samsung_ls-22mehsfj_ls-20mehsfv_206bw_226bw_training_manual


>> Download samsung_ls-22mehsfj_ls-20mehsfv_206bw_226bw_training_manual documenatation <<

Text preview - extract from the document

      3




           206BW / 226BW
          Tr ai ni ng Manual




                 Samsung Electronics
                       VD Div.
                   LCD Monitor R&D
             Contents
1.    Basic Structure
                                     1.    Cable connect
2.    Product Spec
                                     2.    Supported resolution
3.    Product function explanation
                                     3.    M ain Board schematic
4.    OSD Tree
                                     4.    D isassemble diagram
5.    Product structure
                                     5.    D D C input method
6.    Product Chassis assembly
                                     6.    A uto Color Calibration
7.    Block D iagram
                                     7.    M onitor self test
8.    M ain Board Power Tree
                                     8.    Service M ode/  Safe M ode
9.    IP Board Parts
                                     9.    Check point with Board change
10.   IP Board Parts
                                     10.   D ifference of each L V D S Cable
11.   D imming control method
                                     11.   L CD Panel documents
12.   Panel construction
13.   Trouble Shooting
14.   Cable connect
1- 1. 206BW/226BW Basic Structure




                                       Magic Bright
                                       Magic Color
                                       Unified UI/function
                                       Hidden Function Key
1- 2. Back Ground of Develop.                              Product Outline




  Pr of es s i onal Di s pl ay ( Pr of es s i onal Us e)

    Pr of es s i onal Us er
    :
      - CAD/CAM use
      - Professional Graphics / W Design
                                 eb
      - Desktop Publishing (DTP)
        - Medical

  Hom Ent er t ai nm
     e              ent
         Ret ai l Us er
       - Users who want multimedia Contents
       - Gamer who want fast response
2- 1. Product Spec
                                        Key Speci f i cat i on

                 Model              206BW                  /                226BW

               Screen Size                    20"                                 22"

                Resolution                                1680x1050@60Hz

                  Colors                                         16.7M

              Br i ght nes s                                   300cd/ m2



               Cont r as t        1000: 1                                               700: 1

           Supported Resolution                            VGA ~ WSXGA+


           Horizontal Frequency                                30~81kHz


                Sync Type                                 Sep./Comp./SOG

            Vertical Frequency                                  56~75Hz

              Viewing Angle       160o/160o    (CR > 10)                 170o/160o   (CR > 10)
                                                       CR : Contrast Ratio
            Res pons e Ti me                         5m ( whi t e t o bl ack)
                                                       s

            Si gnal I nput                              Anal og / Di gi t al
                                                    ( 15pi n D- s ub / DVI - D)
           Power Consumption                               50 W (Max)
                                                               att
2- 2. Product Spec
                                                  Key Speci f i cat i ons

                      Model                                 206BW                                             226BW
         Set Di mens i on( m ) w/ o s t and
                            m                  476 * 65. 2 * 329 ( W x H x D)               514. 6 * 63. 0 * 353. 0( W x H x D)

          Set Di mens i on( m ) w s t and
                             m                 476 * 219. 3 * 397( W x H x D)              514. 6 * 219. 3 * 421. 7 ( W x H x D)

                     VESA( m )
                            m                              100 x 100                                         100 x 100

               ( kg) ( Net / Gr os s )                      6. 0 / 7. 9                                       6. 5 / 8. 5


                        Ti l t                        - 1o ~ 0o( For war d)                              - 1o ~ 0o( For war d)
                                                     0o ~ 22o( Backwar d)                               0o ~ 22o( Backwar d)

                   Power Suppl y                                                  Power / I nver t er

                   Saf et y Mode                         Up t o WSXGA+                                     Up t o WSXGA+


         Magi c Br i ght I I / Magi c Col or                Suppor t                                          Suppor t



               Em s s i ons St andar d
                 i                                               X                                                X


                    Magi c Tune                 Magic Tune Premium (XP 2000, XP2003)             Magic Tune Premium (XP 2000, XP2003)
                                                       Magic Tune 3.6 ( 98, Me )                        Magic Tune 3.6 ( 98, Me )
2- 2. Comparison with 225BW
                                                             Key Speci f i cat i ons

