Image preview - the first page of the document
![Samsung_PN50C590G4FXZA_fast_track_guide_[SM]](/pics/5c26da3a80974.gif)
>> Download Samsung_PN50C590G4FXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
PN50C590G4FXZA Fast Track Troubleshooting Manual - Rev 1/10/12
SERVICE BULLETINS
Please check GSPN for parts update!
Buffer Y
Vs Va Vsc Ve
Voltages
X Main
SMPS
Y Main Logic PCB
Buffer X
Main PCB
Buffer E Buffer F
FIRMWARE
HELP : 1-888-751-4086 (Tech Support) Please check Samsung.com for
1-866-894-0637 (FE) latest update!
GSPN Firmware for SX1 Model
http://gspn3.samsungcsportal.com -. Version : 1016.3
PLUS ONE -. Folder Name: T-TDT5AUSC
http://my.plus1solutions.net/clientPortals/samsung -. Related Models
. PDP: C500, C530, C540, C550, C590
HOT TIPS -. Description
-Power On Problems: (pg. 3) This firmware will prevent below
problems
-Video Problems: (pg. 4) . Picture Noise on specific channels
. Distorted picture on 70Hz, 75 Hz 1
Version 1014.1-To improve HDMI 24P
PN50C590G4FXZA Fast Track Troubleshooting Manual
Power On Sequence
-STBY 5V (Pin 2 CN801)
