Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LS24KIERBQ/EDC Exploded View
M0003
M0013
M0014
M0215
M0006
M0215
T0764
M0146
T0056
M0112
T0175
T0003
M0175
M0130
5-1
5. Exploded View & Part List
5-1-1. LS24KIERBQ/EDC Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
T0003 BN96-06451B ASSY COVER P-FRONT;LS24KI,ABS,HB,BK26,BL 1 S.A
M0112 BN63-04038B COVER-FRONT;LS24KI,ABS,HB,BK26,BLK SPRAY 1 S.N.A
M0130 BN67-00210A LENS LED;KILIMANZARO 26",PC CLEAR 1 S.N.A
M0175 BN96-06651B ASSY BOARD P-TOUCH FUNCTION;Kilimanzaro, 1 S.A
T0056 BN63-04039B COVER-DECORATION;LS24KIE,ABS,HB,NATURE,S 1 S.N.A
T0175 BN96-06426A ASSY SPEAKER P;8ohm,kilimanzaro,2W,4p,1w 1 S.A
M0215 BN07-00399A LCD-PANEL;LTM240CT01 1 S.A
T0764 BN44-00195A SMPS-LCD MONITOR;245B2,DYREL,AC-DC,85.67 1 S.A
M0146 BN63-04051A SHIELD-PCB SMPS;2493HM,SPTE,T0.3 1 S.N.A
M0014 BN94-01549A ASSY PCB MAIN;LS24KIEEFV/XAA,2493HM 1 S.A
M0006 BN96-06454A ASSY SHIELD P-COVER;Kilimanzaro 24,SECC, 1 S.N.A
M0215 BN44-00136B INVERTER;245B,GH253A,60khz,24V,3.0mA,7.0 1 S.A
M0013 BN96-06452D ASSY COVER P-REAR;LS24KI,HIPS,HB,BK26 1 S.A
M0003 BN96-06600C ASSY STAND P;2493HM,ABS HB,BK26_SPRAY,US 1 S.A
5-2
5. Exploded View & Part List
5-2. LS24KIERBQ/EDC Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
LS24KIERBQ/
2493HM,WUJ1/S24A0-LKI,24,LCD-MO,NETHERLA
EDC
0.1 M0001 BN90-01425B ASSY COVER FRONT;LS24KI,BLK SPRAY 1 S.N.A
..2 T0003 BN96-06451B ASSY COVER P-FRONT;LS24KI,ABS,HB,BK26,BL 1 S.A
...3 M0081 6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT), 4 S.N.A
...3 T0069 AA60-00091F SPACER-FELT;-,FELT,150X10,-,-,BLK,T0.5,- 4 S.N.A
...3 T0069 AA60-00091M SPACER-FELT;-,FELT,35X10,-,-,BLK,T0.5,-, 2 S.N.A
...3 T0069 AA60-00171G SPACER-FELT;43L2,FELT,505,T0.5,10 2 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0112 BN63-04038B COVER-FRONT;LS24KI,ABS,HB,BK26,BLK SPRAY 1 S.N.A
...3 T0056 BN63-04039B COVER-DECORATION;LS24KIE,ABS,HB,NATURE,S 1 S.N.A
...3 M0130 BN67-00210A LENS LED;KILIMANZARO 26",PC CLEAR 1 S.N.A
...3 T0175 BN96-06426A ASSY SPEAKER P;8ohm,kilimanzaro,2W,4p,1w 1 S.A
...3 M0175 BN96-06651B ASSY BOARD P-TOUCH FUNCTION;Kilimanzaro, 1 S.A
....4 M2893 BN39-01007B LEAD CONNECTOR;Kilimanjaro,UL1571#30,5 t 1 S.A
....4 M0145 BN96-06651A ASSY BOARD P-FUNCTION;Kilimanzaro,CT5000 1 S.A
0.1 M0002 BN90-01426A ASSY COVER REAR;LS24KI 1 S.N.A
..2 M0013 BN96-06452D ASSY COVER P-REAR;LS24KI,HIPS,HB,BK26 1 S.A
...3 M0131 AA63-01252A GASKET;FIRENZE,Conductive Fabric,15mm,3m 1 S.N.A
...3 T0069 AA63-60131A SPACER-FELT;SVP403J,FELT,-,-,-,BLK,T0.5, 5 S.N.A
...3 M0006 BN63-04040A COVER-REAR;2493HM,HIPS,HB,BK26 1 S.N.A
0.1 M0216 BN90-01427E ASSY STAND;LS24KI,USB STAND,BLK SPRAY 1 S.N.A
..2 M0003 BN96-06600C ASSY STAND P;2493HM,ABS HB,BK26_SPRAY,US 1 S.A
...3 T0081 6001-001547 SCREW-MACHINE;BH,+,M4,L10(5),ZPC(BLK),SW 4 S.A
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 11 S.A
...3 M0081 6003-001238 SCREW-TAPTITE;FH,+,S,M4,L8,ZPC(BLK),SWRC 4 S.N.A
...3 M0963 BN61-00251A FOOT;GH17BS,RUBBER,T1.6 4 S.N.A
...3 CIS4 BN61-01438A HOLDER-STAND;MATISSE HAS-STAND,SWRCH18A 1 S.N.A
...3 BN61-02634A GUIDE-STAND RETAINER;HUBBLE,ACETALl,T2.0 2 S.N.A
...3 BN61-02919A GUIDE-STAND LIFT;HUBBLE24",ACETAL,2.8 1 S.N.A
...3 BN61-02921A BRACKET-STAND BODY;HUBBLE24",SECC,2.0,OU 1 S.N.A
...3 BN61-02922A BRACKET-STAND LIFT;HUBBLE24",SECC,2.0,IN 1 S.N.A
...3 BN61-03588A GUIDE-STAND BODY;KILIMANZARO 26",ALDC 1 S.N.A
...3 BN61-03589A GUIDE-STAND BOTTOM;2693HM,SECC,T2.0 1 S.N.A
...3 CCM1 BN63-02183K COVER-SHEET;Rhcm,PE Vinyl,T 0.05,250MM,2 0.4 S.N.A
...3 CCM1 BN63-02183L COVER-SHEET;Rhcm,PE Vinyl,T 0.05,300MM,2 0.3 S.N.A
...3 BN63-03257B COVER-STAND VESA;HUBBLE27",HIPS,2.8,-,-, 1 S.N.A
...3 BN63-04011A COVER-STAND FRONT;KILIMANZARO 26",HIPS,H 1 S.N.A
...3 T0004 BN63-04013B COVER-STAND BASE;KILIMANZARO 26",HIPS,HB 1 S.N.A