             Model                           206BW                /                     225BW                           225BW
Set Di mens i on( m ) w/ o s t and
                   m                  476 * 65. 2 * 329 ( W x H x D)       / 514. 6 * 63. 0 * 353. 0( W x H x    504.7 x 65.8 x 335.1 mm
                                                                          D)
 Set Di mens i on( m ) w s t and
                    m                 476 * 219. 3 * 397( W x H x D) / 514. 6 * 219. 3 * 421. 7 ( W x H x        504.7 x 219.8 x 408 mm
                                                                      D)

            VESA( m )
                   m                                                  100 x 100                                        100 x 100

   W ght ( kg) ( Net / Gr os s )
    ei                                                      6. 0 / 7. 9 /   6. 5 / 8. 5                               6.9 K g / 9.2K g


               Ti l t                                          - 1o ~ 0o( For war d)                                -1o ~ 0o(Forward)
                                                              0o ~ 22o( Backwar d)                                 0o ~ 17o(Backward)

          Power Suppl y                                                                    Power / I nver t er

          Saf et y Mode                                           Up t o WSXGA+                                      Up t o WSXGA+


Magi c Br i ght I I / Magi c Col or                                    Suppor t                                         Support



      Em s s i ons St andar d
        i                                                                 X                                               TCO


           Magi c Tune                                   Magic Tune Premium (XP 2000, XP2003)                          Version 3.6
                                                                Magic Tune 3.6 ( 98, Me )
2- 2. Comparison with 225BW
                                              Key Speci f i cat i ons

        Model             206BW                   /                225BW                       225BW
      Screen Size                    20"                                  22"                    22"


       Resolution                                1680x1050@60Hz                           1680x1050@60Hz


         Colors                                         16.7M                                   16.7M

     Br i ght nes s                                   300cd/ m2                               300cd/m2

      Cont r as t        1000: 1                                                700: 1          600:1


  Supported Resolution                                                   VGA ~ WSXGA+


  Horizontal Frequency                                30~81kHz                                30~81kHz


       Sync Type                                 Sep./Comp./SOG                            Sep./Comp./SOG


   Vertical Frequency                                  56~75Hz                                 56~75Hz

     Viewing Angle       160o/160o    (CR > 10)                 170o/160o    (CR > 10)   140o/130o (CR > 10)
                                              CR : Contrast Ratio                         CR : Contrast Ratio

   Res pons e Ti me                         5m ( whi t e t o bl ack)
                                              s                                          8ms(white to black)

   Si gnal I nput                              Anal og / Di gi t al                         Analog / Digital
                                           ( 15pi n D- s ub / DVI - D)                   (15pin D-sub / DVI-D)

  Power Consumption                               50 W (Max)
                                                      att                                   50 Watt (Max)
2- 2. Product Accessory






                                                                         User's Guide,
                                          Warranty Card                  Monitor Driver,
        Quick Setup
                                        (Not available in all            Natural Color,
          Guide
                                             locations)                  MagicTuneTM,
                                                                         MagicRotation
                                                                           software




                                       D-Sub Cable                 Power Cord
2- 2. Product Accessory

              Sold separately




                                DVI Cable




                                            Set-Bracket



                                                                    Screws (4 EA)
- 3. Pr oduct I mage




   1) MENU BUTTON : OSD Menu open / OSD Menu Exit / OSD Menu return
   2) Magic Bright BUTTON: Hot key to the control a Magic brightness
   2) Brightness BUTTON: Hot key to the control a brightness when the OSD not displayed
   3) ENTER / SOURCE BUTTON : source change / select a OSD menu
   4) AUTO BUTTON : auto adjustment button
4. OSD adj us t ment f unct i on

  (1) Picture
      *. Analog / Digital source
              Magic Bright  Custom/Text /Internet /Game/Sports/Movie/Dynamic Contrast
              Custom Contrast / Brightness
               Image Lock  Coarse / Fine / Sharpness / H-position / V-Position
                                      (Inactivity with Digital input)
               Auto Adjustment  Auto Adjustment execution
                                      (Inactivity with Digital input)
  (2) Color : Magic Color  Off : To return an Original mode
                              Demo : Intelligent and off condition displayed as a demo.
                              Full : Color Enhancement with Skin tone
                              Intelligent : Color Enhancement without Skin tone.
              Color Tone  To control the color Temp with 4 steps
                             Cool / Normal / Warm / Custom
              Gamma  3steps Gamma control(Mode1 / Mode2 / Mode3)
              Color Control : Red / Green / Blue
4. OSD adj us t ment f unct i on


