5. Exploded View & Part List
5. Exploded View & Part List
5-1. LN40B530P7N Exploded View
M0027
T0764
M0115
M0013
T0101
M0014
M0125
M0146
T0447
M0215
T0175
T0003
5-1
5. Exploded View & Part List
5-1-1. LN40B530P7N Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-09660P ASSY COVER P-FRONT;LB530 40,UO(08),PC+AB 1 S.A
M0013 BN96-06944C ASSY COVER P-REAR;LB530 40,UO(08),HIPS,V 1 S.A
M0215 BN07-00516A LCD-PANEL;T400HW01 V4,AU40H14,8bit,40inc 1 S.A
M0174 BN44-00197A IP BOARD;SIP408A,PEARL,15mA,130mA,150Hz, 1 S.A
M0014 BN94-02906B ASSY PCB MAIN;LN40B530P7NXZA 1 S.A
M0254 BN61-02875A HOLDER-SIDE AV;07,COMMON,UO,PC+ABS,V0,-, 1 S.N.A
T0175 BN96-06809B ASSY SPEAKER P;8ohm,L550 P2/P3,Down Firi 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0027 BN96-11165A ASSY STAND P-BASE;LB530 40,UO(08),ABS+PM 1 S.A
5-2
M0013
T0101
M0146
M0014
T0101
T0764
M0215
5-2. LN46B530P7N Exploded View
T0003
M0125
M0115
T0175
M0027
T0447
5. Exploded View & Part List
5-3
5. Exploded View & Part List
5-2-1. LN46B530P7N Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-09661M ASSY COVER P-FRONT;LB530 46,UO(08),PC+AB 1 S.A
M0013 BN96-06945C ASSY COVER P-REAR;LB530 46,UO(08),HIPS,V 1 S.A
M0215 BN07-00582A LCD-PANEL;V460H1-L05,CM46H15,8bit,46inch 1 S.A
M0174 BN44-00202A IP BOARD;IP-271135A,PEARL,15mA,116mA,150 1 S.A
M0014 BN94-02906C ASSY PCB MAIN;LN46B530P7NXZA 1 S.A
M0254 BN61-03606A HOLDER-SIDE AV;46F8,HIPS V0,BK500,UO, PE 1 S.N.A
T0175 BN96-06809B ASSY SPEAKER P;8ohm,L550 P2/P3,Down Firi 1 S.A
M0115 BN61-03790A BRACKET-STAND LINK;AMBER 46,SECC,T1.6,-, 1 S.N.A
M0027 BN96-11166A ASSY STAND P-BASE;LB530 46,UO(08),ABS+PM 1 S.A
5-4
5. Exploded View & Part List
5-3. LN40B530P7N Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LN40B530P7NXZA LN40B530P7N,N64B/40AP7-G5P,40,LCD-TV,UNI
0.1 M0002 BN90-01552D ASSY COVER REAR;LB530 40(08) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.N.A
..2 M0013 BN96-06944C ASSY COVER P-REAR;LB530 40,UO(08),HIPS,V 1 S.A
...3 BRKT/WALL+ 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0101 BN61-03348A BRACKET-WALL;LCD TV 32,SECC T1.2 2 S.N.A
...3 M0006 BN63-04371D COVER-REAR;L530 40,UO,HIPS,V0,BK500 1 S.A
...3 T0071 BN64-01066A INLAY-TERMINAL;40A530 UO,PS SHEET,T0.5,B 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,BLK 1 S.N.A
0.1 M0001 BN90-01951Q ASSY COVER FRONT;LB530 40 1 S.N.A
..2 T0175 BN96-06809B ASSY SPEAKER P;8ohm,L550 P2/P3,Down Firi 1 S.A
..2 T0003 BN96-09660P ASSY COVER P-FRONT;LB530 40,UO(08),PC+AB 1 S.A
...3 IR-PCB+H/B 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 K/C+C/F 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 AA60-00091P SPACER-FELT;,FELT,500X10,BLK,T0.5 2 S.N.A
...3 M0279 AA63-01637A FELT;50P9,FELT,0.5,10,80 1 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.8 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.7 S.N.A
...3 BN63-02224A FELT-VIBRATION;63P5,FELT,T0.5,850,10 2 S.N.A
...3 M0112 BN63-04370F COVER-FRONT;LB530 40,UO,PC+ABS,V0,BK25,S 1 S.N.A
...3 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 3.6 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,VIOLET 1 S.N.A
...3 T0022 BN64-00755A KNOB-CONTROL;32L450,ABS,V0,BK07 1 S.N.A
...3 M0145 BN96-07269A ASSY BOARD P-FUNCTION;LN40A450C1D,CT5000 1 S.A
...3 M0146 BN96-07270E ASSY BOARD P-POWER & IR;LN40A450C1D,CT50 1 S.A
...3 BN63-01151A FELT-NON WOVEN;MM17NS,T0.5,393,10,BLK 2 S.N.A
...3 BN64-00993C DECORATION-BOTTOM;40,LB530,PC CLEAR,NO C 1 S.N.A
...3 BN96-06932A ASSY HOLDER P-BOSS;40,L530,HIPS,V0,BK500 1 S.N.A
....4 H/BBOTTOM BN61-03888A HOLDER-BOSS BOTTOM;HOLDER-BOSS BOTTOM 40 1 S.N.A
....4 B/TAPE BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.7 S.N.A
....4 ADH BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.003 S.N.A
0.1 M0216 BN90-02229A ASSY STAND;LB530 40,UO(08) 1 S.N.A
..2 M0027 BN96-11165A ASSY STAND P-BASE;LB530 40,UO(08),ABS+PM 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
...3 C/STANDBOT 6003-001239 SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR 6 S.N.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02885A HOLDER-SWIVEL RING;MURANO40,ACETAL NATUR 1 S.N.A
...3 BN61-02886A BRACKET-HINGE SWIVEL;BORDEAUX PLUS,40,SE 1 S.N.A
...3 BN61-03715A BRACKET-STAND BOTTOM;BRACKET-STAND-BOTTO 1 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 T0920 BN61-04994A GUIDE-STAND;40,LB530,PC+GF(20%) V0,BLK 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 T0004 BN63-05522A COVER-STAND BASE;40,LB530,ABS+PMMA,HB 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 6 S.N.A
0.1 BN91-02030A ASSY LCD-AUO;LE40A556P1FX/XC,T400HW02 V1 1 S.N.A
..2 M0215 BN07-00516A LCD-PANEL;T400HW01 V4 1 S.A
0.1 M0017 BN91-04169B ASSY CHASSIS;LN40B530P7NXZA 1 S.N.A
..2 M0014 BN94-02906B ASSY PCB MAIN;LN40B530P7NXZA 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.025 S.N.A
...3 CN903 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 CN330 3711-006765 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.N.A
...3 CN330 3711-006766 HEADER-BOARD TO CABLE;BOX,24P,2R,2mm,STR 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CN850 3722-002516 JACK-USB;4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 S.A
...3 CIS3 BN40-00138A TUNER;TDAU4-K01A,TDAU4-K01A,VSB(NTSC/ATS 1 S.A
...3 M001 BN61-04928A BRACKET-SUPPORT PCB;SPCC,T 0.8,SCREW-M4 1 S.N.A
...3 BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-03483B ASSY SMD;LN40B530P7NXZA,BN94-02783A 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A 0.001 S.N.A
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D109 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D700 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D701 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D702 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D913 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D915 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D916 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D919 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D923 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 FD913 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 FD915 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 FD964 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 FD965 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D101 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D102 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D106 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D630 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D103 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D950 0403-000766 DIODE-ZENER;VLZ3V3A,3.16-3.38V,500mW,SOD 1 S.N.A
....4 D906 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 FD906 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 FD960 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D729 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D730 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D731 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D732 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D733 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D734 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D850 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D851 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D905 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D917 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D920 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D924 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 S.A
....4 D830 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 1 S.A
....4 D901 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D902 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 FD901 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 FD902 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 FD962 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 FD963 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 1 S.A
....4 D104 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 Q100 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q103 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q104 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q107 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1_PWM 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q302 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q401 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q701 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q903 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q950 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC1_DB 1006-001266 IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 1 S.A
....4 IC112 1103-001406 IC-EEPROM;AT24C512BN-SH25-T,512Kbit,64Kx 1 S.A
....4 IC202 1105-001931 IC-DDR2 SDRAM;K4T51163Q,DDR2-800,512Mbit 1 S.N.A
....4 T0124 1201-002797 IC-POWER AMP;NTP-3200,QFN,56P,8x8mm,DUAL 1 S.A
....4 T0085 1201-002849 IC-AUDIO AMP;DRV603,TSSOP,14P,5x4.4mm,DU 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,PLAST 1 S.A
....4 T0087 1203-002835 IC-POSI.FIXED REG.;KIA7805AF,DPAK,3P,6.6 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 T0087 1203-003703 IC-POSI.FIXED REG.;AP1117E-18A,SOT-223,3 1 S.A
....4 IC108 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC501 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC107 1203-005538 IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4. 1 S.A
....4 IC603 1203-005559 IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2 1 S.A
....4 IC602 1204-002818 IC-DEMODULATOR;S5H1411,-,100P,14x14mm,PL 1 S.A
