Image preview - the first page of the document
![Samsung_LN-S3292D_LN-S4092D_LN-S4692D_Exploded View & Part List_[SM]](/pics/5c26d7631a0d7.gif)
>> Download Samsung_LN-S3292D_LN-S4092D_LN-S4692D_Exploded View & Part List_[SM] documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LN-S3292D Exploded View
M0452 T0279
T0175
M0014
T0447
M0215 M0013
T0159
T0175
T0023
T0003
T0175
M0013
5-1
5 Exploded View & Parts List
5-2 LN-S3292D Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03941A ASSY COVER P-FRONT;MILANO-3,32UO,ABS,HB, 1 S.A
T0023 BN96-03425A ASSY COVER P-KNOB POWER;MILANO-3,46UO,AB 1 S.N.A
T0175 BN96-02190A ASSY SPEAKER P;8ohm,Left,10W,Milano 32/4 1 S.A
T0175 BN96-02191A ASSY SPEAKER P;8ohm,Right,10W,Milano 32/ 1 S.A
M0215 BN07-00324A LCD-PANEL;T315XW02(V3),8bit,760.0*450.0* 1 S.A
T0447 BN96-03942A ASSY BRACKET P-PANEL;MILANO-3,32UO 1 S.N.A
M0014 BN94-01037A ASSY PCB MAIN;LNR3292DX/XAA 1 S.A
T0159 BN96-03775A ASSY PCB P-SMPS;FreeVoltage SMPS,LA32R71 1 S.A
T0175 BN96-03987A ASSY SHIELD P-PCB MAIN;MILANO-3,32,SECC, 1 S.N.A
M0452 BN96-02438A ASSY COVER P-HOLDER AV;MILANO,32,57UO,AB 1 S.A
T0279 BN63-02544A COVER-JACK;MILANO3 46,HIPS,V0,GR503 1 S.N.A
M0013 BN96-02205A ASSY COVER P-REAR;MILANO,32,HIPS,V0,GR50 1 S.A
M0013 BN96-02840B ASSY STAND P-BASE;32 MILANO-2,SWIVEL,ABS 1 S.A
5-2
5 Exploded View & Parts List
5-3 LN-S4092D Exploded View
T0279
M0452
T0603
M0014 M0013
M0146
T0120
T0175
M0146
M0215
T0175
M0013
T0003
5-3
5 Exploded View & Parts List
5-4 LN-S4092D Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03424A ASSY COVER P-FRONT;MILANO-3,40UO,ABS,HB, 1 SA
T0175 BN96-02190B ASSY SPEAKER P;8ohm,Left,10W,Milano 40 1 SA
T0175 BN96-02191B ASSY SPEAKER P;8ohm,Right,10W,Milano 40 1 SA
M0215 BN07-00245A LCD-PANEL;LTA400WS-LH1,8bit,952*551*51.0 1 SA
M0146 BN61-01503A BRACKET-PANEL TOP;40" ROME,SECC,T1.2 1 SNA
T0120 BN94-00622E ASSY PCB POWER;ROME,40",AC110V,USA,JAPAN 1 SA
M0014 BN94-00963A ASSY PCB MAIN-SPZ;LNS4092WX/XAA,AM LCD 1 SA
M0146 BN63-01649A SHIELD-PCB SMPS;40" ROME,SECC,T0.5 1 SNA
T0603 BN63-02542A SHIELD-PCB MAIN;MILANO3 40,SECC,T0.5 1 SNA
M0452 BN96-02447A ASSY COVER P-HOLDER AV;MILANO,40,46UO,AB 1 SNA
T0279 BN63-02544A COVER-JACK;MILANO3 46,HIPS,V0,GR503 1 SNA
M0013 BN96-02348C ASSY COVER P-REAR;MILANO,40,HIPS,V0,GR50 1 SA
M0013 BN96-02841B ASSY STAND P-BASE;40 MILANO-2,SWIVEL,ABS 1 SA
5-4
5 Exploded View & Parts List
5-5 LN-S4692D Exploded View
T0279
M0452
M0013
M0014
M0146
M0112
T0120
T0175
M0215
T0175
M0013
T0003
5-5
5 Exploded View & Parts List
5-6 LN-S4692D Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03424A ASSY COVER P-FRONT;MILANO-3,40UO,ABS,HB, 1 SA
T0175 BN96-02190B ASSY SPEAKER P;8ohm,Left,10W,Milano 40 1 SA
T0175 BN96-02191B ASSY SPEAKER P;8ohm,Right,10W,Milano 40 1 SA
M0215 BN07-00245A LCD-PANEL;LTA400WS-LH1,8bit,952*551*51.0 1 SA
M0146 BN61-01503A BRACKET-PANEL TOP;40" ROME,SECC,T1.2 1 SNA
T0120 BN94-00622E ASSY PCB POWER;ROME,40",AC110V,USA,JAPAN 1 SA
M0014 BN94-00963A ASSY PCB MAIN-SPZ;LNS4092WX/XAA,AM LCD 1 SA
M0112 BN96-03429A ASSY SHIELD P-PCB;MILANO-3.40UO,SECC,T0. 1 SNA
M0452 BN96-02447A ASSY COVER P-HOLDER AV;MILANO,40,46UO,AB 1 SNA
T0279 BN63-02544A COVER-JACK;MILANO3 46,HIPS,V0,GR503 1 SNA
M0013 BN96-02348C ASSY COVER P-REAR;MILANO,40,HIPS,V0,GR50 1 SA
M0013 BN96-02841B ASSY STAND P-BASE;40 MILANO-2,SWIVEL,ABS 1 SA
5-6