  (3) Image : Coarse / Fine / Sharpness / H-Position / V-Position

  (4) OSD : Language  To support 9 languages
             H-Position / V-Position
            Transparency : The degree of transparency of OSD.
            Display Time : 5 sec / 10 sec / 20 sec / 200 sec

  (5) Setup : Auto Source(Auto / Manual)
              Image Reset(No / Yes) (Inactivity in Digital Source)
              Color Reset(No / Yes)
              RTA : on/off ( factory setting is on the RTA function )


  (6) Information : Source information,Frequency, Resolution
4. OSD adj us t ment f unct i on
    * . OSD and ot her f unct i on

      1) OSD Lock : To create a OSD LOCK with pushing the Function menu key for 5 seconds.

                       The Magic bright , Brightness and Contrast can be adjusted in OSD LOCK condition.
                       To push a menu key for 5 seconds in order to remove a Lock .


      2) Fact or y   MODE : To push a menu key for 5 seconds with minimum Brightness / Contrast ,
                              Then can go to factory mode.

                                 Below OSD looking cab be displayed.

                       Service Function
                       Adjust
                       PC Auto Color
                       Option
                       Checksum
                       Panel Information
                       Reset
                       Bus Stop
                       2006/10/14
                       TM-Mendel WW-0714
5. Pr oduct connect i vi t y

                                              1. POW   ER ON/ OFF





                                              Swi t ch :
                                              Us e t hi s but t on
                                              f or t ur n t he
                                              m oni t or on and of f                                    RGB I N por t : Connect t he





                                              2. POW   ER por t :                                       s i gnal cabl e t o t he RGB I N
                                              Power cor d, pl ugs                                       por t on t he back of your
                                              i nt o m oni t or and                                     m oni t or . ( SOURCE: Anal og)
                                              wal l r ecept acl e.







                                                                                                        Kens i ngt on Lock : The





                                          DVI I N por t : Connect t he                                  Kens i ngt on l ock i s a devi ce





                                          DVI Cabl e t ot he DVI I N por t                              us ed t o phys i cal l y f i x t he
                                          on t he back of your                                          s ys t em when us i ng i t i n a
                                                                                                        publ i c pl ace.
                                                                                                        ( The l ocki ng devi ce has t o
                                                                                                        be pur chas ed s epar at el y. )
                                                                                                        For us i ng a l ocki ng devi ce,
                                                                                                        cont act





3- 1. Product function explanation
                                                    Key Specification
            function        Detail function                                    explanation
          Magi c col or              Of f                                      Magic Color Off

                                    Demo                                 For the display in the Shop.
                                                                Left-> Magic Color On, Right-> Magic Color Off

                                    Ful l                              Enhance the R/G/B Color Tone

                               I nt el l i gent             Enhance the R/G/B Color Tone except skin tone color

          Magi c Br i ght         Cus t om                                    Factory condition

                                    Text             For the text user , The brightness Setting condition(100 ~ 160 cd/m2)

                                 I nt er net       For the internet user , The brightness Setting condition(140 ~ 200 cd/m2)

                                    Game          For the internet game user , The brightness Setting condition(225cd/m2  )

                                  Spor t s                 For the sports picture , The brightness Setting condition
                                                                            (180 cd/m2 over, 8000K)

                                   Movi e                  For the movie screen , The brightness Setting condition
                                                                           (200 cd/m2 over, 6500K)

                            Dynam c Cont r as t
                                 i                            For t he movi ng s cr een t o i ncr eas e t he CR


           Col or Tone              Cool                 To change a R/G/B Color, and enhance a blue Tone (9300K)

                                  Nor mal                                    Natural R/G/B Color

                                    W m
                                     ar                   To change a R/G/B Color, and enhance a red Tone (6500K)

                                  Cus t om                          User to change a R/G/B Color Control
3- 3. Magic Color


                    On   Off   Demo
                               M ode




                                       R /G/B 3


3- 4. Magic Color




                    Skin Tone
3- 5. Product function explanation



                                       Key Specification


      function    Detail function                               explanation

       Gam a
          m           Mode 1                 Basic gamma which is support from Panel(Gamma 2.2)


                      Mode 2                     To adjust more brighter via Scaler (Gamma 1.8)


                      Mode 3                     To adjust more darker via Scaler (Gamma 2.5)


       Col or          R/ G/ B      To cont r ol t he each R/ G/ B   Col or and make t he col or bal ance
      Cont r ol
3- 7. Gamma Mode




