Image preview - the first page of the document



>> Download Samsung_PN43D450A2DXZA_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document

    PN43D450A2DXZA                             Fast Track Troubleshooting Manual

                                                                                                  Pub# AP-PN43D450A2D Rev. Date: 5/18/2012
 Y Buffer
                                                                                                Service Bulletins:
                                           SMPS
                                                                                                 2011 PDP Option Byte Table -
                                                                                                 ASC20110630001 .
               Y Main                                                   X Main                  Quick Parts List:

                                                                                                Version     Parts No       Short Description
                                                                                                  ALL     BN44-00442A             SMPS
                                                                                                 N102     BN96-16507A       Logic Main PCB
                                                                                                 B104     BN96-16507B       Logic Main PCB
                                                                                                  ALL     BN96-16508A           Buffer E
                                                                                 Main             ALL     BN96-16509A           Buffer F
                                  Logic
                                                                                                 N102     BN96-16510A           X Main
                                                                                                 B104     BN96-16510B           X Main
                                                                                                  ALL     BN96-16511A            Y Main
                                                                                                  ALL     BN96-16512A        Y Main Scan
                 Spkr      Buffer E                     Buffer F          Spkr          Func.     ALL     BN96-16730C      Function & IR PCB
                                                                                                  ALL     BN96-19469A          Main PCB
                                                                                                 N102     BN96-17356A             Panel
HELP: 1-888-751-4086 (Tech Support)             Latest Firmware:
                                                                                                 B104     BN96-17356B             Panel
        1-866-894-0637 (ME/FE)                   None
