Image preview - the first page of the document
>> Download 510MP_ET-SB-EX-SI_1251363473 documenatation <<
Text preview - extract from the document
TFT-LCD MONITOR
Chassis Model
MH15AS Syncmaster 510MP
MH17AS Syncmaster 710MP
SERVICE Manual
TFT-LCD MONITOR CONTENTS
1. Precautions
2. Product Specifications
3. Disassembly & Reassembly
4. Alignment & Adjustments
5. Troubleshooting
6. Exploded View & Parts List
7. Electrical Parts List
8. Block Diagram
9. Wiring Diagram
10. PCB Layout
11. Schematic Diagrams
12. Panel Description
This Service Manual is a property of Samsung Samsung Electronics Co.,Ltd.
Electronics Co., Ltd. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea, 442-742.
Any unauthorized use of Manual can be punished Printed in Korea
under applicable International and/or domestic law. P/N : BN82-00107F-00
URL : http://itself.sec.samsung.co.kr/
4 Alignments and Adjustments
4-1 General Alignment Instuction
1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation.
Check the basic characteristics such as height, horizontal and vertical sync.
2. Use the specified test equipment or its equivalent.
3. Correct impedance matching is essential.
4. Avoid overload. Excessive signal from a sweep generator might overload the front-end of the TV.
When inserting signal markers, do not allow the marker generator to distort test result.
5. Connect the TV only to an DC power source with voltage and frequency as specified on
the backcover nameplate.
6. Do not attempt to connect or disconnect any wire while the TV is turned on.
Make sure that the power cord is disconnected before replacing any parts.
7. To protect aganist shock hazard, use an isolation transform.
MH15AS/MH17AS 4-1
4 Alignments and Adjustments
Memo
4-2 MH15AS/MH17AS
8 Block Diagram
This Document can not be used without Samsung's authorization.
8-1 MH15AS
IF-Tuner
IF-Tuner
74VHC4066
S/W
MH15AS/MH17AS 8-1
8 Block Diagrams
8-2 MH17AS
IF-Tuner
IF-Tuner
74VHC4066
S/W
8-2 MH15AS/MH17AS
3 Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the
MH15AS/MH17AS monitor.
WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling
these components.
3-1 Disassembly
Cautions : 1. Disconnect the monitor from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
3. R/Cover opening jig : BH81-00001A
1. Place monitor face down on cushioned table.
Remove 4 screws from grip on the stand and
insert the opening drive into the grooves at
each side and press until it clicks.
2. Remove back cover from the monitor and
remove 2 screws from the main shield.
3. Remove 2 screws from the shield and
disconnect scart cable. Lift up the start cable
from the shield.
4. Disconnect speaker cable and function cable
from the shield PCB and remove shield PCB.
Disconnect inverter cables, LVDS cable from
the MAIN board.
MH15AS/MH17AS 3-1
3 Disassembly and Reassembly
5. Remove 7 screws from the MAIN board and
remove 7 screws from the cover front.
(MH15NS : Remove 6 screws from the MAIN
board and remove 6 screws from the cover
front.)
6. Remove the cover front and remove 4 screws
from the panel.
7. Remove shield from the panel.
3-2 Replacement Order of Lamp Assemblies
1. After confirm there is nothing on the desk,
turn the LCD module over and put it on a flat
desk set to the ground.
2. Remove 2 screws for the lamp unit.
3-2 MH15AS/MH17AS
3 Disassembly and Reassembly
Slide the lamp unit 3. Slide the lamp unit. Please take out the lamp
units from the LCD module.
Slide the lamp unit
4. Please fix the new lamp units on the LCD
module : opposite process 2 and 3.
3-3 Reassembly
Reassembly procedures are in the reverse order of disassembly procedures.
MH15AS/MH17AS 3-3
3 Disassembly and Reassembly
Memo
3-4 MH15AS/MH17AS
6 Exploded View and Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 MH15AS
MH15AS/MH17AS 6-1
6 Exploded View & Parts List
6-2 MH17AS
6-2 MH15AS/MH17AS
7 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
7-1-1 MH15AS Main PCB Parts
Level Loc. No. Code No. Description Specification Remarks
0 MH15ASSS/EDC
1 RH-MH15ASSS/EDC - 3 TM150XG-26L10(ZPD) -
3 BN94-00512B - ASSY PCB MAIN RH RJ MH15AS SA
4 2409-001043 C134 C-ORGANIC 47UF,20%,6.3V,WT,TP,6.3X6.8,2.5 SA
4 2409-001043 C457 C-ORGANIC 47UF,20%,6.3V,WT,TP,6.3X6.8,2.5 SA
4 BN39-00491A CIS6 LEAD CONNECTOR-YC MH15/17AS,UL2547#26,UL/CSA,2P,70mm,#26,SMH200-02,SMH200-02,BK,SJ03-01-572 SA
4 3701-001219 CN100 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF SA
4 3711-004712 CN101 CONNECTOR-HEADER BOX,9P,1R,2mm,STRAIGHT,SN SA
4 3711-005505 CN300 CONNECTOR-HEADER NOWALL,11P,1R,2.54mm,ANGLE,SN,WHT SA
4 3722-002081 CN301 JACK-EARPHONE 5P/2C,-,SnPb,L-BLU,- SA
4 3711-003942 CN305 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN SNA
4 3711-003942 CN306 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN SNA
4 2904-001070 FT303 FILTER-SAWAV 38.9MHz,SIP5K,TP,14.6dB,B/G,42dB SA
4 2904-001225 FT308 FILTER-SAWAV 38.9MHz,SIP5K,ST,15.7dB,L/L',35dB SA
4 2903-001240 FT309 FILTER-CERAMIC TR,5.5MHz,-,28dB,-,TP,- SA
4 2903-001246 FT310 FILTER-CERAMIC TR,5.5MHz,-,-,-,TP,multi.frequency SA
4 3704-001061 IC300_SOCK SOCKET-IC 64P,DIP,SN,1.778mm SA
4 AB29-00002A IC302 FILTER-ICCOMB -,TDA9181,-,-,ST,SMP-160,-,- SA
4 1204-001833 IC304 IC-VOLUMECONTROL TDA7496L,DIP,20P,-,PLASTIC,26V,6W,0TO+70C,ST,AMP&VOLUMECONTROL SA
4 1204-001583 IC402 IC-IFCIRCUIT U4468B,DIP,16P,-,PLASTIC,5V,50MW,-20TO+75C,ST,- SA
4 2701-000169 L307 INDUCTOR-AXIAL 3.9uH,10%,2534 SA
4 2701-000157 L310 INDUCTOR-AXIAL 220uH,5%,2534 SA
4 2701-000157 L311 INDUCTOR-AXIAL 220uH,5%,2534 SA
4 2701-000157 L317 INDUCTOR-AXIAL 220uH,5%,2534 SA
4 2701-000210 L318 INDUCTOR-AXIAL 680uH,10%,3070 SA
4 AA40-00076A TUNER TUNER TECC0949PG35A(S),PAL,181CH,38.9MHZ,75OHM,75OHM,DIN,ASYMM,5V,TR,-10TO+60 SA
