Image preview - the first page of the document
![Samsung_LN-S3292D_LN-S4092D_LN-S4692D_Electrical Part List_[SM]](/pics/5c26d76700e77.gif)
>> Download Samsung_LN-S3292D_LN-S4092D_LN-S4692D_Electrical Part List_[SM] documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LNS3292D Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LNS3292DX/XAA LN-S3292D,E62A/32M50-GMO,32,LCD-TV,UNITE
0.1 M0216 BN90-00828B ASSY STAND;32,MILANO-2,SWIVEL,ABS,HB,BK0 1 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
..2 M0013 BN96-02840B ASSY STAND P-BASE;32 MILANO-2,SWIVEL,ABS 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 6 S.A
...3 BN61-02149A HOLDER-SWIVEL RING;32 MILANO,ACETAL(AL), 1 S.N.A
...3 BN61-02151A HOLDER-SWIVEL RING;32 MILANO,ACETAL(AL), 1 S.N.A
...3 BN61-02154A BRACKET GUIDE;32 MILANO,SECC,T1.6,SUB 1 S.N.A
...3 BN61-02156A BRACKET-STAND BOTTOM;32 MILANO,SECC,T2.0 1 S.N.A
...3 BN61-02157A GUIDE-STAND;32 MILANO,SWIVEL,ABS,HB,GR50 1 S.N.A
...3 M0111 BN63-02276B COVER-STAND;32 MILANO-2,SWIVEL,ABS,HB,BK 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 8 S.N.A
...3 CCM1 BN63-02864A COVER-SHEET;BORDEAUX32,PVC MILAY,T0.15,S 1 S.A
...3 CCM1 BN63-02865A COVER-SHEET;BORDEAUX32,PVC MILAY,T0.15,S 1 S.A
0.1 M0001 BN90-01003A ASSY COVER FRONT;32M50,UO,ABS,HB,BK23,MI 1 S.N.A
..2 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 6 S.N.A
..2 T0023 BN96-03425A ASSY COVER P-KNOB POWER;MILANO-3,46UO,AB 1 S.N.A
...3 T0081 BN61-02466A GUIDE-POWER;MILANO 3,PMMA 1 S.N.A
...3 T0023 BN64-00488A KNOB-POWER;MILANO-3,ABS,V0,BK07,H/STAMPI 1 S.N.A
...3 T0054 BN64-00489A KNOB-DECORATION;MILANO3,ABS,HB,AL 1 S.N.A
...3 CIS7 AA61-60003B SPRING ETC-CS;-,SUS304,-,-,OD11.2,N7,OD1 1 S.N.A
..2 T0003 BN96-03941A ASSY COVER P-FRONT;MILANO-3,32UO,ABS,HB, 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 1 S.N.A
...3 M0112 BN63-01934F COVER-FRONT;MILANO-3,32UO,ABS,HB,BK23,S/ 1 S.N.A
...3 T0069 BN63-01935A COVER-MIDDLE;MILANO,32,ABS,V0,GR70,SV012 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.48 S.N.A
...3 T0056 BN63-02786A COVER-DECORATION;MILANO3-32,ABS,-,-,-,V0 1 S.N.A
...3 T0061 BN64-00343A WINDOW-REMOCON;ROME,40,PC,CLEAR 1 S.N.A
...3 T0022 BN64-00490A KNOB-CONTROL;MILANO-3,40,46,ABS,V0 1 S.N.A
...3 M0146 BN96-02399A ASSY BOARD P-POWER & IR;LNR269DX/XAA,CT5 1 S.A
...3 M0145 BN96-02400A ASSY BOARD P-FUNCTION;LNR269DX/XAA,CT500 1 S.A
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
..2 T0382 BP61-00495C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm 0.2 S.N.A
..2 T0175 BN96-02190A ASSY SPEAKER P;8ohm,Left,10W,Milano 32/4 1 S.A
..2 T0175 BN96-02191A ASSY SPEAKER P;8ohm,Right,10W,Milano 32/ 1 S.A
0.1 M0002 BN90-01021A ASSY COVER REAR;32M50,UO,HIPS,V0,GR503,M 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 10 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 3 S.A
..2 T0279 BN63-02544A COVER-JACK;MILANO3 46,HIPS,V0,GR503 1 S.N.A
..2 M0013 BN96-02205A ASSY COVER P-REAR;MILANO,32,HIPS,V0,GR50 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001321 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(BLK),SWRC 4 S.A
...3 M0114 BN61-01605A HOLDER-WIRE;FIRENZE 46,HIPS HB,GR503 1 S.N.A
...3 M0006 BN63-01936A COVER-REAR;MILANO,32,HIPS,V0,GR503 1 S.N.A
...3 BN96-03594A ASSY BRACKET P-VESA;MILANO,32,BR/VESA+BR 1 S.N.A
....4 M0113 BN61-01505A BRACKET-VESA;40,ROME,SECC,T1.6 1 S.N.A
....4 T0101 BN61-02499A BRACKET-WALL;GML32KE,SECC,T1.0 1 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0.1 MP1.0 BN91-01058T ASSY LCD-AMZ;LE32M61BX/XEC 1 S.N.A
..2 M0215 BN07-00324A LCD-PANEL;T315XW02(V3),8bit,760.0*450.0* 1 S.A
0.1 M0017 BN91-01126A ASSY CHASSIS;LNR3292DX/XAA 1 S.N.A
..2 M0014 BN94-01037A ASSY PCB MAIN;LNR3292DX/XAA 1 S.A
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.25 S.N.A
...3 JA801 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004909 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG 1 S.A
...3 CN1003 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 CN1301 3722-001147 JACK-USB;4P/1C,AU,BLK,STRAIGHT,A TYPE 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CIS3 BN40-00081A TUNER;DNVS303HH261A,DNVS303HH261A,VSB/QA 1 S.A
...3 T0253 BN59-00498A MODULE-SPLITTER;UMX-NT-059,UMX-NT-059,2i 1 S.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 T0852 BN96-01470A ASSY BOARD P-OPTICAL;HP-P5581,OPTICAL 1 S.A
....4 CN906 3707-001067 CONNECTOR-OPTICAL;PLUG,SM,-,4.4/2.0mm 1 S.A
...3 T0174 BN97-01099A ASSY SMD;LNR3292DX/XAA 1 S.N.A
....4 CIS05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
