Samsung_FPT5084_Fast_Track_[TM]


>> Download Samsung_FPT5084_Fast_Track_[TM] documenatation <<

Text preview - extract from the document
    FPT5084X/XAA                           Fast Track Troubleshooting Manual
                                                                      No Service Bulletins




Hot Item:                            Firmware version: 1022
 Repeated failure of SMPS or 12amp      Resolves HDMI video flicker
fuse on SMPS.
 Replace Y main when replacing
SMPS where the 12amp fuse is open.
FPT5084X/XAA   Fast Track Troubleshooting Manual
     FPT5084X/XAA                                  Fast Track Troubleshooting Manual
Support Sheet

  To do list:
    Option bytes should always be verified before and after the repair.
    Quick links listed below for training, triage and Help.


  Option Byte setting




 Training
   Plus One
     http://my.plus1solutions.net/clientPortals/samsung/

 Help
  GSPN
    http://service.samsungportal.com/EP/web/portal/jsp/EP_Default1.jsp
