5. Exploded View & Part List
5. Exploded View & Part List
5-1. SIMPLE STAND Exploded View (LS19MYNKBBA/ZC)
M0013
M0027
M0003
M0006
M0014
M0174
M0215
T0514
BN63-03965A
T0003
5-1
5. Exploded View & Part List
5-1-1. LS19MYNKBBA/ZC Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
M0003 BN96-06388A ASSY STAND P;-,943BW,-,SECC T2.0,-,- 1 SA
M0006 BN96-06381C ASSY SHIELD P-COVER;LS19MYW,SECC T0.8,AU 1 SNA
M0013 BN96-06380C ASSY COVER P-REAR;LS19MYW,,HIPS,HB,BK23, 1 SC
M0027 BN96-06384A ASSY STAND P-BASE;-,943BW,-,HIPS HB,BK28 1 SA
M0174 BN44-00121X IP BOARD;PWI1904SS(A),Mc19"W(4Lamp),0.7~ 1 SA
M0215 BN07-00440A LCD-PANEL;M190PW01 V0,AU19021,6bit Hi-FR 1 SA
T0003 BN96-06382S ASSY COVER P-FRONT;943NWPLUS,ABS,HB,BK23 1 SA
T0514 BN61-03557A BRACKET-SUPPORT;2043BW/NW[Mckinley],SPTE 1 SNA
BN63-03965A SHIELD-LAMP;943BW/NW,SPTE,T0.3,(Wide) 1 SNA
5-2
5. Exploded View & Part List
5-2. LS19MYNKBBA/ZC Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
ASSY COVER FRONT;943NWPLUS,BLACK_
0.1 BN90-01417S 1 SNA
TCO03
ASSY COVER
..2 T0003 BN96-06382S 1 SA
P-FRONT;943NWPLUS,ABS,HB,BK23
COVER-FRONT;943NWPLUS,ABS,HB,BK23,50
...3 M0112 BN63-03984K 1 SNA
000:
...3 M0130 BN67-00209A LENS LED;Mckinley,PC CLEAR,TP15(TP-1020) 1 SNA
LABEL-TCO,ENERGY;TCO03,ENERGY,W/
...3 T0527 BN68-01173C 1 SNA
W,PET,T0
...3 M0020 BN96-09158B ASSY BOARD P;Mckinley,Function Assy,With 1 SA
ASSY PCB FUNCTION;ASSY FUNCTION
....4 P0055 BN94-03205C 1 SNA
PCB,BN96
.....5 M2893 BN39-01007A LEAD CONNECTOR;Mckinley,UL1571#30,5 to 5 1 SA
.....5 BN61-03552A GUIDE-CONTROL;2043BW/NW,ABS HB,GR70 1 SNA
TAPE-FUNCTION TAPE;DOUBLE FACE
.....5 BN74-00022A 0.01 SNA
TAPE,Poly
TAPE-FUNCTION TAPE;DOUBLE FACE
.....5 BN74-00023A 1 SNA
TAPE,Poly
.....5 T0174 BN97-02776Q ASSY SMD;MCKINLEY 1 SNA
......6 L0405 0601-002461 LED;SMD,InGaN Blue,1.6X3.2X1.1mm,468nm,1 1 SA
......6 AD480 2203-006399 C-CER,CHIP;1000nF,10%,6.3V,X5R,1005 1 SA
CONNECTOR-HEADER;BOX,5P,1R,1mm,SMD-
......6 CN906 3711-006471 1 SA
A,AU,
......6 BN41-00947D PCB SUB-FUNCTION;Mckinley function,FR-4, 1 SNA
......6 AVR73 2007-000142 R-CHIP;2.7Kohm,5%,1/16W,TP,1005 2 SNA
......6 MR39 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 2 SNA
......6 1209-001890 IC-SENSOR;CT1N07,MLF,24P,4x4mm,PLASTIC,5 1 SA
......6 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 SNA
ASSY COVER
0.1 M0002 BN90-01418C 1 SNA
REAR;LS19MYN,SIMPLE,ANALOG,AU
ASSY COVER
..2 M0013 BN96-06380C 1 SC
P-REAR;LS19MYW,,HIPS,HB,BK23,
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 SNA
...3 M0006 BN63-03940A COVER-REAR SUB;2043BW/NW,HIPS,HB,BK23 1 SNA
COVER-REAR;943BW/NW,HIPS,HB,BK23,BOE/
...3 M0006 BN63-03982C 1 SNA
AUO
RUBBER-PANEL;943BW/
...3 BN73-00162A 6 SNA
NW,RUBBER,BLACK,(Wide
RUBBER-
...3 M0126 BN73-00170A 3 SNA
FOOT;943BW,2043BW,RUBBER,8*8,1.5,
0.1 BN91-01803B ASSY LCD-ATZ;LS19PEN* 1 SNA
..2 M0215 BN07-00440A LCD-PANEL;M190PW01 V0,AU19021,6bit Hi-FR 1 SA
0.1 BN91-01877A ASSY SHIELD;MCKINLEY 19,LS19MYW 1 SNA
..2 BN63-03965A SHIELD-LAMP;943BW/NW,SPTE,T0.3,(Wide) 1 SNA
..2 CIS1 BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915, 0.12 SNA
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
0.1 M0017 BN91-04249C ASSY CHASSIS;943NWPLUS 1 SNA
SCREW-TAPTYPE;PWH,+,-
..2 M0081 6003-000264 3 SA
,B,M3,L6,ZPC(WHT),S
SCREW-TAPTYPE;BH,+,S,M4,L8,ZPC(WHT),S
..2 M0081 6003-001439 1 SNA
WRC
..2 M0174 BN44-00121X IP BOARD;PWI1904SS(A),Mc19"W(4Lamp),0.7~ 1 SA
BRACKET-SUPPORT;2043BW/
..2 T0514 BN61-03557A 1 SNA
NW[Mckinley],SPTE
..2 M0014 BN94-03001A ASSY PCB MAIN;943NWPLUS 1 SA
