Image preview - the first page of the document
>> Download samsung_e1720n_e1920n_e2020n_e2220n_chassis_lcl17as_lcl19ys_lcl19as_lcl19ns_lcl20ys_lcl22ys_lcl22ns_chinese_sm documenatation <<
Text preview - extract from the document
! !
"#$ !
%&'( !)*
+,
-.$/0
-.$/0
-.
1234
1234
1234
5678
9:;<=<>
12$?@AB
CD
EF$G,HI
EF$G,HI
EF
G,HI
G,HI
G,HI
G,HI
G,HI
G,HI
G,HI
JKF
JKF
JKFLM
JKF LM
NJOPQ
R
STUVWXYZ
[\
[\ Z]
Z]
^_ !"#$%&'(#)"($
`_ )#!&#$%&'(#)"($
abc "!#$%&'(#)"($
de %(#$%&'(#)"($
[ "!&##$%&'(#)"($
fe #!##$%&'(#)"($
g$he $##$%&'(#)"($
klmnopq
ijklmnopqrn stuvi rn
wQxyz{v[|$}[~
[
*
+
!"#$ %&'(
'(
) *+,-
% ./0123456789:;<23
=>?@
AB
CD
EFGHIJ
KL
M$E=>?N/
OPQRF)S
@
=>?NOP/
QRF)STU
@
VWCD
VWCD
XS
YZ[\Z ]XF^_
S@
YZ
`_
?N/
a !bc
?N/
d !bc E
efg
h^_Sij_ _
_
j_
klm
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LS19CLYSB/XF - Exploded View (E1920N)
SB01A
SB04A
R001A
M0107
M0014
BN63-06356A
M0174
M0215
F001A
5-1
5. Exploded View & Part List
5-1-1. Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
F001A BN96-13091A ASSY COVER P-FRONT;Cobalt 18.5W,ABS,HB,B 1 SA
M0014 BN94-03397D ASSY PCB MAIN-STZ;E1920N,STZ 1 SA
M0107 BN63-06355C SHIELD-COVER;PLUM 18.5",SECC,T0.8,18.5" 1 SNA
M0174 BN44-00325B IP BOARD;IP-22155A,PLUM15.6",18.5"w(2Lam 1 SA
M0215 BN07-00703A LCD-PANEL;LTM185AT01,SS8YTSV,6bit Hi-FRC 1 SA
R001A BN96-13090F ASSY COVER P-REAR;Cobalt 18.5W,HIPS,HB,B 1 SA
SB01A BN96-12853A ASSY STAND P-BODY;COBALT,HIPS,BK23,ETCH 1 SA
SB04A BN96-12816A ASSY STAND P-BASE;COBALT 17~20,HIPS HB,B 1 SA
BN63-06356A SHIELD-LAMP;PLUM 18.5'',SPTE,T0.3 1 SNA
5-2
5. Exploded View & Part List
5-2. LS19CLYSB/XF - Parts List (E1920N)
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
0.1 R001A BN90-02725B ASSY COVER REAR;E1920N,BLACK,AMLCD 1 SNA
..2 R001A BN96-13090F ASSY COVER P-REAR;Cobalt 18.5W,HIPS,HB,B 1 SA
SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),S
...3 W391 6003-000275 2 SA
WR
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 SNA
...3 T0060 BN61-05331A SPRING ETC;LAVENDER 23",SK5,T0.5 1 SNA
HOLDER-STAND;LAVENDER
...3 CIS4 BN61-05332A 1 SNA
23",ACETAL,WHITE
...3 M0111 BN63-05625A COVER-STAND;LAVENDER 23W,BK23 1 SNA
...3 R001 BN63-06842E COVER-REAR;Cobalt 18.5W,HIPS,HB,BK23,SIM 1 SNA
RUBBER-
...3 M0126 BN73-00170A 3 SNA
FOOT;943BW,2043BW,RUBBER,8*8,1.5,
...3 BN96-13846A ASSY SHIELD P-LAMP;Cobalt 18.5",STPE,T0. 1 SNA
....4 BN63-06356A SHIELD-LAMP;PLUM 18.5'',SPTE,T0.3 1 SNA
....4 M0131 BP63-00786A GASKET;HLS6187WX/XAA,Conductive Adhesive 1 SNA
0.1 BN91-02220X ASSY LCD;LS19CFNKFY/ZA,BN07-00703A 1 SNA
..2 M0215 BN07-00703A LCD-PANEL;LTM185AT01,SS8YTSV,6bit Hi-FRC 1 SA
0.1 M0017 BN91-05223N ASSY CHASSIS-STZ;E1920NX 1 SNA
..2 M0174 BN44-00325B IP BOARD;IP-22155A,PLUM15.6",18.5"w(2Lam 1 SA
..2 M0014 BN94-03397D ASSY PCB MAIN-STZ;E1920N,STZ 1 SA
...3 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.814 SNA
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.003 SNA
...3 0204-002420 SOLVENT;1M-1000,C3H70H,96 3.47 SNA
...3 0204-002607 FLUX;DF-234U,13%,14KG,Gravity 0.82 2.259 SNA
CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED
...3 3701-001510 1 SNA
PIN
CONNECTOR-
...3 CN906 3711-005847 1 SNA
HEADER;BOX,9P,1R,2MM,ANGLE,SN,
...3 BN97-04137D ASSY SMD;E1920N,STZ,BN94-03397D 1 SNA
SOLDER-CREAM;LST309-
....4 0202-001477 0.462 SNA
M,D20~45um,96.5Sn/3A
DIODE-SWITCHING;MMBD4148SE,100V,200m
....4 DS01A 0401-001056 3 SA
A,SO
....4 DR01A 0402-001614 DIODE-RECTIFIER;S1G,400V,1A,DO-214AC,TP 1 SA
....4 MZD1 0403-001411 DIODE-ZENER;5.49-5.73V,200mW,SOD-323,TP 8 SA
....4 0403-001712 DIODE-ZENER;QZX363C6V8,6.47/7.14V,200mW, 1 SNA
TR-SMALL
....4 PQ02 0501-002080 1 SA
SIGNAL;2SC2412K,NPN,200mW,SC-59