...3 T0003 BN63-04014A COVER-STAND BOTTOM;KILIMANZARO 26",HIPS, 1 S.N.A
...3 BN63-04015A COVER-STAND LIFT REAR;KILIMANZARO 26",HI 1 S.N.A
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
...3 BN63-04016A COVER-STAND LIFT FRONT;KILIMANZARO 26",H 1 S.N.A
...3 M0412 BN63-04017A COVER-SWIVEL BASE;KILIMANZARO 26",ACETAL 1 S.N.A
...3 BN63-04018A COVER-STAND HINGE;KILIMANZARO 26",HIPS,H 1 S.N.A
...3 BN63-04019B COVER-STAND USB;KILIMANZARO 26",ABS,HB,B 1 S.N.A
...3 T0081 BN73-00085A RUBBER CUSHION;MATISSE,-,##4.5(IN SIDE), 1 S.N.A
...3 M0007 BN96-01524D ASSY STAND P-STOPPER;2693HM,SUS 1 S.N.A
...3 M0126 BN96-05211A ASSY STAND P-SPRING;-,HUBBLE 24",-,SUS,W 2 S.N.A
...3 T0054 BN96-06458B ASSY HINGE P;2493HM,SECC T2.0 1 S.N.A
...3 M0852 BN96-06638A ASSY USB P;LS26KIEEFV/XAA,65X35 1 S.A
....4 0406-001217 DIODE-TVS;NUP4301MR6,6/-/-V,500W,TSOP-6 2 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001957 FET-SILICON;NTR2101P,P,-8V,-3.7A,0.052oh 1 S.A
....4 T0596 0904-002329 IC-USC;USB2514,QFN,36P,6.55x6.55mm,58.6K 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 P803T 1404-001223 THERMISTOR-PTC;45mohm,20,6V,-,40A,4A,TP 1 S.A
....4 X202 2801-003326 CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH 1 S.A
0.1 M0106 BN91-01017X ASSY LCD-STZ;LS24HUBCBQ/EDC 1 S.N.A
..2 M0215 BN07-00399A LCD-PANEL;LTM240CT01 1 S.A
0.1 M0017 BN91-01886A ASSY CHASSIS;LS24KIEEFV/XAA 1 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 T0268 BN39-00796C CBF-POWER CABLE;Kilimanjaro,UL1007#26,16 1 S.A
..2 M2893 BN39-00799A LEAD CONNECTOR-LVDS;LS27HUB(HUBBLE 27"), 1 S.A
..2 T0764 BN44-00195A SMPS-LCD MONITOR;245B2,DYREL,AC-DC,85.67 1 S.A
..2 M0146 BN63-04051A SHIELD-PCB SMPS;2493HM,SPTE,T0.3 1 S.N.A
..2 M0014 BN94-01549A ASSY PCB MAIN;LS24KIEEFV/XAA,2493HM 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.025 S.N.A
...3 CN102 3701-001173 CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN101 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN703 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004068 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,ANGL 1 S.A
...3 CN330 3711-005955 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,ANG 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 CN500 3722-002081 JACK-EAR PHONE;5P/2C,-,SnPb,L-BLU,- 1 S.A
...3 T0510 BN97-01874A ASSY SMD-MAIN;LS24KIEEFV/XAA 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/ 1.556 S.N.A
....4 D105 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D106 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D107 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D108 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D109 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D110 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D111 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D112 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D129 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D130 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D121 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D122 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D123 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D124 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D125 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D126 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D127 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D128 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D523 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D732 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D733 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D734 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D113 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D114 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD110 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD111 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD500 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D118 0403-000579 DIODE-ZENER;BZX84C5V1,4.8-5.4V,200mW,SOT 1 S.A
