Image preview - the first page of the document
![Samsung_LNT3242H_LNT4042H_LNT4642H_Electrical Part List_[SM]](/pics/5c26d9209807f.gif)
>> Download Samsung_LNT3242H_LNT4042H_LNT4642H_Electrical Part List_[SM] documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LNT3242HX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LNT3242HTX/XAA LN-T3242HT,N34A/32S80-GJA,32,LCD-TV,UNIT 0
0.1 M0001 BN90-01172A ASSY COVER FRONT;32S81,UO,PC+ABS,V0,BK25 1 S.N.A
..2 T0003 BN96-04694A ASSY COVER P-FRONT;32S81,UO,PC+ABS,V0,BK 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 4 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.48 S.N.A
...3 M0112 BN63-03094A COVER-FRONT;32S81,UO,PC+ABS,-,-,-,V0,-,B 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0022 BN64-00467D KNOB CONTROL;MOSEL32,ABS,-,-,-,V0,BK07,- 1 S.A
...3 T0023 BN64-00589A KNOB POWER;32S81,PC,-,-,-,-,VIOLET,-,- 1 S.N.A
...3 T0054 BN64-00590A KNOB-DECORATION;JASMINE 32,ABS,-,-,-,HB, 1 S.N.A
...3 M0145 BN96-03466A ASSY BOARD P-FUNCTION;SONOMA,SJ06-01-008 1 S.A
...3 T0175 BN96-04770A ASSY SPEAKER P;8ohm,4pin,10W,Jasmine 32" 1 S.A
...3 T0066 BN96-04749B ASSY COVER P-DECORATION;32S81,-,ABS,HB,N 1 S.N.A
....4 T0056 BN63-03096B COVER-DECORATION;32S81,ABS,-,-,-,HB,-,NT 1 S.N.A
....4 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.7 S.N.A
...3 M0146 BN96-04884E ASSY BOARD P-POWER & IR;LE37R86BD,CT5000 1 S.A
...3 BN63-01925A FELT-VIBRATION;42D5,FELT,T0.35,10,370 4 S.N.A
0.1 M0002 BN90-01173L ASSY COVER REAR;LNT3242HTX/XAA 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0013 BN96-04696G ASSY COVER P-REAR;32S81,UO(HOTEL),HIPS,V 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
...3 T0101 BN61-03348A BRACKET-WALL;LCD TV 32",SECC T1.6 4 S.N.A
...3 M0006 BN63-03095A COVER-REAR;32S81,UO,HIPS,-,-,-,V0,-,BK50 1 S.N.A
...3 T0071 BN64-00554G INLAY-TERMINAL;07,COMMON,PS SHEET,T0.5,L 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0216 BN90-01175A ASSY STAND;JASMINE32 1 S.N.A
..2 M0027 BN96-04697A ASSY STAND P-BASE;32S81,-,ABS+PMMA,HB,BK 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 S.N.A
...3 T0920 BN61-02929A GUIDE-STAND;JASMINE 32,ABS,V0,-,-,-,BK50 1 S.N.A
....4 BN61-02967A BRACKET-SUPPORT STAND;32 BORDEAUX PLUS,S 1 S.N.A
....4 T0514 BN61-03046A BRACKET-SUPPORT;32 BORDEAUX PLUS,SECC,2. 1 S.N.A
...3 BN61-02945A BRACKET-STAND BOTTOM;JASMINE 32",SECC,T1 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 T0004 BN63-03106A COVER-STAND BASE;JASMINE 32",ABS+PMMA,HB 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,CR Rubber Gray,T1.5 8 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
0.1 M0019 BN91-01180F ASSY LCD;LE32R72BX/* 1 S.N.A
..2 M0215 BN07-00348A LCD-PANEL;V315B1-L01,8bit,31.5inch,16.7M 1 S.A
0.1 M0017 BN91-01604A ASSY CHASSIS;LNT3242HTX/XAA 1 S.N.A
..2 M0014 BN94-01337A ASSY PCB MAIN;LN32T71BDA 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA701B 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN801 3701-001400 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,Ni 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty S.A/S.N.A
...3 CN330 3711-005606 HEADER-BOARD TO CABLE;BOX,30P,2R,2mm,STR 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001163 JACK-VHS;4P,AU,BLK,ANGLE 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002543 JACK-PIN;3P,Sn,RED/WHT/YEL,ANGLE 1 S.A
...3 CN704B 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 1 S.N.A
...3 CN601H 3722-002547 JACK-MODULAR;8P/4C,N,STRAIGHT,N,AU,1PORT 1 S.A
...3 CIS3 BN40-00107A TUNER;DNVS227IH262A,DNVS227IH262A,NTSC/V 1 S.A
...3 T0099 BN62-00003A HEAT SINK-IC;NK,SUN,A6063S,T2.5,W28,L28, 1 S.N.A
...3 T0603 BN63-03195A SHIELD-PCB MAIN;TULIP NT,SPTE,T0.5 1 S.N.A
...3 CCMM1 BN73-00024D SILICON/RUBBER;BORDEAUX,SILICON,28x28XT6 1 S.N.A
...3 T0174 BN97-01623A ASSY SMD;LN32T71BDA 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
