Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                                2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                      2493HM

                                                         Feature

 Support PC / DVI / HDMI
 5ms, DC 10000:1 Applied
 2W*2 Speaker
 TCO'03
 USB (1 up, 2 down) optional
 HDCP Applied for HDMI/DVI-D
 Fixed Aspect Ratio Support
 Supported camera effects: Black/Sepia/Green/Blue
 Off-Timer function for reducing standby power usages

                                                     Specifications

               Item                                                     Description

LCD Panel                         TFT-LCD panel, RGB vertical stripe, normally black transmissive,
                                  24 Inch viewable, 0.270(H) x 0.270(W) mm pixel pitch
Scanning Frequency                Horizontal: 30 kHz ~ 81 kHz (Automatic)
                                  Vertical: 56 Hz ~ 75 Hz
Maximum Resolution                Horizontal: 1920 Pixels
                                  Vertical: 1200 Pxels
Input Signal                      PC/DVI/HDMI

Input Sync Signal                 Seperate H/V sync, Composite:
                                  automatic synchronization without external switch
                                  Level : TTL level (V high  2.0V, V low  0.8V)
Maximum Pixel Clock Rate          164 MHz

Active Display
                                  518.4(H) x 324.0(V) mm
Horizontal/Vertical
AC Power Voltage & Frequency      AC 90~264V Volts, 60/50Hz

Power Consumption                 Less than 100W

Dimensions                        565.0 x 447.5 x 250.0 mm ( W X H X D) (With Stand)
                                  565.0 x 389.0 x 81.0 mm ( W X H X D) (Without Stand)
Weight                            Products: 8.5 kg

Environmental                     Operating Temperature: 10