....4 D115 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 D133 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
....4 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
....4 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
....4 D504 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D505 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D511 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D512 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D522 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q502 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q507 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q100 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q103 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q196 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q300 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q301 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q302 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q310 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q505 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q600 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q701 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-002169 FET-SILICON;Si4435BDY-T1-E3,P,-30V,-9.1A 1 S.N.A
....4 IC106 1001-001496 IC-VIDEO SWITCH;PI3HDMI1210ABEX,HDMI/DVI 1 S.A
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
....4 IC112 1103-001410 IC-EEPROM;S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 1 S.A
....4 T0085 1201-001980 IC-AUDIO AMP;TDA7266D,SO,20P,16X11.1MM,- 1 S.A
....4 IC205 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 S.A
....4 IC304 1203-001824 IC-VOL. DETECTOR;7042,SOT-89,3P,-,PLASTI 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 IC150 1203-004618 IC-SWITCH REG.;MP3213DH,MSOP,8P,3x3mm,PL 1 S.A
....4 IC109 1205-003371 IC-LCD CONTROLLER;MST97889CLD-LF,LQFP,25 1 S.A
....4 R110 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000103 R-CHIP;120Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000683 R-CHIP;3.3Kohm,1%,1/10W,TP,1608 1 S.A
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000729 R-CHIP;300ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000979 R-CHIP;5.6Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 RA301 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA302 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA303 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA304 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA305 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA306 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA307 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 RA400 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
....4 RA401 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
....4 RA402 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
....4 RA403 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
....4 RA404 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
....4 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
....4 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,1608 1 S.A
....4 C120 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,1608 1 S.A
....4 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C120 2203-001222 C-CER,CHIP;0.82nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-001222 C-CER,CHIP;0.82nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,1608 1 S.A
....4 C120 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C120 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,3216 1 S.A