...3 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.558 SNA
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.003 SNA
...3 0204-002420 SOLVENT;1M-1000,C3H70H,96 3.47 SNA
...3 0204-002607 FLUX;DF-234U,13%,14KG,Gravity 0.82 2.259 SNA
CONNECTOR-
...3 3701-001219 1 SA
DSUB;15P,3R,FEMALE,ANGLE,AUF
HEADER-BOARD TO
...3 3711-004261 1 SA
BOARD;BOX,12P,1R,2mm,ANG
...3 T0174 BN97-03561Z ASSY SMD;943NWPLUS,BN94-03001A 1 SNA
SOLDER-CREAM;LST309-
....4 0202-001477 0.795 SNA
M,D20~45um,96.5Sn/3A
DIODE-SWITCHING;MMBD4148SE,100V,200m
....4 0401-001056 3 SA
A,SO
....4 MZD1 0403-001411 DIODE-ZENER;5.49-5.73V,200mW,SOD-323,TP 9 SA
....4 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 SA
TR-SMALL SIGNAL;KTC3875S-
....4 Q101 0501-000445 4 SA
Y,NPN,150mW,SOT
TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-
....4 PQ02 0501-002080 2 SA
59
....4 Q409 0505-001165 FET-SILICON;SI3443BDV,P,-20V,+-4.4A,65mo 1 SA
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 SA
....4 IC112 1103-001410 IC-EEPROM;S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 1 SA
....4 T0087 1203-003695 IC-POSI.FIXED REG.;NCP1117ST33T3G,SOT-22 1 SA
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 SA
IC-LCD CONTROLLER;SE717M-
....4 IC109 1205-003364 1 SA
LF,PQFP,128P,20
....4 KAR21 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 4 SNA
....4 CER02 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 2 SNA
....4 AR30 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 17 SA
....4 FMR4 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 2 SNA
....4 FAR22 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 2 SNA
....4 AVR51 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 2 SNA
....4 CER04 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 4 SA
....4 R227 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 SA
....4 MROP1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 20 SA
....4 ARR2 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 SNA
....4 MR112 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 2 SA
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 HR13 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 2 SNA
....4 WR15B 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 2 SA
....4 ZR10 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 3 SNA
....4 R1 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608 6 SNA
....4 C258 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 3 SA
....4 C134 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 2 SA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 SNA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 3 SNA
....4 AAC14 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608 6 SA
....4 DC108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 40 SC
....4 C100 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 3 SNA
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 19 SC
CRYSTAL-SMD;14.31818MHz,30ppm,28-
....4 X202 2801-003667 1 SA
AAN,16p
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 3 SNA
CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-
....4 AC510 3708-001150 1 SA
A,SN,Y
....4 T0077 BN41-01172A PCB MAIN;Lavender,CEM-3,2layer,1.0,1.6T, 1 SNA
ASSY MICOM;MCKINLEY,943NWPLUS,ATZ,LM
....4 M0018 BN97-03565S 1 SNA
Y19N
IC-FLASH
.....5 IC115 1107-001614 1 SNA
MEMORY;MX25L1005,1Mbit,1Mx1,SOP
..2 M0251 BN96-02854N ASSY CABLE P;Fininfarina,FLAT CABLE,-,15 1 SA
ASSY SHIELD P-COVER;LS19MYW,SECC
..2 M0006 BN96-06381C 1 SNA
T0.8,AU