                   G amma M ode 1 :
                   2.2 Gamma

                   G amma M ode 2 :
                   1.8 G amma

                   G amma M ode 3 :
                   2.5G amma
4. OSD Tree

     (Picture)       (Color)           (Image)         (OSD)          (Set Up)     (Information)   (Magic Bright)

  - Contrast     - Color Tone      - Fine         - Language       - Auto Source   -               - Custom
  - Brightness     .Cool           - Coarse       - Position       - Color Reset   -               - Text
                   .Normal         - Sharpness      .H Position    - Image Reset   -               - Internet
                   .Warm           - H Position     .V Position    - RTA                           - Game
                   .Custom         - V Position   - Transparency                                   - Sport
                 - Color Control                  - Display Time                                   - Movie
                   .Red                                                                            - DCR
                   .Green
                   .Blue
                 - Gamma
                   .Mode1
                   .Mode2
                   .Mode3
                 -MagicColor
                    .off
                    .Demo
                    .Full
                    .Intelligent
5. Product structure

    1. Panel
    2. Main Board
    3. IP BOARD
    4. Function Key
5-1. Signal Connections and Pin Assignments


 1. 15pin D-sub connector




                            2. DVI-D connector
5- 2. Di s pl ay Modes
     Di s pl ay Mode       Hor i zont al    Ver t i cal   Pi xel Cl ock   Sync Pol ar i t y
                       Fr equency ( kHz)   Fr equency         ( MHz)          ( H/ V)
                                               ( Hz)
    I BM, 640 x 480         31. 469          59. 940        26. 175             +/ -
    I BM, 720 x400          31. 469          70. 087        28. 322             -/+
    VESA 640 x480            37. 5             75             31. 5             -/-
    VESA 800 x 600          37. 879          60. 317          40. 0             +/ +
    VESA 800 x 600          46. 875           75. 0           49. 5             +/ +
   VESA 1024 x 768          48. 363          60. 004          65. 0             -/-


   VESA 1024 x 768          60. 023          75. 029        78. 750             +/ +


   VESA 1280 x 1024         63. 981          60. 020        108. 00             +/ +


   VESA 1280 x 1024         79. 976          75. 025         135. 0             +/ +


   SUN 1280 x 1024          81. 129          76. 106        135. 00             -/-


   VESA 1400 x 1050         65. 317          59. 978        121. 75        - / + ( 203B)


   VESA 1680 x 1050         65. 300          60. 000        146. 00        +/ + ( 205BW)
5- 3. Block Diagram(Main Board)
                                                     (PC) DIGITAL
                                        Rx2+ Rx2- Rx1+ Rx2- Rx0+ Rx0- RxC+ RxC-




  A   PC Signal                                                                     LV D S Signal_Even         L
                                                       TMDS
                                                                                                               C
                                                      ADC/                                                     D
                                                  IMAGE SCALER/
                   R
                                                      LVDS
                   G
                   B                              (Gm5822LF)
               HSYNC                                                                                           P
               VSYNC
          (PC)ANALOG
                                                                                   LV D S Signal_Odd
                                                                                                         +5V
                                                                                                               A
                                             24MHZ                                                             N
                                                        SDA     SCL
                                                                                                               E
                                                           C                                                   L
                                                                         FUNCTION PBA


                                                     Flash Memory

                                                                                                   +5V
                                  +5V
                                                                      +3.3V             +1.8V
         IP Board          +14V                      +5V
  B                                                            3.3V_Scaler
                                                                regulator
                                                                                    1.8V_Scaler
                                                                                     regulator
                                  Backlight PWM

                    Backlight Enable
5- 5. Ser vi ce ( Hot key) Funct i on
l i s t ( 1)
 No              Function                                      method
         Service Function
 1    Hidden Service Function      In the Power on, make a bright / Contrast `0
                                   And push the menu key for 5 seconds.
                                   Then It is possible to see left OSD window.



                                   1) Adjust
                                   2) PC Auto color
                                   3) Option
                                   4) Checksum
                                   5) Panel Information
                                   6) Reset
         Adjust                    7) Bus Stop
         PC Auto Color
         Option
         Checksum                  *. 2006/10/15: MCU firmware date
         Panel Information
         Reset                     *. TM-Curie22WW-0714: MCU firmware version information
         Bus Stop
         2006/10/15
         TM-Curie22WW-0714
Ser vi ce ( Hot key) Funct i on
l No s t ( 2)Function
  i                       Met hod
 2   Hidden Service Function (1)   Move via ( -) / (+) key , Select via Enter key .