....4 IC201 1204-002980 IC-DECODER;SEMS13-LF,FBGA,377P,21x21mm,P 1 S.A
....4 IC801 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 S.A
....4 D720 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D721 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D722 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D723 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D724 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D725 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D726 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D727 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D728 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D831 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D852 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D853 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D899 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D908 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D910 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D921 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D922 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D925 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 FD910 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 FD961 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 R760 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R118 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R127 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R132 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R2_PWM 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R429 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R430 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R135 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R139 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R141 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R142 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R111 2007-000127 R-CHIP;9.1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R422 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R423 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R424 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R450 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R451 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R452 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R740 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R821 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R850 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R933 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR100 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 FR904 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR960 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R464 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R601 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R607 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R608 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R610 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R612 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R701 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R904 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R951 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 WFR358 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R125 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R126 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R303 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R384 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R385 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R395 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R935 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR917 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR922 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR962 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR966 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R009 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R120 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R123 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R138 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R159 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R160 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R161 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R162 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R178 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R184 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1_PWM 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R463 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R704 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R917 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R922 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R937 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR307 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR918 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR963 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R119 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R129 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R130 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R134 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R136 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R302 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R316 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R329 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R348 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R354_J 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R398 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3_PWM 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R505 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R722 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R723 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R732 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R733 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R852 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R853 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R918 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R929 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R939 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R942 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R947 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R948 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR924 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR967 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R924 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R726 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R727 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R652 2007-000159 R-CHIP;56Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R602 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R651 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R324 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.N.A
....4 R604 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR881C 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR88_C 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R001 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R350 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R356_J 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R710 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R880_C 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR916 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 FR961 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R01_DB 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R317 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3_64M 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R916 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R952 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 WFR357 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R100 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R200 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R300 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R402 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R403 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R404 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R407 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R412 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R613 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R617 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R526 2007-000640 R-CHIP;270ohm,1%,1/10W,TP,1608 1 S.A
....4 R609 2007-000669 R-CHIP;2Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R155 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R156 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R157 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R158 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R606 2007-000755 R-CHIP;330Kohm,1%,1/10W,TP,1608 1 S.A
