Image preview - the first page of the document
![Samsung_PN59D7000FFXZA_fast_track_guide_[SM]](/pics/5c34675b61574.gif)
>> Download Samsung_PN59D7000FFXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
PN59D7000FFXZA Fast Track Troubleshooting Manual, Rev. 1/11/12
Y Buffer X Buffer No Service Bulletins
X Main Please check GSPN for parts update!
SMPS Quick Parts List:
Y Main Version Parts No Short Description
ALL BN44-00447A Power PCB
ALL BN94-04689B Main PCB
I201 BN96-16531A Logic Main PCB
ALL BN96-16532A Buffer E
ALL BN96-16533A Buffer F
Main ALL BN96-16534A Buffer G
ALL BN96-16535A X Main
Logic ALL BN96-16536A Y Main
ALL BN96-16537A Buffer X
ALL BN96-16538A Buffer Y Up
ALL BN96-16539A Buffer Y Down
ALL BN96-17107A RF module PCB
Spkr ALL BN96-18260E Function & IR PCB
Spkr Wi-Fi
Blue Tooth Y504 BN96-20516A Logic Main PCB
Buffer E Buffer F Y503 BN96-20516A Logic Main PCB
I201 BN96-18201A Panel
HELP: 1-888-751-4086 (Tech Support) Latest Firmware: Y503 BN96-20269A Panel
Y504 BN96-20270A Panel
1-866-894-0637 (FE)
Please check Samsung.com for latest ALL BN63-07791A Bottom Cover
GSPN
update! ALL BN96-16810A Front Cover
http://gspn3.samsungcsportal.com ALL BN96-16826A Rear Cover
ALL BN96-16886A Stand Guide
PLUS ONE 2011 PDP Firmware for D6000, D7000 I201 BN96-18641A Stand Guide Neck
http://my.plus1solutions.net/clientPortals/samsung Series (T-MST5AUSC, 1009.2 Y503 BN96-18641A Stand Guide Neck
Y503 BN96-18955B Stand Base
HOT TIPS Firmware for D6000, D7000 Series I201 BN96-18955B Stand Base
-Power On Problems: (pg. 3) - Version : 1009.2 ALL BN40-00208A Tuner
- Folder Name: T-MST5AUSC ALL BN96-18070B Speaker
-Video Problems: (pg. 4)
- Related Models: LED: D6000, D7000 Series ALL BN96-18130H LVDS Cable
- Description:
ALL AA59-00442A Remote
Support 3D Explore and Compassion Apps
ALL BN63-02368B Cleaning Cloth
ALL BN96-09872R Power Cord
PN59D7000FFXZA Fast Track Troubleshooting Manual
Power On Sequence:
1. STBY 5V (CN801, #2, 5v)
2. PS_ON (CN801, #1, 3.3v-0v)
3. VS_ ON (CN802, #6, 0-3.3v)
4. Panel should illuminate briefly
PN59D7000FFXZA Fast Track Troubleshooting Manual
Sample
"VITAL SIGNS"
When troubleshooting, It's very important to first check Vs, Va, Vsc & Ve
If Vs is missing (0V), disconnect power and check for short. Use ohm
Power Supply Trouble Shooting Notes: meter to measure resistance while disconnecting Y-Board & X-Board
supply feeds one at a time.
2010/2011 models
Turn Power On and Test SMPS with shorted connector removed for
Will not be run with the "X" or "Y" main disconnected. The SMPS will correct Vs voltage verification. (It may only come up briefly but to full
shut down immediately. However if a meter is first connected to the level). Be careful not to reconnect power connectors until Vs falls below
test point when power is applied it will read the correct voltage briefly 10V.
before shut- ting down.(You have enough time to check key
If Va is low or missing, disconnect power connectors to Address Boards
voltages)
and Check to see if SMPS Supply is restored. (Note Va feed normally
CAUTION: Do not reconnect any connectors to SMPS or Y/X Boards passes through the Y-Drive to the Address Boards (Logic Buffer Boards).
until power has been turned off long enough for Vs to drop below 10V If Vsc is low or missing and Vs is OK, the failure is with the Y-Board
or damage will occur to X or Y Boards. .
since the Y-Board generates the Vsc voltage from the supplied Vs.
SMPS Over Current Protection If Ve is low or missing and Vs is OK, the failure is with the X-Board since the
Ve is generated by the X-Board from the supplied Vs. (Please note: In some
If a short circuit occurs on either the VS or VA voltage lines, the SMPS rare cases the Ve is generated by the Y-Board fed to the X-Board.)
stops operating, but should not fail. When the short circuit is removed
from the source line, the Power Supply will operate normally again. Other SMPS Voltages:
Many SMPS Supplies are replaced needlessly! Check Low Voltage feeds to the Main Board and other supplied Assemblies.
3
PN59D7000FFXZA Fast Track Troubleshooting Manual
TROUBLESHOOTING VIDEO PROBLEMS
1. Verify Video Operation 2. Using Test Patterns in Service Mode
