAPTOR;SADP-90FH B,AD-9019S,-,100/240VA 1 SA
I0007 BA44-00244A ADAPTOR;PA-1900-08S,AD-9019S,-,90to264Va 1 SA
5-1
- -
- This Document can not be used without Samsung's authorization -
5. Part List
NP-R560-ASS0RU
Location Part Number Parts Name & Specification Q'ty SA/SNA
I0009 BA43-00149A BATTERY;P32R07-02-H01,SEDONA,Li-ion,2P3S 1 SA
I0009 BA43-00150A BATTERY;3UR18650F-2-SDN-12,Sedona,Li-ion 1 SA
I0013 BA59-02244A MODULE-CAMERA;SCB-1300D,GD-5931A,1.3M CA 1 SA
K0001 BA75-02095A UNIT-HOUSING_LCD_BACK;OSLO2,SEC,PC+ABS,1 1 SA
K0002 BA75-02096A UNIT-HOUSING_LCD_FRONT;OSLO2,SEC,PC+ABS, 1 SA
K0007 BA64-00716A LOGO-SAMSUNG;HAINAN2,DOMESTIC,T0.75,8.25 1 SA
K0101 BA81-05588A RUBBER-FRONT_LOWER;OSLO2,SILICON,W5*L5*H 2 SA
K1001 BA39-00637A CBF HARNESS-CONN;OSLO,Teflon,UL10005,30/ 1 SA
K1001 BA39-00638A CBF HARNESS-CONN;OSLO,Wire,UL10005,30/8/ 1 SA
K1002 BA44-00248A INVERTER;OSLO,541180560003,DC,8.5to20V,1 1 SA
K1002 BA44-00249A INVERTER;OSLO,DAC-09N019 AF,DC,8.5Vto20V 1 SA
K1002 BA44-00250A INVERTER;OSLO,VK.21209.202,DC,8.5to20V,1 1 SA
K1007 BA39-00760A CBF HARNESS-WEBCAMERA;OSLO2,WIRE,-,5/4P, 1 SA
K2001 BA42-00182A ANTENNA-MAIN;SS-03-03-099,Oslo,2.3to6GHz 1 SA
K2002 BA42-00183A ANTENNA-AUX;SS-03-03-100,Oslo,2.3to6GHz, 1 SA
K3001 BA61-01113A HINGE-L;OSLO,SUS,H20,W31,L24mm,NTR,-,DET 1 SA
K3002 BA61-01116A HINGE-R;OSLO,SUS,H20,W31,L24mm,NTR,-,DET 1 SA
K4000 BA75-01886C UNIT-BRACKET_LCD_UPPER;OSLO2,SEC,SUS,T0. 1 SA
K4001 BA81-03386A BRACKET-LCD_L;OSLO,SECC,T0.8,W28.2*L246. 1 SA
K4002 BA81-03387A BRACKET-LCD_R;OSLO,SECC, 0.8T,W26.2*L246 1 SA
L1004 BA68-20039A LABEL-PPID_E;BLADE,-,PET,-,W50.8,L12.7mm 1 SA
M0001 BA92-04953A ASSY MOTHER BD-TOP;OSLO2,PGA,DDR3,3MB / 1 SA
M1002 3301-001594 BEAD-SMD;90ohm,2.0*1.2*1.3mm,-,TP,-,-,- 1 SA
M1004 2203-005052 C-CER,CHIP;0.0033nF,0.25pF,50V,NP0,1005 1 SA
M1004 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,1608 1 SA
M1004 2203-006000 C-CER,CHIP;1NF,10%,3KV,X7R,TP,4520 1 SA
M1009 3711-000456 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 SA
M1009 3711-003609 HEADER-BOARD TO CABLE;BOX,2P,1R,1.25MM,S 1 SA
M1013 2801-003856 CRYSTAL-SMD;0.032768MHz,20ppm,28-ACP,7pF 1 SA
M1021 1201-001991 IC-AUDIO AMP;TPA6017A2PWPR,TSSOP,20P,6.5 1 SA
M1028 3722-002002 JACK-USB;4P/1C,AUF/TIN,BLK,ANGLE-OFFSET, 1 SA
M1028 3722-002601 JACK-USB;4P/2C,AUF,BLK,ANGLE-OFFSET,A TY 1 SA
M1029 2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608 1 SA
M1033 4301-000108 BATTERY-LI;3V,220mAH,BUTTON,20x3.2mm,NO 1 SA
M3001 BA96-03224B ASSY COOLER-CPU;OSLO,CPU,KDB0705HA-7F66, 1 SA
M3001 BA96-03336A ASSY COOLER-CPU;OSLO,CPU,KDB0705HA-7F66, 1 SA