....4 FR473 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R124 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R148 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R149 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R401 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R605 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R950 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R622 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R13 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R176 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R650 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R724 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R725 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R730 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R731 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R855 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R856 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R936 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R938 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R137 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R131 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R171 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R173 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R174 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R527 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R630 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R900 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R222 2007-007307 R-CHIP;150ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R627 2007-007307 R-CHIP;150ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R220 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R221 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R223 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R224 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R419 2007-007319 R-CHIP;390ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R603 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R114 2007-007549 R-CHIP;4.99Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R525 2007-007721 R-CHIP;560ohm,1%,1/10W,TP,1608 1 S.A
....4 R734 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R735 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R736 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R854 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R931 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R932 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R943 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R946 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R949 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R115 2007-008593 R-CHIP;750ohm,1%,1/16W,TP,1005 1 S.A
....4 R150 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 S.N.A
....4 R312 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R416 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R619 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R620 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 FR450 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 FR455 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 FR815 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 FR816 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R815 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R816 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 FR920 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 FR964 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R310 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R319 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R320 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R321 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R362 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R919 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R930 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 1 S.N.A
....4 R335 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 1 S.N.A
....4 R336 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 1 S.N.A
....4 R752 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 1 S.N.A
....4 R940 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 1 S.N.A
....4 R611 2011-001519 R-NETWORK;33OHM,5%,1/16W,L,CHIP,4P,TP,1. 1 S.N.A
....4 R325 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 1 S.N.A
....4 R361 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 1 S.N.A
....4 R615 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 1 S.N.A
....4 R02_DB 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 1 S.A
....4 R702 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 1 S.A
....4 R03_DB 2011-001589 R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1 1 S.A
....4 C138 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C140 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C199 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C905 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C910 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C911 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C310 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C605 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C701 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C706 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C719 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C124 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C195 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C201 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C220 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C312 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C405 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C449 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C176 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C177 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C179 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C180 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C119 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 S.A
....4 C443 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 S.A
....4 C444 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 S.A
....4 C720 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C721 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C722 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C851 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C906 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 1 S.A
....4 C114 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C155 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C156 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C158 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C650 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C615 2203-000851 C-CER,CHIP;0.039nF,5%,50V,C0G,1608 1 S.A
....4 C616 2203-000851 C-CER,CHIP;0.039nF,5%,50V,C0G,1608 1 S.A
....4 C163 2203-000925 C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C164 2203-000925 C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C601 2203-000925 C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C682 2203-000925 C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C606 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
....4 C613 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
....4 C614 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
....4 C752 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
....4 C907 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C908 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C623 2203-001072 C-CER,CHIP;0.056nF,5%,50V,NP0,1005 1 S.A
....4 C426 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C427 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C430 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C431 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C432 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C433 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C434 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C435 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C302 2203-001628 C-CER,CHIP;0.03nF,5%,50V,NP0,1608 1 S.N.A
....4 C303 2203-001628 C-CER,CHIP;0.03nF,5%,50V,NP0,1608 1 S.N.A
....4 C713 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 1 S.N.A
....4 C714 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 1 S.N.A
....4 C438 2203-001724 C-CER,CHIP;4700nF,+80-20%,16V,Y5V,3216 1 S.N.A
....4 C712 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C715 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C716 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C743 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C854 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C855 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C100 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C126 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C143 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C150 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C151 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C165 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C166 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C167 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C168 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C169 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C170 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C171 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C172 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C447 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C448 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C603 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 FC453 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C403 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C404 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C406 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C410 