....4 C120 2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C120 2203-006170 C-CER,CHIP;220nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-006170 C-CER,CHIP;220nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-006337 C-CER,CHIP;4700nF,20%,25V,X5R,TP,3225 1 S.A
....4 C621 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C649 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C558 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 U2547 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
....4 C367 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
....4 C560 2402-001218 C-AL,SMD;22UF,20%,35V,WT,TP,6.6X6.6X5.8M 1 S.A
....4 C373 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
....4 C365 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C366 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C540 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C542 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C543 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
....4 C3045 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
....4 C602 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
....4 C650 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
....4 C619 2402-001273 C-AL,SMD;220uF,20%,35V,WT,REEL,10X10mm 1 S.A
....4 T0052 2703-001334 INDUCTOR-SMD;1.5uH,10%,2012 1 S.A
....4 T0052 2703-001334 INDUCTOR-SMD;1.5uH,10%,2012 1 S.A
....4 T0052 2703-001334 INDUCTOR-SMD;1.5uH,10%,2012 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-001778 INDUCTOR-SMD;3.3uH,20%,3225 1 S.A
....4 T0052 2703-002916 INDUCTOR-SMD;10uH,20%,8080 1 S.A
....4 X202 2801-003667 CRYSTAL-SMD;14.31818MHz,30ppm,28-AAN,16p 1 S.A
....4 F103 2901-001302 FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m 1 S.A
....4 F103 2901-001302 FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m 1 S.A
....4 F103 2901-001302 FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m 1 S.A
....4 F103 2901-001302 FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m 1 S.A
....4 G101 3301-000316 CORE-FERRITE BEAD;120ohm,2012,TP,-,- 1 S.N.A
....4 G101 3301-000316 CORE-FERRITE BEAD;120ohm,2012,TP,-,- 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001793 BEAD-SMD;18ohm,1608,-,TP,11.8ohm/37.6MHz 1 S.A
....4 T0568 3301-001793 BEAD-SMD;18ohm,1608,-,TP,11.8ohm/37.6MHz 1 S.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
....4 T0568 3301-001793 BEAD-SMD;18ohm,1608,-,TP,11.8ohm/37.6MHz 1 S.A
....4 F601 3601-001382 FUSE;125V,3A,SLOW BLOW,CERAMIC,6.1x2.69x 1 S.N.A
....4 CN330 3711-005470 HEADER-BOARD TO CABLE;BOX,30P,1R,1.25mm, 1 S.A
....4 CN330 3711-005743 HEADER-BOARD TO CABLE;BOX,5P,1R,1.25mm,A 1 S.A
....4 L701 BN27-00002A COIL-CHOKE(SMD);47uH,47uH,20%,12*12*8mm, 1 S.A
....4 T0010 BN27-00009A COIL CHOKE;SMD 12x12x6,EOS,33uH,15%,-,0. 1 S.A
....4 T0010 BN27-00009A COIL CHOKE;SMD 12x12x6,EOS,33uH,15%,-,0. 1 S.A
....4 S301 BN32-00005A SENSOR SW-TILT;SPSF100100,DC5V,1mA,-10 ~ 1 S.A
....4 T0077 BN41-00962A PCB MAIN;LS26KIE,FR-4,4,MP1.0,1.6T,153x1 1 S.N.A
....4 R110 2007-000803 R-CHIP;36Kohm,1%,1/10W,TP,1608 1 S.A
....4 MAIN BN97-01959A ASSY MICOM-MAIN;M-KI24E0CAA-1003.0,(CD5B 1 S.N.A
.....5 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8Bi 1 S.N.A
....4 T0085 1201-002487 IC-AUDIO AMP;MAX9728A,QFN,12P,3x3mm,DUAL 1 S.A
....4 R110 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 S.A
....4 C400 2402-001314 C-AL,SMD;100uF,20%,16V,WT,-,6x5.8mm 1 S.A
....4 C550 2402-001314 C-AL,SMD;100uF,20%,16V,WT,-,6x5.8mm 1 S.A
....4 C605 2402-001314 C-AL,SMD;100uF,20%,16V,WT,-,6x5.8mm 1 S.A
....4 D701 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
....4 Q409 0505-001957 FET-SILICON;NTR2101P,P,-8V,-3.7A,0.052oh 1 S.A
....4 R110 2007-000099 R-CHIP;62Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000099 R-CHIP;62Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000211 R-CHIP;1.1Kohm,5%,1/10W,TP,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