        Service Function
        Adjust
        PC AutoFunction            1) Auto adjustment
        Service Color
        Option
        Checksum
        Panel Information          2) PC Auto Color :
        Reset
        Bus Stop
                                   3) Option: Spread Step / Spread Span
        2006/10/15
        TM-Curie22WW-0714
                                   4) Checksum: MCU firmware checksum information
        2005/08/20
        TM-BRHMS24WW-0714
Ser vi ce ( Hot key) Funct i on
l No s t ( 3)Function
  i                       Met hod
 3   Hidden Service Function (1)

     *. Panel Information
                                            5) Panel Information :


         Service Function
                                               Monitor On Time : Power On Time
                                               Panel Cycle : Panel On/off time (Power off
         Monitor On Time:            42Hr                      Mode change, DPMS on/off)
         Panel Cycle    :            13
                          Time    Ch. No       Panel : Panel on Time
         Panel:      :    42Hr      165
         Lower Lamp:       42Hr     165
                                               Lower lamp : Lower lamp on time
         Upper Lamp:       42Hr     165        Upper lamp : Upper Lamp on time
         Version : TM-Curie22WW-0714
         Checksum :                         6) Reset: Factory reset

                                            7) Bus Stop: Communication Line ON / OFF
6. Tr oubl es hoot i ng

 Defect check process
                                                                yes

            Power On?            FOS check                      no



           LED off?            No video        Abnormal display




         Power cable        Signal cable        Signal cable,
         Adapter            LVDS harness        LVDS harness
         Function harness   Inverter harness    PCB Ass'y
                            Inverter
                            Panel, pcb
Trouble Shooting

    Check points before repair

      To check a input voltage and cable connect status
       . Power Cable and signal Cable connect status check
       . Function Key check
      Must do after repair
       . Resolution : 1024 x 768/60Hz
       . Auto execution
       . Recovery Factory Mode
         => If push the Menu Button and Enter(Source) Button for 5 seconds at the same time,
             The monitor goes to Factory Mode.
      Other self test items
       . If Lamp works for a few second and no work,
         IP Board/Panel Lamp have a problem.
       . LED doesn't work -> IP Board / Micom/ Function Block problem.
DDC input method
                           1.Install Winddc.exe
                             Program in the PC
                           2. Cilck the Winddc icon.
                           3. File open.
 1                         4. Select Port#1
                           5. Load DDC file
                             File Name
                             -. "SM206BWA.ddc"

               2             -. "SM206BWD.ddc"
                             -. "SM226BWA.ddc"
                             -. "SM226BWD.ddc"

                           6. Click Next(OK) button.


                   3




                       4
DDC input method

                     SM 930BA




           SM 950B


                 5
Auto Color Calibration

    Aut o Col or
     PC analog ( 1024X768@60 ) or signal generator ( MSPG-3240L).




                          PC Analog Adjustment pattern(16 GRAY)

     Push the Menu Key for 5 seconds at OSD Language English
Service Mode/Safe Mode

   Service Mode entry

     Brightness and Contrast value to "O".
     Push the Enter(Source) key for 5 seconds.
     SVC Function OSD displayed.
     In order to escape from SVC Function ,
     Please power off the monitor


   Safe Mode

   If input signal too higher than given product specification,
   The monitor gives to User for 1 minute for Video Card Setting
   and The user can make a resolution to recommend Mode.
   206BW/226BW         : UXGA/60Hz,75Hz supported, Displayed for 1 minute with
                        Down Scaling condition.
                         However, Will be displayed `' Sync Out of Range"
                         If the input vertical frequency is over the 85Hz
           Mai n PCB




                       EEPROM - NV RA M
  scaler




Flash
memory




S-D RA M
Circuit Diagram
Circuit Diagram
Circuit Diagram
Circuit Diagram(IP Board)
   SMPS Par t


                                                               POWER TR ANS FORMER,   DIODE, INDUC TOR ,
     LINE FILTER, X- CAP,                                      FET                    CAPAC ITOR
     Y- CAP
                                                                     Sw ching BLOCK
                                                                       it
      Inpu Filt BLOCK
          t    er                                                                                                               D C /A C
                                                                                                              13V out
                                                                                                                             IN V E R T E R