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C411 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C413 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C418 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C420 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C423 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C424 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C116 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C120 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C123 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C125 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C127 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C134 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C139 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C141 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C144 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C147 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C148 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C149 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C437 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C01_DB 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C02_DB 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C03_DB 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C04_DB 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C05_DB 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C132 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C135 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C136 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C137 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C189 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C191 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C202 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C207 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C208 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C209 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C210 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C211 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C212 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C213 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C214 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C215 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C216 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C217 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C218 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C219 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C304 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C311 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C401 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C402 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C407 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C408 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C409 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C425 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C436 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C440 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C511 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C515 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C519 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C521 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C522 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C529 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C530 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C532 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C534 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C535 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C536 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C537 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C538 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C540 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C541 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C542 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C543 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C544 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C545 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C546 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C547 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C548 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C549 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C550 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C551 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C552 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C553 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C555 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
5-15
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C557 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C558 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C604 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C607 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C608 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C610 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C611 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C612 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C617 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C619 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C620 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C621 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C622 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C624 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C626 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C628 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C629 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C630 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C631 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C633 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C634 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C635 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C637 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C640 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C642 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C643 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C646 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C700 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C750 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C860 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C904 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C912 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 FC904 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 FC960 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C112 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C153 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C159 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C160 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C307 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C308 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 1 S.A
....4 C001 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C102 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C103 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C108 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C109 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C121 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C122 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C130 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C131 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C133 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C145 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
5-16
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C146 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C190 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C193 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C197 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C203 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C439 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C509 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C510 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C526 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C559 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C561 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C562 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C563 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C565 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C567 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C568 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C602 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C618 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C645 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C900 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C902 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C909 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 1 S.A
....4 C110 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 1 S.N.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 1 S.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 1 S.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 1 S.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 S.A
....4 T0052 2703-000398 IND◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
