Text preview - extract from the document

                                                               13 Circuit Descriptions



13 Circuit Descriptions
13-1 Block description (N36A)




NO.   BLOCK                     DESCRIPTION                 REMARK
 1    X242(IC202)               DTV DECODER                 215H4AALA11HG
 2    FBEX(IC1301)              IMAGE BACKEND ENHANCER      NZ2YFKC
 3    SUB_MICOM(IC602)          CONTROL POWER,PANEL, etc.   WT61P6S
 4    SOUND AMP(IC1100)         SOUND AMP IC                NTP3000(H12363B)
 5    SOUND PROCESSOR(IC1002)   SOUND MAIN PROCESSOR IC     MSP4450K E8
 6    TUNER(TU500)              HALF-NIM-TUNER & SPLITTER   DTVS227CH281A
 7    DDR MEMORY(IC201)         X242 DDR MEMORY             HYB18T512161BF-25
 8    IC-RECEIVER(IC1201)       2ADC+1HDMI                  MST3388MK-LF-110
 9    HDMI SWITCH(IC1202)       3 TO 1 HDMI SWITCH          SIL9185CTU



                                                                                 13-1
13 Circuit Descriptions

13-2 Block description (N34B)




                    DDR-
                    MEMORY




                                                          TUNER
                          DTV-IC

                  FLASH
                  MEMORY


                                    Scaler+
                                     Video
                                    Decoder

                   Backend
                   Enhanced                         SUB-
                                     DDR            MICOM
                                     MEMORY
              MAIN POWER BLOCK


                                   SOUND
                                    AMP         SOUND
                                              PROCESSOR




 NO.    BLOCK                         DESCRIPTION                 REMARK
  1     LAKE1(IC1301)                 DTV DECODER+ARM CPU         S5H2111X01
  2     SVP-PX(IC1001)                VIDEO DECODER+SCALER        STP03
  3     FBE2(IC1201)                  IMAGE BACKEND ENHANCER      DNIe SDP64
  4     SUB_MICOM(IC202)              CONTROL POWER,PANEL,etc.    WT61P6S
  5     SOUND_IC(IC302)               SOUND MAIN PROCESSOR IC     MSP4450
  6     SOUND_AMP(IC401)              SOUND AMP IC                NTP3000
  7     TUNER(TU501)                  DTV TUNER                   BN40-00097A




13-2
