                                                      6. Wiring Diagram

6. Wiring Diagram
6-1. Wiring Diagram - Main Board




              CN400        CN600
                                      CN601




                                              CN702



      CN703                   CN101
                  CN102




                                                                  6-1
6. Wiring Diagram

6-2. Wiring Diagram (Main)




                                     CN702
                             CN703




6-2
                             6. Wiring Diagram

6-3. Wiring Diagram (SMPS)




                                         6-3
6. Wiring Diagram

6-4. Wiring Diagram (PANEL)




6-4
                                                                                           6. Wiring Diagram

6-5. Connector Functions
  Connector Name                                         Function Description
                    VGA Signal Input Port.
      CN101
                    *Symptom: No RGB Signal.
                    DVI Signal Input Port.
      CN102
                    *Symptom: No DVI Signal
                    HDMI Signal Input Port
      CN703
                    *Symptom: No HDMI Signal.
      CN702         Function Key Terminal.
      CN400         It delivers the LVDS signal from the Main Board to the Panel.
                     It provides 5V and 18V power from the SMPS to the Main Board
      CN600
                    *Symptom: No Power.
                    It provides PWM output from the Main Board to the SMPS
      CN601
                    *Symptom: No Power or Blank Screen
                    Audio Input Port
      CN500
                    *Symptom: No Audio Output
                    Audio Output Port
      CN501
                    *Symptom: No Audio Output for the Connected External Device

6-6. Cables
  Use              Power Cable                   Power Control Cable                LVDS Cable

  Code             BN39-00796C                      BN39-00797B                     BN39-00799A








                                                                                                       6-5
6. Wiring Diagram

Memo




6-6
