Image preview - the first page of the document
![Samsung_LNT3242H_LNT4042H_LNT4642H_Operation Instruction & Installation_[SM]](/pics/5c26d8f5c3bab.gif)
>> Download Samsung_LNT3242H_LNT4042H_LNT4642H_Operation Instruction & Installation_[SM] documenatation <<
Text preview - extract from the document
10 Operating Instructions and Installation
10 Operating Instructions and Installation
10-1 Front
- The product color and shape may vary depending on the model.
1. SOURCE 4. < CH >
Toggles between all the available input sources Press to change channels.
(TV, AV1, AV2, S-Video 1, S-Video 2, Component1, In the on-screen menu, use the < CH > buttons
Component2, PC, HDMI1, HDMI2, HDMI3) as you use the and buttons on the remote
In the on-screen menu, use this button as you would control.
use the ENTER button on the remote control.
5. SPEAKERS
2. MENU
Press to see an on-screen menu of your TV's features. 6. (POWER)
Press to turn the TV on and off.
3. REMOTE CONTROL SENSOR
Press to decrease or increase the volume. Aim the remote control towards this spot on the TV.
In the on-screen menu, use the buttons as POWER INDICATOR
you use the and buttons on the remote control. Blinks and turns off when the power is on and lights
up in stand-by mode.
10-1
10 Operating Instructions and Installation
10-2 Connection Panel
1. AUDIO OUT 6. AV IN 1 / AV IN 2
Connects to the audio input jacks on your Amplifier/ Video and audio inputs for external devices, such as
Home theater. a camcorder or VCR.
2. DIGITAL AUDIO OUT (OPTICAL) S-VIDEO
Connect to a Digital Audio component. Connects an S-Video signal from a camcorder or
3. PC IN VCR.
Connect to the video and audio output jacks on 7. HEADPHONE
your PC. Connects a set of external headphones for private
4. HDMI IN 1,2,3 /DVI IN(HDMI1) (AUDIO R/L) listening.
Connect to the HDMI jack of a device with an HDMI 8. SERVICE
output. Use the HDMI 1 IN terminal for a DVI Connector for service only.
connection to an external device. You should use the 9. COMPONENT IN 1,2
DVI to HDMI cable or DVI-HDMI adapter (DVI to Connects Component video/audio.
HDMI) for a video connection,and the DVI IN 10. POWER INPUT
'R-AUDIO-L' terminal for audio. Connect the supplied power cord.
- The HDMI IN 1 terminal does not support PC 11. EX LINK
connection Connector for Wall Mount Adjustment only.
- No sound connection is needed for an HDMI to 12. KENSINGTON LOCK
HDMI connection The Kensington lock (optional) is a device used to
- When using an HDMI/DVI cable connection, it is physically fix the system when used in a public
only possible from the HDMI IN 1 terminal. place. If you want to use a locking device, contact
5. ANT 1 IN/ANT 2 IN the dealer where you purchased the TV.
Connects to an antenna or cable TV system. - The place of the Kensington Lock may be different
depending on its model.
10-2
10 Operating Instructions and Installation
10-3 Remote Control
- This is a special remote control for the visually impaired, and has Braille points on the Power, Channel and Volume buttons.
10-3
10 Operating Instructions and Installation
1. POWER 19.When pressing this button, a number
Turns the TV on and off. of buttons on the remote control (e.g.
2. NUMERIC BUTTONS TV, DVD, STB, CABLE, VCR, MUTE,
Press to change the channel. VOL and CH buttons) light up for a few
3. _ seconds and then turn off to save
Press to select additional channels(digital power. This function is convenient for
and analog) being broadcast by the same using the remote at night or when dark.
station. For example, to select channel 20.SOURCE
"54-3", press "54", then press "." and "3". Press to display all of the available
4. CH LIST video sources.
Used to display Channel Lists on the screen. 21. PRE-CH
5. ANTENNA Turns to the previous channel.
Press to select "AIR" or "CABLE". 22. FAV.CH
6. VCR/DVD Functions Press to switch to your favorite channels.
- Rewind 23.HDMI
- Stop Selects the HDMI mode directly.
- Play/Pause 24.CH / CH
- Fast/Forward Press to change channels.
7. VOL / VOL 25.EXIT
Press to increase or decrease the volume. Press to exit the menu.
8. (MUTE) 26.UP / DOWN / LEFT / RIGHT / ENTER
Press to temporarily cut off the sound. Use to select on-screen menu items and
9. MENU change menu values.
Displays the main on-screen menu. 27.INFO
10.S.MODE Press to display information on the TV
Sound mode selection. screen.
11.RETURN 28.CAPTION
Returns to the previous menu. Controls the caption decoder.
12.P.MODE 29.STILL
Picture effect selection. Press to stop the action during a particular
13.SRS scene. Press again to resume normal video.
Selects TruSurround XT mode. 30.P.SIZE
14.MTS Picture size selection.
Press to choose stereo, mono or Separate 31.PIP
Audio Program(SAP broadcast). Picture-in Picture ON/OFF.
15.SLEEP 32.CH /
Press to select a preset time interval Displays the available channels in sequence.
for automatic shut off. (These buttons change channels in the PIP
16. AUTO PROG. window only.)
Press to automatically store selected 33.ADD/DEL
TV/Cable channels. Use to store and delete channels
17. SET to/from memory.
Adjusts 5 separate devices - 34.RESET
TV, VCR, Cable, DVD, or Set-Top Box When your remote does not work,
18. TV, DVD, STB, CABLE, VCR change the batteries and press the
Make the remote control work for TV, RESET button for 2-3 seconds
DVD, STB, CABLE, or VCR before use.
10-4