...3 BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L 1 SNA
BRACKET-SUPPORT
...3 BN61-03573C 1 SNA
STAND;LS19MYW,SECC,T1.6,
SHIELD-COVER;LS19MYW,SECC,T0.8,AUO
...3 M0107 BN63-03962B 1 SNA
Panel
...3 T0073 AA63-01141C GASKET-EMI;42D5,Conductive Fabric,1.5mm, 4 SNA
...3 T0060 BN61-03594A SPRING ETC-STAND;Mckinley,SUS304,T0.3,SI 1 SNA
...3 T0139 6502-000135 CABLE CLAMP;DAWS-2NA,ID10,NTR,NYLON66 1 SC
0.1 BN92-02621Z ASSY P/MATERIAL;LS19MYWKBA/XSF* 1 SNA
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 1.3 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 T0524 6902-000241 BAG PE;HDPE/NITRON,T0.5/T0.012,W600,L600 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 0.79 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
LABEL-SUMMARY;G52,G72,ART,100G,WHT,BL
..2 T0527 BH68-40364A 1 SNA
K,W
PACKING INNER-00,PAD;COMM,CB-
..2 BH69-40383M 1 SNA
SW4,1000,80
..2 T0527 BN68-00129A LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP 1 SNA
..2 BN69-00391P PAD-ANGLE;T4,50,2200,YEL,56g 1 SNA
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
..2 BN69-02088A CUSHION-01,SET;943BW,EPS,M50(Simple), Wi 1 SNA
..2 BH69-00457A PACKING INNER-00,PAD;COMM,T3.0,1130,1180 1 SNA
PALLET-PACKING;KR17LO,WOOD-
..2 BH69-00403A 1 SNA
WoodEN,1070,1
0.1 BN92-03163X ASSY LABEL;2243BW-KBQ/KOR 1 SNA
..2 M0412 BN68-01571A LABEL RATING-01;ALL,SS,PE,T0.05,90,50,Da 1 SNA
..2 BN68-00354A LABEL-01,CAUTION;22A1,T/P,60,18,HIGH VOL 1 SNA
0.1 BN92-05336X ASSY BOX;LS19MYNKBBA/ZC 1 SNA
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 1 SNA
LABEL BOX-00;ALL MODEL,MOJO
..2 BH68-00651K 1 SNA
90G,90,95,WH
..2 BN69-03866E BOX-SET;943BWX-Simple,CB,A1,W500,D355,H1 2 SNA
0.1 M0045 BN92-05421B ASSY ACCESSORY;LS19MYNKBBA/ZC 1 SNA
..2 M0114 BN39-00244G CBF SIGNAL;D-sub cable,15P/15P,20276N,15 1 SA
..2 M0027 BN96-06384A ASSY STAND P-BASE;-,943BW,-,HIPS HB,BK28 1 SA
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 SNA
COVER-STAND
...3 BN63-03998A 1 SNA
BASE;LS19MYK,HIPS,HB,BK26,SM
ASSY HOLDER P-WIRE;MCKINLEY,ABS
...3 T0010 BN96-06529A 1 SNA
HB,BK23
....4 6902-000336 BAG ZIPPER;LDPE,T0.05,W70,L80,TRP,0.500g 1 SNA
....4 M0114 BN61-03555A HOLDER-WIRE;MCKINLEY,ABS HB,BK26 1 SNA
...3 T0527 BN68-01529A LABEL-STICKER;T,W/W,ART PAPER,T0.05,50,1 1 SNA
RUBBER FOOT;MATISSE,BUMPON,#13.5,T2.0
...3 AR011 BN73-00077A 4 SNA
,60
..2 M0003 BN96-06388A ASSY STAND P;-,943BW,-,SECC T2.0,-,- 1 SA
COVER-STAND
...3 M0111 BN63-03985A 1 SNA
FRONT;LS19MYW,HIPS,HB,BK23,S
COVER-STAND
...3 M0111 BN63-03992A 1 SNA
REAR;LS19MYW,HIPS,HB,BK26,Si
...3 T0054 BN96-06383A ASSY HINGE P-SIMPLE;943BW,SPCC, HGI,T2.0 1 SNA
...3 T0524 6902-000675 BAG PE;LDPE,T0.05,W200,L250,PINK,28,3 PE 1 SNA
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 SA
...3 T0527 BN68-01529A LABEL-STICKER;T,W/W,ART PAPER,T0.05,50,1 1 SNA
..2 M0045 BN96-11662W ASSY ACCESSORY;LS20MYZRBQA/ZC 1 SA
CBF-POWER CORD;DT,US,EP3,IEC320
...3 T0268 3903-000466 1 SA
C13,125/
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
MARK RECYCLE-CARD WARRANTY-
...3 BH68-00261F 1 SNA
05;SyncMaster
MARK RECYCLE-03,WARRANTY CARD;SECA
...3 BH68-00344C 1 SNA
W'TY
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
MANUAL-02,TCO03 CARD;COMM,W/W,Mojo
...3 BN68-01118B 1 SNA
100g,
ASSY MANUAL
...3 BN96-11899A 1 SNA
P-IB+QSG;MCKINLEY,MCKINLEY,S
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 BN59-00950A S/W DRIVER-04,IB;comm,sync master,w/w,MC 1 SNA
....4 BN68-01377A MANUAL FLYER-03,QSG;2043BW,SyncMaster,W/ 1 SNA
5-7
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
