Image preview - the first page of the document
![Samsung_LN46C610N1FXZA_fast_track_guide_[SM]](/pics/5c26d8747982c.gif)
>> Download Samsung_LN46C610N1FXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
LN46C610N1FXZA Fast Track Troubleshooting Manual Rev - 1/10/12
SERVICE BULLETINS
No Bulletins listed on GSPN as of
POWER 12/28/11
PCB
MAIN
Insert Photo of TV Board Layout Version
Include Board Assy names (as
PCB appearing in parts) and any Short
Parts No Description
special labels/items (i.e. Plasma voltage label) ALL BN44-00341B Power PCB
LVDS DRIVER
Function & IR PCB
CABLE BOARD ALL BN96-13226B
ALL BN94-03446N Main PCB
T-CON PCB ALL BN07-00833B Panel
SPEAKER SPEAKER
(under shield) ALL BN81-04467A T-CON PCB
HELP : 1-888-751-4086; 1-866-894-0637 (FE) FIRMWARE ALL BN96-10689A Stand Guide Neck
GSPN 10/18/2010 ALL BN96-12768B Rear Cover
http://gspn3.samsungcsportal.com Firmware for Valencia 128M and X4
BN96-14032A
Model . Version : 1010.0 (Valencia ALL Front Cover
PLUS ONE 128M), 1005.0 (X4) Folder Name: T- ALL BN96-12795C Stand Guide
http://my.plus1solutions.net/clientPortals/samsung VAL5AUSC & T-MSX6AUSC ALL BN96-12763E Stand Base
Description
HOT TIPS This firmware will prevent below ALL BN40-00163A Tuner
Power On Problems: (see page 2) problems ALL BN96-12837B Speaker
Video Problems: (see pages 3,4) . ' USB Power Overload' message pops up BN96-12723D
ALL LVDS Cable
even USB port is not connected
TIP: After replacing Main/Panel . HDMI 2 looks activated when HDMI 1 ALL 3903-000467 Power Cord
picture is upside down. port is connected ALL BN59-01041A Remote
Fix: Test Mode/Mirror Option/Toggle 1
ALL BN63-01798B Cleaning Cloth
LN46C610N1FXZA Fast Track Troubleshooting Manual
CN201
SW-P
Wiring Diagram
Include Connector Numbers , References, and
Locations.
LN46C670M1FXZA
Power On Sequence (approximate Voltages)
)
1. Standby Voltages: CN201-4 (5V) To Force Backlight On
2. Power On CN201-2 (0 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