M3004 BA81-03505B FAN;OSLO,KDB0705HA-7F66,PET,2200rpm,5V,D 1 SA
5-2
- -
- This Document can not be used without Samsung's authorization -
5. Part List
NP-R560-ASS0RU
Location Part Number Parts Name & Specification Q'ty SA/SNA
M4000 BA59-02036A MODEM;1456VQL-T3(INT-RoHS),56Kbps,Agere 1 SA
M4000 BA59-02037A MODEM;T60M951.07 LF,56Kbps,Agere 2 Chip, 1 SA
M4001 BA39-00593A CBF HARNESS;FIRENZE2,WIRE,-,2,240mm,BLAC 1 SA
M4001 BA39-00632A CBF HARNESS-MODEM;OSLO,WIRE,-,2,220mm,BL 1 SA
M9999 0403-001047 DIODE-ZENER;BZX84C12L,5%,225mW,SOT-23,TP 1 SA
M9999 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 1 SA
M9999 0601-002037 LED;SMD,BLUE,1.6x0.8x0.4mm,465/470nm,1.6 1 SA
M9999 0801-002628 IC-CMOS LOGIC;7SZ08,2-INPUT AND GATE,SC- 1 SA
M9999 0903-001439 IC-MICROCOMPUTER;HD64F2110BVTE10V,TQFP,1 1 SA
M9999 0904-002297 IC-BUS CONTROLLER;AU6371B51-JEL-NP,LQFP, 1 SA
M9999 0904-002373 IC-GRAPHIC CONT.;NB9P-GE2,BGA,969P,29x29 1 SA
M9999 0904-002376 IC-DRAM CONTROLLER;EB88CTPM,FCBGA,1329P, 1 SA
M9999 0904-002378 IC-I/O CONTROLLER;AF82801IBM,mBGA,676P,3 1 SA
M9999 1103-001165 IC-EEPROM;24C08,8KBIT,1KX8BIT,SOP,8P,5X4 1 SA
M9999 1103-001333 IC-EEPROM;24C08A,1Kx8Bit,SOP,8P,5x4mm,-, 1 SA
M9999 1105-001908 IC-GDDR3;K4J52324QE-BC12,GDDR3 SDRAM,512 1 SA
M9999 1203-003765 IC-PWM CONTROLLER;SC486IMLTRT,MLP,24P,4x 1 SA
M9999 1203-004471 IC-PWM CONTROLLER;ISL6256AHRZ-T,QFN,28P, 1 SA
M9999 1203-004685 IC-PWM CONTROLLER;SC415,MLPQ,24P,4x4mm,P 1 SA
M9999 1203-004687 IC-PWM CONTROLLER;TPS51120,QFN,32P,5x5mm 1 SA
M9999 1203-004943 IC-PWM CONTROLLER;SC471MLTRT,MLPQ,16P,3X 1 SA
M9999 1205-002596 IC-SWITCH;TPS2062,SOIC,8P,5x6x1.65mm,PLA 1 SA
M9999 1205-002807 IC-SWITCH;R5538D001-TR-F,QFN,20P,4x4mm,P 1 SA
M9999 1205-003091 IC-ETHERNET CONTROLLER;88E8055,QFN,64P,9 1 SA
M9999 1205-003156 IC-CLOCK GENERATOR;SLG8SP513,QFN,64P,9x9 1 SA
M9999 1209-001718 IC-SENSOR;EMC2102,QFN,28P,5x5mm,PLASTIC, 1 SA
M9999 2007-007274 R-CHIP;27.4Kohm,1%,1/10W,TP,1608 1 SA
M9999 2203-001201 C-CER,CHIP;0.0070nF,0.5pF,50V,NP0,1005 1 SA
M9999 2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,1005 1 SA
M9999 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
M9999 2203-006090 C-CER,CHIP;10000nF,10%,6.3V,X5R,TP,2012 1 SA
M9999 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,2012 1 SA
M9999 2203-006824 C-CER,CHIP;4700NF,10%,10V,X5R,1608 1 SA
M9999 3404-001311 SWITCH-TACT;12VDC,50mA,100gf,6.0x6.0x5.0 1 SA
M9999 3701-001403 CONNECTOR-DSUB;15P,2R,FEMALE,ANGLE,NI 1 SA
M9999 3708-002166 CONNECTOR-FPC/FFC/PIC;25P,0.5mm,SMD-A,AU 1 SA
M9999 3708-002402 CONNECTOR-FPC/FFC/PIC;6P,1.0mm,SMD-A,SnB 1 SA
5-3
- -
- This Document can not be used without Samsung's authorization -
