Image preview - the first page of the document



>> Download Samsung_PN50B450_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document

  PN50B450B1DXZA                              Fast Track Troubleshooting Manual
                                                                                 No Service Bulletins




Hot Item:                               Firmware version : ver.1021.1
 Distorted Video: Use the internal       - If customer turns unit off and back
test patterns in both the main board    on,
(FE2) and the Logic board located          . Loss of channels
within the service menu test patterns      . the TV displays "Weak or no
to determine location of distorted      signal"
video prior to removing the rear           . the cable system's setting always
cover. Refer to GSPN                    changes from "HRC" to "STD" though
                                        he set it to "HRC" before
                                         - The problem happens at the region
                                        where the cable system is "HRC" or
                                        "IRC"
PN50B450B1DXZA   Fast Track Troubleshooting Manual
  PN50B450B1DXZA                                   Fast Track Troubleshooting Manual
Support Sheet

  To do list:
    Option bytes should always be verified before and after the repair.
    Quick links listed below for training, triage and Help.


  Option Byte setting




 Training
   Plus One
     http://my.plus1solutions.net/clientPortals/samsung/

 Help
  GSPN
    http://service.samsungportal.com/EP/web/portal/jsp/EP_Default1.jsp
