Image preview - the first page of the document
>> Download R25plus documenatation <<
Text preview - extract from the document
R25Plus
R25
-
1. R25
Napa-refresh LCD
-Merom/Yyonah CPU -nVIDIA G72M-V -200nit Glare/Non Glare
-4MB/2MB Core2 Duo/Core Duo -128MB GDDR 100~300Mhz - 14.1" WXGA(1280*800)
-Intel 945PM&ICH7M
-DDR2 667/533MHz HDD
- 9.5mmH, User Replaceable
- 60GB ~ 200GB
- SATA 5400Rpm
- -HDD
- PCI Express Card slot
ODD
- 3 USB2.0
- DVD-ROM, DVD-Combo,
- VGA
-Super- Multi (Dual Layer)
- 4 in 1 Memory Card slot MS,SD,XD,MMC
- RJ45/11,
- HP out , Mic-in Power Management
- 4 Cell / 8 Cell Battery
- Over 4hr
- long life smart LI-Lon 8cell
-ACPI V2.0 compliant
- 10/100 Ethernet
-Wireless
.Mini Card (802.11bg/abg) -
.Bluetooth V2.0+EDR - Ag+
-340.4 x 259.6 x (28.0 ~ ) 31.1 ~ 38.7mm
-2.4Kg with 4 cell battery
PCMCIA PATA HDD !!!
