Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                                   2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                T220HD / T200HD

                                                          Feature

 Supreme Digital Interface & Networking
 - With a built-in HD digital tuner, it supports HD broadcasting with no particular set-top box and provides simple
   access with a single remote control.
 Excellent Picture Quality
 - DNIe technology provides life-like clear images.
 Dynamic Contrast
 - Automatically detects the input visual signal and adjusts to create optimum contrast.
 SRS TruSurround XT
 - SRS TruSurround XT provides a virtual Dolby surround system.
 Convenience
 -The TV utilizes the HDMI system to implement perfect digital sound and picture quality.

                                                       Specifications

                                                                        Description
               Item
                                                  T220HD                                       T200HD
LCD Panel                        TFT-LCD Panel, RGB Vertical strip,           TFT-LCD Panel, RGB Vertical strip,
                                 normaly White, 22-Inch viewable,             normaly White, 20.1-Inch viewable,
                                 0.282(H) X 0.282(V)mm Pixel Pitch            0.258(H) X 0.258(V)mm Pixel Pitch
Scanning Frequency               Horizontal : 30KHz ~ 81KHz(Automatic)        Horizontal :30KHz ~ 81KHz(Automatic)
                                 Vertical: 56Hz ~ 75Hz(Automatic)             Vertical:56Hz ~ 75Hz(Automatic)
Display Colors                   16.7 Million colors                          16.7Million colors
Maximum resolution               Horizontal: 1680pixels                       Horizontal : 1680pixels
                                 Vertical: 1050pixels                         Vertical:1050pixels
Input Signal                     Analog 0.7Vp-p
