Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                                2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  943NW / 943NWX

                                                         Feature

 Panel Specifications: 300 cd/m2, 5 ms, CR 1000:1, 170/160 (CR>10)
 DPMS : <1W
 TCO'03
 Off-Timer function for reducing standby power usages
 Windows Vista authentication
 Picture;a screen size desire
 Supported Color Effect: Black and white/Sepia/Aqua/Green

                                                     Specifications

                    Item                                                    Description
LCD Panel                                   TFT-LCD panel, RGB vertical stripe, normally white transmissive,
                                            19" wide Viewable 0.258(H) mm x 0.258(V) mm pixel pitch
Scanning Frequency                          Horizontal : 30 kHz ~ 81 kHz (Automatic)
                                            Vertical: 56 Hz ~ 75 Hz(WSXGA+ : 60Hz)
Display Colors                              16.7 Million colors
Maximum resolution                          Horizontal: 1440 Pixels
                                            Vertical: 900 Pixels
Input Signal                                Analog
Input Sync Signal                           Seperate H/V sync, Composite H/V, Sync-on-Green
                                            Level: TTL level
Maximum Pixel Clock rate                    137 Mhz
Active Display
                                            408.24(H) x 255.15(V)
(Horizontal/Vertical)
AC power voltage & Frequency                AC 110V~130V, 60Hz & AC, 200V~240V 50Hz
Power Consumption                           38 W (Max)
Dimensions Set                              439 x 68.4 x 290 mm [Without Stand]
(W x D x H)             SIMPLE STAND
                                            439 x 185 x 368 mm [With Stand]
                                            439 x 65.5 x 290 mm [Without Stand]
                        HAS STAND
                                            439 x 190 x 357.3mm [With Stand]
Weight                  SIMPLE STAND        Set : 3.5 kg [Without Stand], 3.8 kg [With Stand]
(Set/Package)                               Package : 5.1 Kg
                        HAS STAND           Set : 3.5 kg [Without Stand], 5.0 kg [With Stand]
                                            Package : 6.55 Kg
Environmental Considerations                Operating Temperature: 10