....4 Q409 0505-001165 FET-SILICON;Si3443CDV,P,-20V,+-4.4A,65mo 1 SA
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 SA
....4 IC112 1103-001410 IC-EEPROM;S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 1 SA
....4 T0087 1203-006118 IC-POSI.FIXED REG.;S-1172B18-U5T1G,SOT-8 1 SA
....4 T0087 1203-006141 IC-POSI.FIXED REG.;S-1172B33-U5T1G,SOT-8 1 SA
IC-LCD CONTROLLER;SE919LM-
....4 IC109 1205-003895 1 SA
NT,QFP,64P,7x7
....4 DR1 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 4 SA
....4 CER02 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 2 SNA
....4 AR30 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 20 SA
....4 AVR51 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 1 SNA
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 CER04 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
....4 MROP1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 14 SA
....4 AR108 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 5 SA
....4 ARR2 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 2 SA
....4 ZR24 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 SNA
....4 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 3 SNA
....4 HR13 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 SNA
....4 ZR10 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 3 SNA
....4 R1 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608 6 SNA
....4 C134 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 SA
....4 C409 2203-000292 C-CER,CHIP;0.01nF,5%,50V,C0G,1608 2 SA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 SNA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 SNA
....4 6MC22 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 6 SNA
....4 DC108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 24 SC
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 2 SNA
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 19 SC
CRYSTAL-SMD;12MHz,30ppm,28-
....4 X202 2801-003773 1 SA
AAN,20pF,50oh
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82o
....4 L2011 3301-001145 4 SNA
hm
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 2 SNA
CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-
....4 AC510 3708-001150 1 SA
A,SN,Y
HEADER-BOARD TO
....4 HB01A 3711-005743 1 SA
CABLE;BOX,5P,1R,1.25mm,A
....4 T0077 BN41-01323A PCB MAIN;PLUM B1630N,CEM-3,2,MP1.0,1.6,5 1 SNA
....4 BN97-04136D ASSY MICOM;E1920N,STZ,BN94-03250* 1 SNA
.....5 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8,S 1 SNA
..2 M0006 BN96-12503C ASSY SHIELD P-COVER;PLUM 18.5",SECC,T0.8 1 SNA
...3 BN61-05973A STUD-PEM;PLUM23'',M4,D8,L20 2 SNA
...3 M0107 BN63-06355C SHIELD-COVER;PLUM 18.5",SECC,T0.8,18.5" 1 SNA
...3 T0073 AA63-01141A GASKET-EMI;42D5,Conductive Fabric,1.5mm, 2 SNA
...3 M0131 BN63-00049A GASKET;RB17AS,Conductive Fabric,1.5MM,10 3 SNA
...3 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 1 SNA
SCREW-MACHINE;BH,+,WT,M4,L12,ZPC(WHT
..2 T0081 6001-002408 2 SA
),SW
SCREW-TAPTYPE;PWH,+,-
..2 M0081 6003-000264 2 SA
,B,M3,L6,ZPC(WHT),S
ASSY CABLE P-FLAT CABLE;MCKINLEY,FLAT
..2 M0214 BN96-02854W 1 SA
CA
0.1 BN91-05285A ASSY SHIELD;E1920 1 SNA
..2 CIS1 BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915, 0.3 SNA
0.1 BN92-05486D ASSY LABEL;Cobalt, BLACK 1 SNA
..2 CCM1 BN68-01570A LABEL RATING;ALL,SS,PE,T0.05,90,45,Dark 1 SNA
0.1 BN92-05547L ASSY P/MATERIAL;S19S3,W/W 1 SNA
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 1.31 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 T0524 6902-000241 BAG PE;HDPE/NITRON,T0.5/T0.012,W600,L600 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.5 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
