Image preview - the first page of the document
![Samsung_LN40C550J1FXZA_fast_track_guide_[SM]](/pics/5c26d821b0afe.gif)
>> Download Samsung_LN40C550J1FXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
LN40C550J1FXZA Fast Track Troubleshooting Manual Rev - 1/12/12
SERVICE BULLETINS
POWER 2010 LCD Option Byte Table
PCB
Verify All Parts Numbers Are Current
MAIN
Insert Photo of TV Board Layout Version
Include Board Assy names (as
PCB appearing in parts) and any
Parts No Short Description
special labels/items (i.e. Plasma voltage label) ALL BN44-00341A Power PCB
LVDS DRIVER
Function & IR PCB
CABLE BOARD ALL BN96-13451B
ALL BN96-15663A Main PCB
T-CON PCB ALL BN07-00830A Panel
SPEAKER SPEAKER
(under shield) ALL BN81-04411A T-CON PCB
HELP : 1-888-751-4086; 1-866-894-0637 (FE) FIRMWARE ALL BN96-10689A Stand Guide Neck
GSPN 10/18/2010 ALL BN96-12767E Rear Cover
http://gspn3.samsungcsportal.com Firmware for SX1 & X4 Model ALL BN96-12808A Front Cover
PLUS ONE -. Version : 1016.3 (SX1), 2006.0 (X4)
BN96-12795C
http://my.plus1solutions.net/clientPortals/samsung -. Folder Name: T-TDT5AUSC / T- ALL Stand Guide
MSX5AUSC ALL BN96-12762A Stand Base
HOT TIPS This firmware will prevent below ALL BN40-00163A Tuner
Power On Problems: (see page 2) problems
BN96-12837A
. Distorted picture on 70 Hz, 75 Hz ALL Speaker
Video Problems: (see pages 3,4)
. Distorted picture on DTV PIP with 1080i ALL BN96-13171U LVDS Cable
TIP: After replacing Main/Panel mode 3903-000467
picture is upside down. ALL Power Cord
Fix: Test Mode/Mirror Option/Toggle ALL BN59-01041A Remote
1
ALL BN63-01798B Cleaning Cloth
LN40C550J1FXZA Fast Track Troubleshooting Manual
CN201
Wiring Diagram
Include Connector Numbers , References, and
Locations.
LN46C670M1FXZA
Power On Sequence (approximate Voltages)
)
1. Standby Voltages: CN201-4 (5V) To Force Backlight On
2. Power On CN201-2 (0 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
