Image preview - the first page of the document
![Samsung_LN46C630K1FXZA_fast_track_guide_[SM]](/pics/5c26d87d4c19a.gif)
>> Download Samsung_LN46C630K1FXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
LN46C630K1FXZA Fast Track Troubleshooting Manual Rev - 1/10/12
SERVICE BULLETINS
POWER 1. 2010 LCD Option Byte Table
PCB
MAIN
Insert Photo of TV Board Layout Version
Include Board Assy names (as
PCB appearing in parts) and any
Parts No Short Description
special labels/items (i.e. Plasma voltage label) ALL BN44-00341B Power PCB
LVDS DRIVER
Function & IR PCB
CABLE BOARD ALL BN96-13451C
ALL BN94-02701P Main PCB
T-CON PCB ALL BN07-00833B Panel
SPEAKER SPEAKER
(under shield) ALL BN81-04414A T-CON PCB
HELP : BN96-10689A
1-888-751-4086; 1-866-894-0637 (FE) FIRMWARE ALL Stand Guide Neck
GSPN 10/18/2010 ALL BN96-12768B Rear Cover
http://gspn3.samsungcsportal.com Firmware for Valencia 1G Model BN96-12773A
ALL Front Cover
-. Version : 1030.1
ALL BN96-12795C Stand Guide
PLUS ONE -. Folder Name: T-VALAUSC
http://my.plus1solutions.net/clientPortals/samsung -. Related Models LCD: C560 (Only 40"), ALL BN96-12763F Stand Base
C650, C670, C750 ALL BN40-00163A Tuner
HOT TIPS And this firmware prevents below
BN96-12837B
Power On Problems: (see page 2) issues..'USB Power Overload' message ALL Speaker
Video Problems: (see pages 3,4) pops up even USB port is not connected ALL BN96-12723D LVDS Cable
. Plug & Play is displayed whenever 3903-000467
TIP: After replacing Main/Panel turning on TV.
ALL Power Cord
picture is upside down. ALL BN59-01041A Remote
Fix: Test Mode/Mirror Option/Toggle 1
ALL BN63-01798B Cleaning Cloth
LN46C630K1FXZA Fast Track Troubleshooting Manual
CN201
SW-P
Wiring Diagram
Include Connector Numbers , References, and
Locations.
LN46C670M1FXZA
Power On Sequence (approximate Voltages)
)
1. Standby Voltages: CN201-4 (5V) To Force Backlight On