..2 AA69-00243G PAD-PLATE;CB SW-2,YEL,990,990,-,-,SP43J5 1 SNA
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LABEL-SUMMARY;G52,G72,ART,100G,WHT,BL
..2 T0527 BH68-40364A 1 SNA
K,W
..2 BH69-00457A PACKING INNER-00,PAD;COMM,T3.0,1130,1180 1 SNA
..2 T0527 BN68-00129A LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP 1 SNA
PALLET-
..2 BN69-00139L 1 SNA
PACKING;LN17HO,WOODEN,W:1030,D:10
..2 BN69-00391Y PAD-ANGLE;CB,T5,W2100,L50,YEL,403g 1 SNA
..2 BN69-04618A CUSHION-SET;COBALT18.5",SIMPLE,EPS,T0.01 1 SNA
0.1 BN92-05761L ASSY BOX;E1920NX,LS19CLYSB/XF 1 SNA
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 1 SNA
LABEL BOX-00;ALL MODEL,MOJO
..2 BH68-00651U 1 SNA
90G,90,95,WH
LABEL-STICKER
..2 BN68-02258K 1 SNA
HIC;MODEL7,CHINA,MOJO,80G,
..2 BN69-04812A BOX-01,SET;Cobalt18.5"(SIMPLE),PAPER,SW, 1 SNA
0.1 ACCE1 BN92-05916B ASSY ACCESSORY;LS20CLYSB/XF 1 SNA
..2 EC29 BN39-00244H CBF SIGNAL-D-SUB TO D-SUB;D-sub cable,15 1 SA
ASSY STAND P-BASE;COBALT 17~20,HIPS
..2 SB04A BN96-12816A 1 SA
HB,B
...3 T0524 6902-000109 BAG PE;HDPE,T0.015,W350,L430,TRP,28,2,4. 1 SNA
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 SNA
COVER-STAND BASE;COBALT
...3 BN63-06716A 1 SNA
17~20,HIPS,HB,BK
...3 BN68-02691A MANUAL FLYER-STAND;COBALT,Mojo 80g,148,2 1 SNA
...3 BN68-02822G LABEL-STICKER;W/W,ART PAPER,T0.05,50,10, 1 SNA
RUBBER FOOT;MATISSE,BUMPON,#13.5,T2.0
...3 AR011 BN73-00077A 6 SNA
,60
ASSY STAND
..2 SB01A BN96-12853A 1 SA
P-BODY;COBALT,HIPS,BK23,ETCH
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 SA
...3 T0524 6902-000023 BAG PE;LDPE,T0.08,W150,L120,TRP,1.650g 1 SNA
...3 BN61-06067A STAND-BAR;COBALT 21.5,HIPS,BK23 1 SNA
....4 BN61-06068A STAND-BAR IN;COBALT,HIPS,BK23,IN 1 SNA
...3 BN61-06334A BRACKET-PLATE;COBALT,SECC,1.0,SIMPLE 1 SNA
...3 BN68-02822J LABEL-STICKER;W/W,ART PAPER,T0.05,50,10, 1 SNA
..2 ACCE1 BN96-13553Y ASSY ACCESSORY;LS17CLASB/XF 1 SA
...3 T0268 3903-000455 CBF-POWER CORD;DT,CN,IP3/Y(A),IEC320 C13 1 SA
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
LABEL-PASSING;SAMSUNG ALL,ART
...3 T0527 AA68-00764A 1 SNA
PAPER,CLR,
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
MANUAL-TCO 5.0 CARD;COMM,W/W,Mojo
...3 BN68-01118D 1 SNA
80g,21
MANUAL FLYER-WARRANTY CARD;Chinese,Art
...3 BN68-01789A 1 SNA
1
MANUAL FLYER-CHINA
...3 BN68-02528A 1 SNA
MANUAL;Cobalt,SyncMas
0.1 BN90-02693A ASSY COVER FRONT;E1920,BLACK 1 SNA
..2 F001A BN96-13091A ASSY COVER P-FRONT;Cobalt 18.5W,ABS,HB,B 1 SA
...3 F001 BN63-06843A COVER-FRONT;Cobalt 18.5W,ABS,HB,BK23,SIM 1 SNA
...3 AL093 BN67-00281A LENS-LED;Cobalt Project,PC CLEAR,TP26 1 SNA
LABEL-TCO5.0,ENERGY-
...3 BN68-02382B 1 SNA
STAR;TCO5.0,ENERGY-S
...3 M0007 BN64-01309A KNOB-FUNCTION;Cobalt Project,ABS,BK23 1 SNA
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
ASSY BOARD
...3 FB01A BN96-13682E 1 SA
P-FUNCTION;Cobalt,FUNCTION,20
ASSY PCB FUNCTION-BN96-
....4 BN94-03497D 1 SNA
13682E;COBALT,BN9
.....5 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.814 SNA
.....5 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.003 SNA
.....5 0204-002420 SOLVENT;1M-1000,C3H70H,96 3.47 SNA
.....5 0204-002607 FLUX;DF-234U,13%,14KG,Gravity 0.82 2.259 SNA
.....5 EC13 BN39-01298D LEAD CONNECTOR;Cobalt,UL 1061 #28,UL/CSA 1 SA
.....5 T0174 BN97-04306A ASSY SMD;COBALT, FUNCTION 1 SNA
SOLDER-CREAM;LST309-
......6 0202-001477 0.462 SNA
M,D20~45um,96.5Sn/3A
......6 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 SA
......6 AHR40 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 2 SNA
......6 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 2 SNA
......6 T0313 3404-001379 SWITCH-TACT;12V,50mA,250gf,4.9x4.9x1.5mm 6 SA