                                                                                                                                 M A IN
                                                                                                               5V out
                                                                                                                             A /D B O A R D




                            1 5 " 2 L am p : F S D M 0 3 6 5   Contr ol                        Feedback     PHOTOCOUP LER,
                            1 7 " ,1 9 "    : N CP1200         Ci r cui t                      Ci r cui t   TL430
Circuit Diagram(IP Board)
 I nver t er Par t

                                    Swi t chi ng       I nver t er     Back Li ght    Pr ot ect i on
                                     FET_1, 2      Tr ans f or m _1
                                                                 er       Lamp          Bl ock_1
                     I nver t er                                      Connect or _1
      DC-          Cont r ol l er
    (    _14V)      ( OZ960SN)
                                                                       Back Li ght
                                                                                      Pr ot ect i on
                                                                          Lamp
                                                                                        Bl ock_2
                                                                      Connect or _2


  Back Li ght                                                          Back Li ght
     Lam p                                                                            Pr ot ect i on
                                                                          Lamp          Bl ock_3
    ON/ OFF                                                           Connect or _3
    (  )

                                                                       Back Li ght
                                                                                      Pr ot ect i on
                                                                          Lamp
                                                                                        Bl ock_4
                                                                      Connect or _4
 Back Li ght
                 Di m i ng
                     m
    Lamp
                 Cont r ol
                                                   Feed- Back
                  Bl ock
   (  )                                              Bl ock
Circuit Diagram(IP Board)
   SMPS Par t
IP BOARD part(Inverter- Dimming)
  To control the input current in Lamp-> Current Control
  To control the fixed frequency in Lamp-> PWM control
  To control the current and frequency in Lamp-> Complex control.

       Current Control (Analog Dimming)
            -To control the Dimming without the impact to panel.
            - To need a minimum current not to part lighting in Minimum Brightness
            - Low Dimming Ratio ( 2 : 1)
            -The optimum condition of Inverter is Maximum Brightness,
              so the efficiency is low in Dimming condition.


       PWM Control (Burst Dimming)
            - The operate a Lamp via around 300Hz ~ 1kHz frequency .
            - Large current on/off via fixed duty , panel power area ground unstable and noise happen.
              So, there is a Water fall noise
            - Lamp lighting condition is always in Maximum Brightness, The efficiency is high.
              The part lighting in Minimum Brightness solved.
            - High Dimming Ratio (5:1)


       Complex Control
            - To control with Analog method in Front Dimming, so can reduce a noise.
            - To control the PWM method in back Dimming, so increase a Dimming Ratio .
Circuit Diagram(IP Board)

                            I nver t er Par t
* PROTECTION*
   LAMP(Inverter) PROTECION
   => The protection operate in loosed lamp Connector or lamp crack.
   => The lamp protection operate with OVP , If Inverter Trans output voltage high.
   Power Protection
   => All protection (OVP/OCP) of Panel work as a Auto Recovery Mode.
      The power rework again automatically even If the Protection shortly operating.
      However, As an exception, Thermal Protection is working when Power off for
      the discharge and on.
     It is operate by function of internal power IC.
Panel part
Magi c Tune and ot her i nf or m i on
                                at
   No Video / No Power.

      1) Is the power cord to connect to monitor?
         => To connect the power cord to monitor.

      2) Is the Green LED working ?
         => Push the power button .

      3) Is the Green LED toggling ?
         => The monitor goes to DPMS, To touch a mouse or keyboard to escape from the DPMS The other is to change a input
        signal source or rebooting the PC.

      4) The "Check Signal Cable" message display on the front screen?
         =>To connect a signal cable again. To check a input signal status doing push a source select key . Then, The monitor check a
         input signal status automatically.

      5) Is the monitor connect via DVI cable ?
         => If the monitor connect to PC after booting in unconnected DVI cable condition or the DVI cable disconnect from PC and
        connect to PC During the use the PC, The monitor can not be displayed at several video graphic card due to no signal output
        from card. To reboot a PC in DVI cable connected condition.

      6) Is the message "Not Optimum Mode, Recommended Mode 1680 x 1050 60Hz" displayed on the front screen?
         => This message can be seen in case of exceed maximum resolution from graphic card . To reboot a PC in safe mode, and
        change a resolution from graphic card.

