Image preview - the first page of the document
![Samsung_PN50A550_PN58A550_ExplodedView_PartsList_[SM]](/pics/5c26d9d352b15.gif)
>> Download Samsung_PN50A550_PN58A550_ExplodedView_PartsList_[SM] documenatation <<
Text preview - extract from the document
LASMA DISPLAY T V 50AS1(50A550)
M0013
5-1
T0079
M0412
Exploded View & Part List
T0165
T0152
M0523
T0044
T0448
5. ExplodedView&PartList
5-1 PN50A550S1FXZAExplodedView
M0149
M0125
T0456
M0146
M0027
T0003
M0112 M0150
T0175
T0175
M0102 M0150
T0603
M0175
T0056
Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
M0013 BN96-06772R ASSY COVER P-REAR 50P550,PCM,0.5,BKM-P70 1 S.A
M0027 BN96-06693A ASSY STAND P-BASE Spinel 50" 1 S.A
M0102 BN96-06798B ASSY BLU P Pearl(L550),BACK LIGHT UNIT,M 1 S.A
M0112 BN63-04262A COVER-FRONT P550-50,PMMA+ABS,HB,BK27 1 S.N.A
M0125 BN96-07190B ASSY INLET P Spinel,450mm,IG-N06BES4,250 1 S.A
M0145 BN96-07248E ASSY BOARD P-FUNCTION & IR PN50A550S1FXZ 1 S.A
M0146 BN96-06692A ASSY BRACKET P-FILTER SIDE P450 50inch,S 2 S.N.A
M0149 BN96-06690B ASSY BRACKET P-FILTER TOP Spinel 50",SAZ 1 S.N.A
M0150 BN96-06689A ASSY BRACKET P-SUPPORT FILTER Spinel 50" 1 S.N.A
M0150 BN96-06694C ASSY BRACKET P-FILTER BOTTOM 50P550,SEA/ 1 S.N.A
M0412 BN96-06697A ASSY BRACKET P-PCB Spinel 50,,SECC,T0.6, 1 S.N.A
M0523 BN96-06695E ASSY BRACKET P-SUPPORT STAND P550 50,SEC 1 S.N.A
T0003 BN96-06687A ASSY COVER P-FRONT Spinel 50",,ABS+PMMA, 1 S.A
T0044 BN96-07128C ASSY PDP MODULE P S50FH-YB01,PL50FB003B, 1 S.A
T0056 BN63-04456A COVER-DECORATION P550-50,PMMA + ABS,BK23 1 S.N.A
T0079 BN94-01658B ASSY PCB MISC-MAIN PN50A550S1FXZA,F43A,P 1 S.A
T0152 BN96-06773A ASSY BRACKET P-WALL RIGHT P450 50Inch,,S 1 S.A
T0165 BN96-06696P ASSY COVER P-AV 42P450 1 S.N.A
T0175 BN96-07086B ASSY SPEAKER P 8ohm,CORAL,PDP,10W,200mm, 1 S.A
T0175 BN96-07192A ASSY SPEAKER P 8ohm,P450/P550 50inch,PDP 1 S.A
T0448 BN96-06774A ASSY BRACKET P-WALL LEFT P450 50Inch,SEC 1 S.A
T0456 BN67-00212A GLASS-FILTER EMI W3, 510, 50", Normal,Me 1 S.A
T0603 BN64-00588A WINDOW-RMC 32,BORDEAUX PLUS,PC,-,-,-,HB, 1 S.N.A
T0044 BN96-06772X ASSY PDP MODULE P PL50FB003F,50FHD UF1 1 S.A
M0013 BN96-06772R ASSY COVER P-REAR 50P550,PCM,0.5,BKM-P70 1 S.A
Samsung Electronics 5-2
PLASMA DISPLAY T V 58AS1(58A550)
M0013
5-3
T0079
M0412
Exploded View & Part List
T0175
M0006
M0523 T0175
T0044
T0165
M0149
5-2 PN58A550S1FXZAExplodedView
M0523
T0456 M0146
M0027
T0003
M0150
M0112
M0150
M0102
T0603
M0175
T0056
Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
M0006 BN96-06036A ASSY SHIELD P-COVER 58P9,SECC 0.8 1 S.N.A
M0013 BN96-06699D ASSY COVER P-REAR Spinel 58,PCM T0.5,BKM 1 S.A
M0027 BN96-06806A ASSY STAND P-BASE P550 58Inch,ABS,HB,BK2 1 S.A
M0102 BN96-06798B ASSY BLU P Pearl(L550),BACK LIGHT UNIT,M 1 S.A
M0112 BN63-04260A COVER-FRONT P550-58,PMMA+ABS,HB,BK27 1 S.N.A
M0145 BN96-07248D ASSY BOARD P-FUNCTION & IR PN58A550S1FXZ 1 S.A
M0146 BN96-06703A ASSY BRACKET P-FILTER SIDE Spinel 58,,SA 2 S.N.A
M0149 BN96-06700A ASSY BRACKET P-FILTER TOP Spinel 58,,SAZ 1 S.N.A
M0150 BN96-06702A ASSY BRACKET P-SUPPORT FILTER Spinel 58" 1 S.N.A
M0150 BN96-06704B ASSY BRACKET P-FILTER BOTTOM Spinel 58,S 1 S.N.A
M0412 BN96-06701A ASSY BRACKET P-PCB Spinel 58,,SECC,T0.6, 1 S.N.A
M0523 BN96-06695B ASSY BRACKET P-SUPPORT STAND P470 50",SE 1 S.N.A
M0523 BN96-06805A ASSY BRACKET P-WALL P750 58Inch,SECC T0. 2 S.N.A
T0003 BN96-06688A ASSY COVER P-FRONT Spinel 58",,ABS+PMMA, 1 S.A
T0044 BN96-05638C ASSY PDP MODULE P-PDP MODULE PL58FB003A, 1 S.A
T0056 BN63-04457A COVER-DECORATION P550-58,PMMA + ABS,BK23 1 S.N.A
T0079 BN94-01660A ASSY PCB MISC-MAIN PN58A550S1FXZA,F43A,S 1 S.A
T0165 BN96-06696P ASSY COVER P-AV 42P450 1 S.N.A
T0175 BN96-07355A ASSY SPEAKER P 8ohm,P550 58" LEFT,Down F 1 S.A
T0175 BN96-07356A ASSY SPEAKER P 8ohm,P550 58" Right,Down 1 S.A
T0456 BN67-00217A GLASS-FILTER EMI W3, 510, 58", Normal,Me 1 S.A
Samsung Electronics 5-4
Exploded View & Part List
5-3 PN50A550S1FXZAServiceItem
This is the list which is available to repair the real material at the time of service.
Loc. No. Code No. Description Specification Q'ty Remark
M0013 BN96-06772R ASSY COVER P-REAR 50P550,PCM,0.5,BKM-P70 1
M0027 BN96-06693A ASSY STAND P-BASE Spinel 50" 1
M0154 BN96-07132A ASSY PDP P-Y-MAIN BORAD S50FH-YB01,PL50F 1
M0155 BN96-06813A ASSY PDP P-Y SCAN UPPER BOARD PL50FH030A 1
M0156 BN96-06814A ASSY PDP P-Y SCAN LOWWER BORAD PL50FH030 1
M0869 BN96-08171A ASSY PDP P-X MIAN UBFFER S50FH-YB01,PL50 1
M2893 BN39-00802P LEAD CONNECTOR FPT5884X/XAA,UL1007#26,24 1
M2893 BN39-01070C LEAD CONNECTOR-LVDS PN50A550S1FXZA,UL202 1
T0003 BN96-06687A ASSY COVER P-FRONT Spinel 50",,ABS+PMMA, 1
T0037 BN96-07134C ASSY PDP P-LOGIC MAIN S50FH-YB01,PL50FB0 1
T0044 BN96-07128C ASSY PDP MODULE P S50FH-YB01,PL50FB003B, 1
T0073 BN96-07131B ASSY PDP P-X MAIN BOARD S50FH-YB01,PL50F 1
T0074 BN59-00673A REMOCON PEARL,TM96A,49,USA,SAMSUNG,TOOLS 1