HEADER-BOARD TO
......6 HB01A 3711-005743 1 SA
CABLE;BOX,5P,1R,1.25mm,A
......6 BN41-01400B PCB SUB-FUNCTION;Cobalt(all),FR-4,2,1.1, 1 SNA
5-6
1. Precautions
1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
1. For continued safety, do not attempt to modify the circuit board.
2. Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LCD Monitor
1. When servicing the LCD Monitor, Disconnect the AC line cord from the AC outlet.
2. It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of
this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the monitor.
2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
3. Leakage Current Hot Check (Figure 1-1):
WARNING : Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI
C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).
(READING SHOULD)
NOT BE ABOVE 0.5mA
LEAKAGE
DEVICE
CURRENT
UNDER
TESTER
TEST
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
*ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
Figure 1-1. Leakage Current Test Circuit
4. With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit's AC switch
first in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identified by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.
1-1
1. Precautions
1-2. Servicing Precautions
WARNING: An electrolytic capacitor installed with the wrong polarity might explode.
Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1 General Servicing Precautions
1. Always unplug the unit's AC power cord from the AC power source and disconnect the DC Power Jack before
attempting to:
(a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
2. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes
used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to their original position.
3. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels,
input terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON.
Connect an insulation resistance meter (500 V) to theblades of the AC plug.
The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be
greater than 1 megohm.
6. Always connect a test instrument's ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument's ground lead last.
1-3. Static Electricity Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESDs.
4. Use only a grounded-tip soldering iron to solder or desolder ESDs.
5. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate
electrical charges sufficient to damage ESDs.
6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution: Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together,
or lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD.
1-2
1. Precautions
1-4. Installation Precautions
1. For safety reasons, more than two people are required for carrying the product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal
temperature may cause fire.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a fire or electric shock.
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric
shock.
6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the highvoltage cable or the
antenna falling over may cause fire or electric shock.
7. When installing the product, leave enough space (10cm) between the product and the wall for ventilation purposes.
A rise in temperature within the product may cause fire.
1-3
1. Precautions
Memo
1-4
2. Product specifications
2. Product specifications
2-1. Feature & Specifications
Feature
Model E1720NR / E1720NRX E1920N / E1920NX E1920NR / E1920NRX
Brightness(Typical) 250 cd/m2
Response Time(Typical) 5ms
Contrast Ratio(Typical) DC 50000:1
(Typ.500:1)
Viewing Angle
170◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
