Image preview - the first page of the document
Samsung_PN58C540G3FXZA_fast_track_guide_[SM]


>> Download Samsung_PN58C540G3FXZA_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document
     PN58C540G3FXZA                      Fast Track Troubleshooting Manual - Rev 1/10/12
                      Vs Va Vsc Ve                                                                        SERVICE BULLETINS
    Buffer Y          Voltages



                                                                            X Main
                                SMPS
                                                                                                 Please check GSPN for parts update!

                                                                                     Buffer X
                                                     Logic PCB
               Y Main

                                                                      Main PCB



                         Buffer E         Buffer F               Buffer G



                                                                FIRMWARE
HELP : 1-888-751-4086 (Tech Support)                  Please check Samsung.com for
          1-866-894-0637 (FE)                                 latest update!
GSPN                                                 Firmware for SX1 Model
http://gspn3.samsungcsportal.com                      -. Version : 1016.3
PLUS ONE                                              -. Folder Name: T-TDT5AUSC
http://my.plus1solutions.net/clientPortals/samsung   -. Related Models
                                                          . PDP: C500, C530, C540, C550, C590
HOT TIPS                                             -. Description
-Power On Problems: (pg. 3)                            This firmware will prevent below
                                                     problems
-Video Problems: (pg. 4)                                  . Picture Noise on specific channels
                                                          . Distorted picture on 70Hz, 75 Hz                                   1
PN58C540G3FXZA          Fast Track Troubleshooting Manual




                 Power On Sequence
                 -STBY 5V (Pin 2 CN801)
                 -PS_ON (approx 3.3V
