Image preview - the first page of the document
Samsung_Atlantis_DLP_Training_Manual_[TM]


>> Download Samsung_Atlantis_DLP_Training_Manual_[TM] documenatation <<

Text preview - extract from the document
  DLP Training
(Atlantis Chassis)
   March 2004
      Agenda
1.    Power Supply
2.    Digital Board
3.    Analog Board
4.    DMD Board
5.    Troubleshooting
6.    Initialization Process
7.    LED Indicators
8.    Optical Section
9.    Service Hints
10.   Parts Information
11.   Dimensions
12.   Review
                           Power Supply Board
                           CN803
 Pin #     1       2        3        4        5       6     7
 Spec     5V      GND      33VB     GND      Power   N.C.   N.C
          A                                  -S/W
 Used          Supplies DC voltage to the PCB ANALOG




                           CN802
Pin #      1           2        3        4     5      6      7    CN 803
Spec     Power     S14.      S-      S14.      S-    5.7    GN
         -Mute     5VB      GND      5VB      GND    VB     D
Pin #      8           9     10      11        12     13
Spec     12VB      GND      12V      GND      70V    GND
                             B                 B
                                                                  CN 802
Used           Supplies DC voltage to the PCB ANALOG
                          Digital Board