....4 R110 2007-000287 R-CHIP;100ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000287 R-CHIP;100ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000287 R-CHIP;100ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000946 R-CHIP;47ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000946 R-CHIP;47ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000946 R-CHIP;47ohm,1%,1/10W,TP,1608 1 S.A
....4 IC301 1105-001838 IC-DDR SDRAM;EM6A9160TS0A-5G,DDR SDRAM,1 1 S.A
...3 T0066 BP62-00047A HEAT SINK-ES;DLP,A6063S,T2.5,13,13,TAPE 1 S.N.A
...3 HDCP BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
..2 M0006 BN96-06454A ASSY SHIELD P-COVER;Kilimanzaro 24,SECC, 1 S.N.A
...3 BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L 4 S.N.A
...3 BN61-02429F STUD-PEM;PNB,M2.8,D7,L28,ZPC(SIL),SUM24L 2 S.N.A
...3 BN61-02431B STUD-PEM;PND,-,M4,D8,L8,ZPC(SIL),SUM24L 4 S.N.A
...3 BN61-03726A GUIDE-PANEL;2493HM,SECC,T0.8 1 S.N.A
...3 M0107 BN63-04041A SHIELD-COVER;KILIMANZARO 24",SECC,T0.8 1 S.N.A
...3 T0102 BN73-00138A RUBBER-CAP;HUBBLE,ELASTOMER,60,V2 2 S.N.A
...3 M0131 BN63-03886A GASKET;LS24HUC,Polyester+Cu+Ni+Hotmelt,1 2 S.N.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Q'ty
...3 M0131 BN63-03888A GASKET;LS24HUC,Polyester+Cu+Ni+Hotmelt,1 1 S.N.A
...3 M0131 BN63-03890A GASKET;LS24HUC,Polyester+Cu+Ni+Hotmelt,1 1 S.N.A
...3 M0131 BN63-04069A GASKET;LS24HUC,Polyester+Cu+Ni+Hotmelt,1 1 S.N.A
...3 M0131 BH63-00104A GASKET;POSEIDON,CONDUCTIVE FABRIC,2MM,10 1 S.N.A
..2 M2893 BN39-00597A LEAD CONNECTOR;PO24FS,UL1061#28,14P,60mm 1 S.A
..2 M2893 BN39-00797B LEAD CONNECTOR;LS26KIE,UL1007#26,5 pin,1 1 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 3 S.A
..2 M0215 BN44-00136B INVERTER;245B,GH253A,60khz,24V,3.0mA,7.0 1 S.A
..2 M0131 BN63-04529A GASKET;Kilimanjaro,Polyester+Cu+Ni+Hotme 1 S.N.A
0.1 M0112 BN91-01907A ASSY SHIELD;LS24KI 1 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
..2 BN63-03849A GASKET-TCO SHIELD;HUBBLE,Conductive AL F 1 S.N.A
0.1 M0045 BN92-03018E ASSY ACCESSORY;LS24KIERBQ/EDC 1 S.N.A
..2 M0125 BN39-00246K CBF SIGNAL-DVI(D);DVI-Cable,24P/24P,2027 1 S.A
..2 T0128 BN39-00061C CBF SIGNAL-STEREO;Mckinley,1,male,1.5m,B 1 S.A
..2 T0725 BN39-00397C CBF INTERFACE-USB;SPL-07,4P/4P,2725(USB2 1 S.A
..2 M0254 BN96-06445E ASSY ACCESSORY-CABLE&MANUAL;LS24KIERBQ/E 1 S.A
...3 BH68-70448A CARD-01;TFT LCD,SRC,RUSSIA,S/W,120,W210* 1 S.N.A
...3 T0268 3903-000042 CBF-POWER CORD;DT,EU,FP3/YES,IEC320 C13/ 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 T0076 BH68-00633B MANUAL FLYER-02,WARRANTY CARD;comm,Samsu 1 S.N.A
...3 BN68-00907A MANUAL FLYER-01,CARD;COMM,SAMSUNG,18 LAN 1 S.N.A
...3 BN68-01118B MANUAL-02,TCO03 CARD;COMM,W/W,Mojo 100g, 1 S.N.A
...3 M0215 BN96-06501A ASSY MANUAL P-IB+QSG;comm,SyncMaster,W/W 1 S.N.A
....4 CCM1 BN59-00660A S/W DRIVER-02,IB;comm,W/W,SyncMaster 1 S.N.A
....4 BN68-01387A MANUAL FLYER-QSG;comm,SyncMaster,30Lang, 1 S.N.A
..2 M0114 BN39-00244G CBF SIGNAL;D-sub cable,15P/15P,20276N,15 1 S.A
0.1 M0113 BN92-03019A ASSY P/MATERIAL;LS24KIEEFV/XAA 1 S.N.A
..2 T0376 6902-000001 BAG AIR;LDPE,T0.2,L1800,W1000,TRP,,,LDPE 0.004 S.N.A
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.018 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 2.81 S.N.A
..2 M0081 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,-,- 0.052 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.59 S.N.A
..2 T0524 6902-000737 BAG PE;HDPE/HDPE/NITRON,T0.015/T0.015/T1 1 S.N.A
0.1 M0003 BN92-03020E ASSY BOX;LS24KIERBQ/EDC 1 S.N.A
..2 BN69-02141A BOX-SET;LS24KE,CB,A1,SW,W641,D508,H274,1 1.02 S.N.A
0.1 M0019 BN92-03021D ASSY LABEL;LS24KIEEFV/EDC 1 S.N.A
5-15
5. Exploded View & Part List
Memo
5-16
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
