Image preview - the first page of the document
>> Download bn44-00505a_pslf560501a+sanken+psu+info documenatation <<
Text preview - extract from the document
Off-Line PWM Controllers with Integrated Power MOSFET
STR-W6000S Series
General Descriptions Package
The STR-W6000S series are power ICs for switching
power supplies, incorporating a MOSFET and a current TO220F-6L
mode PWM controller IC.
The low standby power is accomplished by the
automatic switching between the PWM operation in
normal operation and the burst-oscillation under light
load conditions. The product achieves high
cost-performance power supply systems with few
external components.
Features
Current Mode Type PWM Control Not to Scale
Brown-In and Brown-Out function
Auto Standby Function Lineup
No Load Power Consumption < 30 mW Electrical Characteristics
Operation Mode fOSC(AVG) = 67 kHz
Normal Operation ----------------------------- PWM Mode
Standby ---------------------------- Burst Oscillation Mode VDSS RDS(ON)
Products
Random Switching Function (min.) (max.)
Slope Compensation Function STR-W6051S 3.95
Leading Edge Blanking Function STR-W6052S 650 V 2.8
Bias Assist Function STR-W6053S 1.9
Audible Noise Suppression function during Standby STR-W6072S 800 V 3.6
mode
Protections Output Power, POUT*
Overcurrent Protection (OCP); Pulse-by-Pulse, POUT (Open frame)
built-in compensation circuit to minimize OCP point Products
variation on AC input voltage AC230V AC85~265V
Overload Protection (OLP); auto-restart STR-W6051S 45 W 30 W
Overvoltage Protection (OVP); auto-restart STR-W6052S 60 W 40 W
Thermal Shutdown Protection (TSD); auto-restart STR-W6053S 90 W 60 W
STR-W6072S 50 W 32 W
* The output power is actual continues power that is measured at