4 BN41-00398A TUNER_PCB PCBSUB-TUNER MH15AS,FR1,1,1.6,147*166,manetpal,14,tuner SNA
4 BN97-00251E - ASSY SMD-SN MH15AS SNA
5 3301-001163 BD200 BEAD-SMD -,80,-,300,TP,-,0.08 SA
5 3301-001163 BD201 BEAD-SMD -,80,-,300,TP,-,0.08 SA
5 2203-005005 C100 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C101 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C102 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C106 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C107 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C108 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000257 C109 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-005437 C110 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-000815 C111 C-CER,CHIP 0.033NF,5%,50V,C0G,TP,1608 SA
5 2203-001607 C112 C-CER,CHIP 0.22nF,5%,50V,NP0,TP,1608 SA
5 2203-000972 C113 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
5 2203-000972 C114 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
5 2203-000972 C115 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
5 2203-000552 C119 C-CER,CHIP 0.02NF,5%,50V,C0G,TP,1608 SA
5 2203-000552 C120 C-CER,CHIP 0.02NF,5%,50V,C0G,TP,1608 SA
5 2203-000552 C121 C-CER,CHIP 0.02NF,5%,50V,C0G,TP,1608 SA
5 2203-000972 C122 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
MH15AS/MH17AS 7-1
7ElectricalPartsList
Level Loc. No. CodeNo. Description Specification Remarks
5 2203-000972 C123 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
5 2203-000972 C124 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 SA
5 2203-001607 C125 C-CER,CHIP 0.22nF,5%,50V,NP0,TP,1608 SA
5 2203-000815 C126 C-CER,CHIP 0.033NF,5%,50V,C0G,TP,1608 SA
5 2203-001652 C128 C-CER,CHIP 470nF,+80-20%,16V,Y5V,TP,1608 SA
5 2203-001652 C129 C-CER,CHIP 470nF,+80-20%,16V,Y5V,TP,1608 SA
5 2203-001652 C130 C-CER,CHIP 470nF,+80-20%,16V,Y5V,TP,1608 SA
5 2203-005005 C131 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C132 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2402-000209 C133 C-AL,SMD 22uF,20%,16V,WT,TP,5.3x5.3mm,1 SA
5 2203-005065 C135 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 SA
5 2203-005005 C136 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C138 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005065 C140 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 SA
5 2203-005065 C141 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 SA
5 2203-000189 C170 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000257 C173 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-005005 C200 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C201 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C202 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C203 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000626 C204 C-CER,CHIP 0.022NF,5%,50V,C0G,TP,1608 SA
5 2203-000626 C205 C-CER,CHIP 0.022NF,5%,50V,C0G,TP,1608 SA
5 2203-000626 C206 C-CER,CHIP 0.022NF,5%,50V,C0G,TP,1608 SA
5 2203-000626 C207 C-CER,CHIP 0.022NF,5%,50V,C0G,TP,1608 SA
5 2203-005005 C208 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C209 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C210 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C211 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C212 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C213 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C214 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C215 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C216 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C217 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C218 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C219 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C220 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C221 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005437 C222 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C223 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C224 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C225 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C226 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C227 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C228 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C229 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C230 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000189 C231 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000189 C232 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000189 C233 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000189 C234 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2402-000179 C235 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 SA
5 2203-000189 C236 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000998 C237 C-CER,CHIP 0.047NF,5%,50V,C0G,TP,1608 SA
5 2203-000998 C238 C-CER,CHIP 0.047NF,5%,50V,C0G,TP,1608 SA
7-2 MH15AS/MH17AS
7ElectricalPartsList
Level Loc. No. Code No. Description Specification Remarks
5 2203-000189 C239 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-000440 C278 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608,- SA
5 2203-000440 C279 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608,- SA
5 2203-005005 C301 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-001652 C302 C-CER,CHIP 470nF,+80-20%,16V,Y5V,TP,1608 SA
5 2203-005005 C303 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-001402 C304 C-CER,CHIP 220nF,+80-20%,16V,Y5V,TP,1608 SA
5 2203-005005 C305 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001128 C306 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM SA
5 2203-005005 C307 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001230 C308 C-AL,SMD 2.2uF,◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
