>> Download Samsung_PN58C550G1FXZA_fast_track_guide_[SM] documenatation <<Text preview - extract from the document PN58C550G1FXZA Fast Track Troubleshooting Manual - Rev 1/10/12
Vs Va Vsc Ve SERVICE BULLETINS
Buffer Y Voltages
X Main
SMPS
Please check GSPN for parts update!
Buffer X
Logic PCB
Y Main
Main PCB
Buffer E Buffer F Buffer G
FIRMWARE
HELP : 1-888-751-4086 (Tech Support) Please check Samsung.com for latest
1-866-894-0637 (FE) update!
Firmware for SX1 Model
GSPN
-. Version : 1016.3
http://gspn3.samsungcsportal.com -. Folder Name: T-TDT5AUSC
PLUS ONE -. Description
http://my.plus1solutions.net/clientPortals/samsung This firmware will prevent below
problems
HOT TIPS . Picture Noise on specific channels
-Power On Problems: (pg. 3) . Distorted picture on 70Hz, 75 Hz
Version 1014.1 2
-Video Problems: (pg. 4) To improve HDMI 24P Connection
1
PN58C550G1FXZA Fast Track Troubleshooting Manual
Power On Sequence
-STBY 5V (Pin 2 CN801)
-PS_ON (approx 3.3V
