Image preview - the first page of the document
![Samsung_PN50C490B3DXZA_fast_track_guide_[SM]](/pics/5c26da25adc1c.gif)
>> Download Samsung_PN50C490B3DXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
PN50C490B3DXZA Fast Track Troubleshooting Manual - Rev 1/10/12
SERVICE BULLETINS
Buffer Y
Vs Va Vsc Ve
Voltages
X Main
SMPS
Please check GSPN for parts update!
Y Main Logic PCB
Buffer X
Main PCB
Buffer E Buffer F
FIRMWARE
Please check Samsung.com for
HELP : 1-888-751-4086 (Tech Support) latest update!
1-866-894-0637 (FE)
GSPN
http://gspn3.samsungcsportal.com
10/17/2010, Ver. 1002.0
PLUS ONE
http://my.plus1solutions.net/clientPortals/samsung No sound from SPDIF on PC-DTV PIP.
9/2/2010, Ver. 1001.0.2
HOT TIPS Volume going up and down
-Power On Problems: (pg. 3) intermittently.
-Video Problems: (pg. 4) 1
PN50C490B3DXZA Fast Track Troubleshooting Manual
Power On Sequence
-STBY 5V (Pin 2 CN801)
