Image preview - the first page of the document
Samsung_PN50C680G5FXZA_fast_track_guide_[SM]


>> Download Samsung_PN50C680G5FXZA_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document
        PN50C680G5FXZA                    Fast Track Troubleshooting Manual - Rev 1/10/12
                                                                                                   SERVICE BULLETINS

     Buffer Y                                          Vs Va Vsc Ve
                                                       Voltages

                                                                                X Main    Please check GSPN for parts update!
                             SMPS
         Y Main                                      Logic PCB


                                                                         Main PCB

                         Buffer E                           Buffer F


                                                                 FIRMWARE
HELP : 1-888-751-4086 (Tech Support)                 Please check Samsung.com for
          1-866-894-0637 (FE)                        latest update!
GSPN
http://gspn3.samsungcsportal.com                     10/17/2010, Ver.1002.0
PLUS ONE                                             No sound from SPDIF on PC-DTV PIP.
http://my.plus1solutions.net/clientPortals/samsung
                                                     9/2/2010, Ver. 1001.0
HOT TIPS                                             Volume going up and down
                                                     intermittently.
-Power On Problems: (pg. 3)
-Video Problems: (pg. 4)
                                                                                                                         1
PN50C680G5FXZA          Fast Track Troubleshooting Manual




                 Power On Sequence
                 -STBY 5V (Pin 2 CN801)
                 -PS_ON (approx 3.3V
