Image preview - the first page of the document
![Samsung_PN63C7000YFXZA_fast_track_guide_[SM]](/pics/5c26d8cf371ab.gif)
>> Download Samsung_PN63C7000YFXZA_fast_track_guide_[SM] documenatation <<
Text preview - extract from the document
PN63C7000YFXZA Fast Track Troubleshooting Manual, Rev. 1/11/12
Y Buffer No Service Bulletins
X Buffer
SMPS
X Main
Please check GSPN for parts update!
Y Main
Quick Parts List:
Version Parts No Short Description
I001 BN44-00334A SMPS
Logic I001 BN94-03313T Main PCB
Main I001 BN96-12689A X Main
I001 BN96-12690A Buffer X Up
I001 BN96-12691A Buffer X Down
Woofer I001 BN96-12692A Y Main
I001 BN96-12693A Buffer Y Up
I001 BN96-12694A Buffer Y Down
Buffer E Buffer F Buffer G
I001 BN96-12696A Buffer E
I001 BN96-12697A Buffer F
Latest Firmware: Please check I001 BN96-12698A Buffer G
HELP : 1-888-751-4086 (Tech Support) Samsung.com for latest update! I001 BN96-14112A Logic Main PCB
1-866-894-0637 (FE) 2010 PDP Firmware for Valencia 1G (T- I001 BN96-14504B Function & IR PCB
GSPN VALAUSC, 1035.0) I001 BN96-13446A Panel
http://gspn3.samsungcsportal.com Firmware for Valencia 1G Model I001 BN96-12997B Front Cover
-. Version : 1035.0. Name: T-VALAUSC I001 BN96-13010B Rear Cover
-. Related Models: PDP: C6400, C6500,
PLUS ONE I001 BN96-13026A Stand Base
C7000, C8000
http://my.plus1solutions.net/clientPortals/samsung -. Desc: Support Netflix 2.1 and MLB.tv apps. I001 BN96-14267A Stand Guide
and this firmware prevents below issues: I001 BN40-00162A Tuner
HOT TIPS - 3D picture judders when 'Motion Judder I001 BN96-12723T LVDS Cable
-Power On Problems: (pg. 3) Canceller' is set to 'Smooth' or 'Standard'. I001 BN96-12942C Speaker
-'USB Power Overload' message pops up I001 BN96-13273C Speaker
-Video Problems: (pg. 4) even USB port is not connected I001 BN59-01043A Remote
- HDMI ports recognition error and signal
loose
I001 BN96-09872R Power Cord
- Plug & Play is displayed whenever turning I001 BN96-10788A Accessory Pack
PN63C7000YFXZA Fast Track Troubleshooting Manual
CN4001
Power On Sequence:
CN5003
1. STBY 5V (CN801, #2, 5v)
2. PS_ON (CN801, #1, 3.3v-0v)
3. VS_ ON (CN802, #6, 0-3.3v)
4. Panel should illuminate briefly
PN63C7000YFXZA Fast Track Troubleshooting Manual
Sample
"VITAL SIGNS"
When troubleshooting, It's very important to first check Vs, Va, Vsc & Ve
If Vs is missing (0V), disconnect power and check for short. Use ohm
Power Supply Trouble Shooting Notes: meter to measure resistance while disconnecting Y-Board & X-Board
supply feeds one at a time.
2010/2011 models
Turn Power On and Test SMPS with shorted connector removed for
Will not be run with the "X" or "Y" main disconnected. The SMPS will correct Vs voltage verification. (It may only come up briefly but to full
shut down immediately. However if a meter is first connected to the level). Be careful not to reconnect power connectors until Vs falls below
test point when power is applied it will read the correct voltage briefly 10V.
before shut- ting down.(You have enough time to check key
If Va is low or missing, disconnect power connectors to Address Boards
voltages)
and Check to see if SMPS Supply is restored. (Note Va feed normally
CAUTION: Do not reconnect any connectors to SMPS or Y/X Boards passes through the Y-Drive to the Address Boards (Logic Buffer Boards).
until power has been turned off long enough for Vs to drop below 10V If Vsc is low or missing and Vs is OK, the failure is with the Y-Board
or damage will occur to X or Y Boards. .
since the Y-Board generates the Vsc voltage from the supplied Vs.
SMPS Over Current Protection If Ve is low or missing and Vs is OK, the failure is with the X-Board since the
Ve is generated by the X-Board from the supplied Vs. (Please note: In some
If a short circuit occurs on either the VS or VA voltage lines, the SMPS rare cases the Ve is generated by the Y-Board fed to the X-Board.)
stops operating, but should not fail. When the short circuit is removed
from the source line, the Power Supply will operate normally again. Other SMPS Voltages:
Many SMPS Supplies are replaced needlessly! Check Low Voltage feeds to the Main Board and other supplied Assemblies.
3
PN63C7000YFXZA Fast Track Troubleshooting Manual
TROUBLESHOOTING VIDEO PROBLEMS
1. Verify Video Operation 2. Using Test Patterns in Service Mode