      The "LOCKED" message displayed on the OSD front screen. 1) Push the MENU KEY for 5 seconds.
          => When push the MENU KEY for 5seconds , The menu goes to LOCKED condition.
             Then, The Magic Bright and Contrast / Brightness only operated.
             Push the menu key for 5 seconds again to escape from the locked.
Abnormal Color.

  1) The displayed color is only one color ?
   => To connect signal cable again well. To check a graphic card in PC whether the graphic card inserted to PC or not.

  2) The abnormal color happen after operating the new program?
     => To reboot a PC

  3) Is the graphic card setting up well ?
     => 1. Insert CD into the CD-ROM driver.
         2. Click "Start" --> "Control Panel" then click the "Appearance and Themes" icon.
=>3. Click "Display" icon and choose the "Settings" tab then click "Advanced




  =>4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab.
=>5. Click "Update Driver.." and select "Install from a list or.." then click "Next" button.




  =>6. Select "Don't search ,I will.." then click "Next" and then click "Have disk".
=>7. Click the "Browse" button then choose A:(D:\Driver) and choose your monitor model in the model list and click the "Next" button.




  =>8. If you can see following "Message" window, then click the "Continue Anyway" button. Then click "OK" button.
=>9. Click the "Close" button then click "OK" button continually




 =>10. Monitor driver installation is completed.
The screen position moving or changing suddenly.

1) The resolution fits to monitor frequency?
   =>To fit a resolution of monitor's recommended resolution.

2) To push a auto adjustment key. If the monitor capture a first input signal,
  =>The monitor operate a auto adjustment automatically. However, If the screen position move after auto adjustment, To push a auto
    adjustment key.
     (Auto adjustment can operate by auto key of Function or Magic tune)

The screen is not clean.
   1) Is the resolution and frequency fit to monitor?
       => To change a resolution(1680 x 1050 60Hz )
           to recommended resolution via display install information of PC.

   2) Push a Auto adjustment.

   3) Adjust sharpness.

When the monitor connect to PC, The message "To find a Plug & Play (VESA DDC) monitor " display on the screen.

1) The PC read a monitor information which is installed in MS registered information . In order to install right model name of monitor,
  To use given install driver CD.

   If the message displayed "unrecognized monitor " , The condition is that the PC is not read a right information from the monitor.
    => To change a signal cable or graphic card. To connect a SVC center after you did above things If you see same issue.
If the PC read a wrong information from the monitor , This problem can be happened. To reboot a PC.

3) To take a long time to load a Magic tune
   => To take a long time for operating the Magic tune due to communicate. Once, after loading . It will not be taken long time.

Magic tune Premium operating condition and service matter.

    1) Is it possible to use a Magic tune to the other supplier monitor?
       => Magic tune is operating with Samsung monitor only . and The Samsung old monitor which is not support a DDC-CI may not working.

   2) Is it possible to update a Magic tune?
       => You can download a latest software from Samsung Homepage . http://www.sec.co.kr/monitor

   3) To operate a Magic tune whenever the PC on.
      =>The Magic tune is working automatically when PC on.

   4) Is the Dual monitor operating a Magic tune?
      => If the monitor support a DDC-CI (Display data channel-command interface), The Magic tune operated.

   5) Is a Magic tune support all OS ?
      => The Magic tune 3.6 is support from win98SE version to win XP.

   6) To know a Magic tune 3.6 in detail.
      => You can see detail explanation in given CD.
18. Disassemble
    Caution :
        1.Power off the monitor before disassemble.
        2.Please use the given Jig when disassemble the monitor .
        3.Please disassemble follow the below given process.
        4.Jig : BH81-00001A




                                 1.    Put the monitor on the cushion .
                                       Remove the 3 screws from the stand base .


                                 2.    Remove the 3 screw from the bottom of the rear
                                       cabinet.


                                 3.    Open the bottom of the rear cabinet
18. Disassemble


                  4.   Remove the lamp Wire shield .


                  5.   Remove the function wire form the PCB ASS'Y.


                  6.   Remove the Panel Lamp wire


                  7.   Remove the LVDS Wire form the Panel.
18. Disassemble




                  7.   Remove the 4 screws from the Shield
                       cover and Main , IP Board.
                  8.   Remove the 4 screws from PBA
                       ( Main 1 screw, IP Board 3 screws)
                       and then , disassemble the main board
                       and IP board from the bracket.
                  9.   The picture which is completed
                       disassemble.



◦ Jabse Service Manual Search 2026 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
