Image preview - the first page of the document



>> Download Samsung_LN26B450_LN32B450_LN37B450_LN40B450_LN32B460_LN32B530_LN37B530_LN40B530_LN46B530_N70A_Disassembly & Reassembly_[SM] documenatation <<

Text preview - extract from the document

                                                                                       3. Disassembly and Reassembly

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LN40B530P2M LCD TV.
    WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
   Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.


                 Description                                    Picture Description                        Screws
 1. Place the TV face down on cushioned table.
    Remove screws from the Stand.
    Remove stand.




                                                                                                                3-1
3. Disassembly and Reassembly


                 Description                 Picture Description   Screws
2. Remove the screws of rear-cover.




3. Lift up the rear-cover.




4. Remove the screws of IP and main board.




3-2
                                                                             3. Disassembly and Reassembly


                Description                                 Picture Description               Screws
5. Remove the speakers and screws of inlet
   socket.




6. Remove the screws of Stand BKLT.
   Lift up the Stand BKLT.




7. Remove the screws on Panel.




 Reassembly procedures are in the reverse order of disassembly procedures.
