Image preview - the first page of the document
![Samsung_LN55C610N1FXZA_fast_track_guide_[SM]](/pics/5c26d8cb5ee66.gif)
>> Download Samsung_LN55C610N1FXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
LN55C610N1FXZA Fast Track Troubleshooting Manual Rev - 1/12/12
SERVICE BULLETINS
POWER 10/5/11 No service bulletins
PCB
Verify All Part Numbers Are Current
MAIN
Insert Photo of TV Board Layout Version
Include Board Assy names (as
PCB appearing in parts) and any
Parts No Short Description
special labels/items (i.e. Plasma voltage label) ALL BN44-00342B Power PCB
LVDS DRIVER
Function & IR PCB
CABLE BOARD ALL BN96-13226B
ALL BN94-03446Q Main PCB
T-CON PCB ALL BN07-00834A Panel
SPEAKER SPEAKER
(under shield) ALL BN81-04415A T-CON PCB
HELP : 1-888-751-4086;1-866-894-0637 (FE) FIRMWARE ALL BN96-10689A Stand Guide Neck
GSPN 10/18/2010 ALL BN96-12769A Rear Cover
http://gspn3.samsungcsportal.com
Firmware for Valencia 128M and X4 ALL BN96-14033A Front Cover
PLUS ONE Model-. Version : 1010.0 (Valencia ALL BN96-12760A Stand Guide
http://my.plus1solutions.net/clientPortals/samsung 128M), 1005.0 (X4) -. Folder Name:
ALL BN96-12764E Stand Base
HOT TIPS T-VAL5AUSC & T-MSX6AUSC
BN40-00163A
Power On Problems: (see page 2) This firmware will prevent below ALL Tuner
problems..USB Power Overload' ALL BN96-12838A Speaker
Video Problems: (see pages 3,4)
TIP: After replacing Main/Panel message pops up even USB port is ALL BN96-12723E LVDS Cable
picture is upside down. not connected ALL 3903-000467 Power Cord
Fix: Test Mode/Mirror Option/Toggle . HDMI 2 looks activated when ALL BN59-01041A Remote
HDMI 1 port is connected ALL BN63-01798B Cleaning Cloth
1
LN32C350D1DXZA Fast Track Troubleshooting Manual
CN201
Wiring Diagram
Include Connector Numbers , References, and
Locations.
Power On Sequence (approximate Voltages)
)
1. Standby Voltages: CN201-4 (5V) To Force Backlight On
2. Power On CN201-2 (0 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
