Image preview - the first page of the document



>> Download AN17_753S Bulletins documenatation <<

Text preview - extract from the document

                 ELECTRONICS
                                                  SERVICE BULLETIN
Product : CRT Monitor                                    Bulletin No.   : 02-C/M-E0093
Model     : AN15V,AN17L,AN17K                            ECN date       : 05.Nov,2002
Buyer     :                                              Bulletin Date : 06.Nov,2002

SUBJECT : One clolor missing due to capacitor failure.

Background : Capacitor CG04,CR04,CB04 on video board could fail due to reverse voltage inflow.
              Reverse voltage inflows into these capacitors when DPMS mode of monitor is turned off.
              This reverse voltage can cause capacitor failure.
              * Symptom : one color missing. (Red or Green or Blue)




Solution :    Replace 3 capacitors for all returned monitor to prevent future failure.(plus one service)
              - Defective Range : monitor produced until Oct.2002
              - Model : AN15V* , AN17L* , AN17K*



  Location                OLD (before) Parts                        NEW (changed) Parts
    No.          SEC Code             Description           SEC Code              Description
 CR04,CG04,                       1uF,20%,160V,WT,TP,                         C-FILM,MPEF,220nF,
   CB04
                2401-000055            3x11,5mm
                                                           2305-000004      10%,100V,TP,12.7x16,5mm




Application             Reference ( O )   Only Defected sets ( )        Whole sets (    )

Attachment              Schematic Diagram ( O )          None ( )

Published by : C.J.Oh            Checked by : M.S.Park        Approved by : K.S.Yeo
               ELECTRONIC
               S
                                                              SERVICE BULLETIN
                                                                            * Bulletin No: 02-C/M-E0093



Location of capacitors mounted on Inner side of video board

        Before             After                      Replace 3 capacitors (CR04,CG04,CB04)
                                                      as below picture.




 This picture is the video board of AN17L,AN17K model.
