Image preview - the first page of the document



>> Download Samsung_LN-S3292D_LN-S4092D_LN-S4692D_Operation Instruction & Installation_[SM] documenatation <<

Text preview - extract from the document

                                                                              10 Operating Instructions and Installation



10 Operating Instructions and Installation
10-1 Front




- The product color and shape may vary depending on the model.


1. SOURCE                                                        5. SPEAKERS
     Toggles between all the available input sources
     (TV, AV1, AV2, S-Video1, S-Video2, Component, PC,           6. REMOTE CONTROL SENSOR
     HDMI1, HDMI2).                                                   Aim the remote control towards this spot on the TV.
     In the on-screen menu, use this button as you would
     use the ENTER       button on the remote control.           7.      (POWER)
                                                                      Press to turn the TV on and off.
2. MENU                                                               POWER INDICATOR
     Press to see an on-screen menu of your TV's features.            Blinks and turns off when the power is on and lights
                                                                      up in stand-by mode.
3.
     Press to decrease or increase the volume.
     In the on-screen menu, use the            buttons as
     you would use the      and   buttons on the remote
     control.


4.
     Press to change channels.
     In the on-screen menu, use the           buttons
     as you use the   and     buttons on the remote
     control.



                                                                                                                       10-1
10 Operating Instructions and Installation

10-2 Connection Panel




1. AV IN 1                                                8. COMPONENT IN
   Video and audio inputs for external devices, such as      Connect component video/audio.
   a camcorder or VCR.
   S-VIDEO IN 1                                           9. KENSINGTON LOCK
   Connect an S-Video signal from a camcorder or VCR.        The Kensington lock (optional) is a device used to
                                                             physically fix the system when used in a public
2. AUDIO OUT (L/R)                                           place.
   Connect to the audio input jacks on your Amplifier/       If you want to use a locking device, contact the deal
   Home theater.                                             er where you purchased the TV.
                                                             - The place of the Kensington Lock may be different
3. DIGITAL AUDIO OUT (OPTICAL)                                  depending on its model.
   Connect to a Digital Audio component.
                                                          10. POWER INPUT
4. SERVICE 1/SERVICE 2                                        Connect the supplied power cord.
   Connector for service only.

5. HDMI/DVI IN 1/2, DVI IN (AUDIO L/R)
   Connect to the HDMI jack of a device with an HDMI
   output.
   Use the HDMI/DVI terminal for DVI connection to an
   external device. You should use the DVI to HDMI
   cable or DVI-HDMI adapter (DVI to HDMI) for the
   connection, and the DVI IN 'R -AUDIO -L' terminal
   for audio.
   - HDMI/DVI IN terminal does not support PC.
   - No sound connection is needed for an HDMI to
     HDMI connection.

6. ANT 1 IN/ANT 2 IN
   Connect to an antenna or cable TV system.

7. PC IN
   Connect to the video and audio output jacks on your
   PC.



10-2
                                                                           10 Operating Instructions and Installation

10-2-1 Side Panel Jacks

- Use the left side panel jacks to connect a component that is used only occasionally, such as a camcorder or
  video game.


                                                           1. AV IN 2
                                                                Video and audio inputs for external devices.

                                                                S-VIDEO IN 2
                                                                Video inputs for external devices with an S-Video
                                                                output.



                                                           2.      HEADPHONE
                                                                Connect a set of external headphones for private lis
                                                                tening.




                                                                                                                10-3
10 Operating Instructions and Installation

10-3 Remote Control




- This is a special remote control for the visually impaired, and has Braille points on the Power, Channel and Volume buttons.


10-4
10 Operating Instructions and Installation




                                     10-5
10 Operating Instructions and Installation

Memo




10-6