5. Part List
NP-R560-ASS0RU
Location Part Number Parts Name & Specification Q'ty SA/SNA
M9999 3709-001398 CONNECTOR-CARD EDGE;52P,0.8mm,SMD-A,AU,M 1 SA
M9999 3709-001491 CONNECTOR-CARD SLOT;26P,1.0mm,ANGLE,AU,E 1 SA
M9999 3709-001523 CONNECTOR-CARD EDGE;204P,0.6mm,ANGLE,AU, 1 SA
M9999 3709-001524 CONNECTOR-CARD EDGE;204P,0.6mm,ANGLE,AU, 1 SA
M9999 3710-002635 SOCKET-INTERFACE;13P,1R,1mm,ANGLE,AU,BLK 1 SA
M9999 3711-000541 HEADER-BOARD TO CABLE;BOX,2P,1R,1.25mm,S 1 SA
M9999 3711-006059 HEADER-BATTERY;NOWALL,7P,1R,2.5,BATTERY, 1 SA
M9999 3711-006496 CONNECTOR-HEADER;NO WALL,26P,1R,1mm,SMD- 1 SA
M9999 3722-002132 JACK-DC POWER;3P,5.5mm,SN-P,BLK 1 SA
M9999 3722-002365 JACK-PHONE;6P,AUF,PINK 1 SA
M9999 3722-002390 JACK-MODULAR;8P/8C,REVERSE,YES,ANGLE-OFF 1 SA
M9999 3722-002416 JACK-PHONE;6P,AUF,LIME,ANGLE 1 SA
M9999 BA26-00004A TRANS MATCHING;H5015,-,12P/12P,-,350uH,- 1 SA
M9999 BA61-00963A SUPPORT-VIDEO_BOARD-LF;VENICE,CU ALLOY,T 1 SA
M9999 BA61-01060B BRACKET-SUPPORT_CPU;OSLO,AL,T1.5,W24,L43 1 SA
M9999 BA75-01937A UNIT-BRACKET_CPU;PALAU,SEC,SPCC,W50*L40* 1 SA
T0001 BA75-02017B UNIT-HOUSING_TOP;OSLO2,SEC,PC+ABS,1.6T,W 1 SA
T0002 BA81-04469B HOUSING-TOP_SVC;OSLO2,SEC,PC+ABS,T1.6,W3 1 SA
T0005 BA68-02155A LABEL-NVIDIA;AQUILA,ALL,-,-,W20,L20MM,SI 1 SA
T0005 BA68-03880A LABEL-LOGO_CENTRINO-DUO2_SANTA;OSLO,N/P 1 SA
T0005 BA68-04123A LABEL-LOGO_VISTA-PREMIUM;N/P,VISTA Premi 1 SA
T0005 BA68-04285A LABEL-ZAIGEN;OSLO2,EECIS,PET,-,W41,L90mm 1 SA
T0010 BA75-01992C UNIT-CAP_TOP_CR;OSLO2,SEC,PC+ABS,T1.5,W3 1 SA
T0101 BA59-02145A BOARD-TOUCHPAD;ACCORDION,TM-01020-003,BO 1 SA
T0301 BA41-00873A FFC-TOCUPAD;OSLO2,1.0,Film,12PIN,T0.35mm 1 SA
T2001 BA96-03220A ASSY SPEAKER;OSLO,X03020R-005,W170*L470m 1 SA
T2004 BA81-00766A RUBBER-SPEAKER;NEON,SILICON/HS40,W6.2*L6 4 SA
T2200 BA39-00524A CBF HARNESS-MIC;HABANA,-,AWG32,2P,-,WHT/ 1 SA
T4003 BA67-00292A CAP-DMB;FIRENZE2,PC/ABS,T1.5,W4.5,L2.8mm 1 SA
T9803 BA81-03890A TAPE-TOUCHPAD;ACCORDION,3M200,W65*L38*T0 1 SA
W3007 BA39-00701A WIRE HARNESS-BLUETOOTH;LYON,Wire,UL1571, 1 SA
W3007 BA39-00702A WIRE HARNESS-BLUETOOTH;LYON,Wire,UL1571, 1 SA
W4001 6001-001625 SCREW-MACHINE;BH,+,-,M2.6,L8,ZPC(BLK),SW 2 SA
W4002 6001-001406 SCREW-MACHINE;CH,+,M2.0,L6.0,NI PLT,SWRC 2 SA
W4002 6001-001480 SCREW-MACHINE;CH,+,M3,L4.0,ZPC(BLK),SWRC 2 SA
5-4
- -
- This Document can not be used without Samsung's authorization -
5. Part List
NP-R560-ASS0RU
Location Part Number Parts Name & Specification Q'ty SA/SNA
W4002 6001-001532 SCREW-MACHINE;CH,+,M2,L3,ZPC(BLK),SWRCH1 2 SA
W4002 6001-001570 SCREW-MACHINE;CH,+,-,M2,L4,ZPC(BLK),SWRC 1 SA
5-5