T0079 BN94-01658B ASSY PCB MISC-MAIN PN50A550S1FXZA,F43A,P 1
T0152 BN96-06773A ASSY BRACKET P-WALL RIGHT P450 50Inch,,S 1
T0175 BN96-07086B ASSY SPEAKER P 8ohm,CORAL,PDP,10W,200mm, 1
T0175 BN96-07192A ASSY SPEAKER P 8ohm,P450/P550 50inch,PDP 1
T0448 BN96-06774A ASSY BRACKET P-WALL LEFT P450 50Inch,SEC 1
T0764 BN44-00222A SMPS-PDP TV PDP 50WF3.5,AC/DC,593.8W,AC1 1
T0764 BN44-00237A SMPS-PDP TV PDP 50WF3.5, AC/DC,593.8W,AC1 1
T0937 BN96-08172A ASSY PDP P-ADDRESS E BUFFER S50FH-YB01,P 1
T0938 BN96-08173A ASSY PDP P-ADDRESS F BUFFER S50FH-YB01,P 1
M0013 BN96-06772X ASSY COVER P-REAR 50P550,PCM,0.5,BKM-P70 1
T0044 BN96-08659A ASSY PDP MODULE P PL50FB003F,50FHD UF1 1
T0073 BN96-08751A ASSY PDP P-X MAIN BOARD S50FH-YB01,PL50FB003F,50 UF1 1
M0154 BN96-08752A ASSY PDP P-Y-MAIN BORAD S50FH-YB01,PL50FB003F,50 UF1 1
M0869 BN96-08753A ASSY PDP P-X MIAN UBFFER S50FH-YB01,PL50FB003F,50 UF1 1
M0156 BN96-08754A ASSY PDP P-Y SCAN BUFFER BORAD S50FH-YB01,PL50FB003F,50 UF1 1
T0037 BN96-08755A ASSY PDP P-LOGIC MAIN S50FH-YB01,PL50FB003F,50 UF1 1
T0937 BN96-08756A ASSY PDP P-ADDRESS E BUFFER S50FH-YB01,PL50FB003F,50 UF1 1
T0938 BN96-08757A ASSY PDP P-ADDRESS F BUFFER S50FH-YB01,PL50FB003F,50 UF1 1
M2893 BN39-01070C LEAD CONNECTOR-LVDS PN58A760T1FXZA,UL20276#30,41P,400mm, 1
T0764 BN44-00237A SMPS-PDP TV PDP 50WF3.5, AC/DC, 593.8W, AC100~240V 1
5-5 Samsung Electronics
Exploded View & Part List
5-4 PN58A550S1FXZAServiceItem
This is the list which is available to repair the real material at the time of service.
Loc. No. Code No. Description Specification Q'ty Remark
M0013 BN96-06699D ASSY COVER P-REAR Spinel 58,PCM T0.5,BKM 1
M0027 BN96-06806A ASSY STAND P-BASE P550 58Inch,ABS,HB,BK2 1
M0145 BN96-07248D ASSY BOARD P-FUNCTION & IR PN58A550S1FXZ 1
M0156 BN96-06497A ASSY PDP P-Y SCAN BUFFER PAIR S58FH-XB01 1
M2893 BN39-00802P LEAD CONNECTOR FPT5884X/XAA,UL1007#26,24 1
M2893 BN39-01070A LEAD CONNECTOR-LVDS PN50A550S1FXZA,UL202 1
T0003 BN96-06688A ASSY COVER P-FRONT Spinel 58",,ABS+PMMA, 1
T0037 BN96-07703A ASSY PDP P-LOGIC MAIN PL58FB003A,58FHD 0 1
T0039 BN96-05647A ASSY PDP P-ADDRESS F-BUFFER BO PL58FH001 1
T0040 BN96-05648A ASSY PDP P-ADDRESS G-BUFFER BO PL58FH001 1
T0044 BN96-05638C ASSY PDP MODULE P-PDP MODULE PL58FB003A, 1
T0045 BN96-05640B ASSY PDP P-X-MAIN BOARD PL58FH001A,S58FH 1
T0045 BN96-05641A ASSY PDP P-X-MAIN BUFFER BOARD PL58FH001 1
T0074 BN59-00673A REMOCON PEARL,TM96A,49,USA,SAMSUNG,TOOLS 1
T0079 BN94-01660A ASSY PCB MISC-MAIN PN58A550S1FXZA,F43A,S 1
T0086 BN96-05643B ASSY PDP P-Y-MAIN UPPER BOARD PL58FH001A 1
T0175 BN96-07355A ASSY SPEAKER P 8ohm,P550 58" LEFT,Down F 1
T0175 BN96-07356A ASSY SPEAKER P 8ohm,P550 58" Right,Down 1
T0262 BN96-05642B ASSY PDP P-Y-MAIN BOARD PL58FH001A,S58FH 1
T0560 BN96-05644B ASSY PDP P-Y-MAIN LOWWER BOARD PL58FH001 1
T0764 BN44-00183A SMPS-PDP TV Saffran 58,SEM,AC/DC,679.9W, 1
T0937 BN96-05646A ASSY PDP P-ADDRESS E-BUFFER BO PL58FH001 1
Samsung Electronics 5-6
Exploded View & Part List
5-5UF1ModuleItem
MODEL ALTERNATE CODE ASSY PDP MODULE P SMPS-PDP TV ASSY COVER P-REAR
KTY-PN50A550S1F[1] BN96-07128A BN44-00222A BN96-06772S
KWY-PN50A550S1F[2] BN96-07128B BN44-00222A BN96-06772S
PN50A550S1F KXY-PN50A550S1F[3] BN96-07128C BN44-00222A BN96-06772S
SYY-PN50A550S1F[4] BN96-08659A BN44-00222A BN96-06772Y
KYY-PN50A550S1F[5] BN96-08659A BN44-00237A BN96-06772Y
KTZ-PN50A550S1FXZA[1] BN96-07128A BN44-00222A BN96-06772R
KWZ-PN50A550S1FXZA[2] BN96-07128B BN44-00222A BN96-06772R
PN50A550S1FXZA KXZ-PN50A550S1FXZA[3] BN96-07128C BN44-00222A BN96-06772R
SYZ-PN50A550S1FXZA[4] BN96-08659A BN44-00222A BN96-06772X
KYZ-PN50A550S1FXZA[5] BN96-08659A BN44-00237A BN96-06772X
KTZ-PN50A510P3FXZA[1] BN96-07128A BN44-00222A BN96-06772T
KWZ-PN50A510P3FXZA[2] BN96-07128B BN44-00222A BN96-06772T
PN50A510P3FXZA KXZ-PN50A510P3FXZA[3] BN96-07128C BN44-00222A BN96-06772T
SYZ-PN50A510P3FXZA[4] BN96-08659A BN44-00222A BN96-06772W
KYZ-PN50A510P3FXZA[5] BN96-08659A BN44-00237A BN96-06772W
KTZ-PN50A530S2FXZA[1] BN96-07128A BN44-00222A BN96-06754G
KWZ-PN50A530S2FXZA[2] BN96-07128B BN44-00222A BN96-06754G
PN50A530S2FXZA KXZ-PN50A530S2FXZA[3] BN96-07128C BN44-00222A BN96-06754G
SYZ-PN50A530S2FXZA[4] BN96-08659A BN44-00222A BN96-06754K
KYZ-PN50A530S2FXZA[5] BN96-08659A BN44-00237A BN96-06754K
KTY-PN50A650T1F[1] BN96-07128A
KWY-PN50A650T1F[2] BN96-07128B
PN50A650T1F
KXY-PN50A650T1F[3] BN96-07128C
KYY-PN50A650T1F[4] BN96-08659A Module code spec.
KTY-PN50A650T1FXZA[1] BN96-07128A BN96-07128A WF3.5 P1 line
KWY-PN50A650T1FXZA[2] BN96-07128B BN96-07128B WF3.5 P2 line
PN50A650T1FXZA
KXY-PN50A650T1FXZA[3] BN96-07128C BN96-07128C WF3.5 P4 line
KYY-PN50A650T1FXZA[4] BN96-08659A BN96-08659A UF1
SXN-PN50A750T1F[1] BN96-07128C
PN50A750T1F
SYN-PN50A750T1F[2] BN96-08659A SMPS code Maker
SXN-PN50A760T1FXZA[1] BN96-07128C BN44-00222A DANAM
PN50A760T1FXZA
SYN-PN50A760T1FXZA[2] BN96-08659A BN44-00237A SEMCO
5-7 Samsung Electronics
