Image preview - the first page of the document
![Samsung_PS42C430_Precaution_[SM]](/pics/5c26d92491ae8.gif)
>> Download Samsung_PS42C430_Precaution_[SM] documenatation <<
Text preview - extract from the document
Precaution
1.Precaution
To avoid possible damage, electric shocks or exposure to radiation, follow the instructions below with regard to
safety, installation, service and ESD.
1-1 SafetyPrecautions
1. Make sure all protective devices are properly installed including non-metallic handles and compartment covers
when installing or re-installing the chassis or chassis assemblies.
2. Make sure that no gaps exist between the cabinets for children to insert their fingers in to prevent children from
receiving electric shocks. Gaps mentioned above include ventilation holes of a too great magnitude between
the PDP module and the cabinet mask, and the improper installation of the rear cabinet.
Errors may occur when the resistance is below 1.0M or over 5.2M. In these cases, make sure that the
device is repaired before sending it back to the customer.
4. Check for Electricity Leakage (AC Leakage Test)
Warning: Do not use an insulated transformer for
LEAKAGE (READING
checking the leakage. Use only those DEVICE CURRENT SHOULD NOT BE
UNDER TESTER ABOVE 0.5mA)
current leakage testers or mirroring systems TEST
that comply with ANSIC 101.1 and the TEST ALL
EXPOSED METAL
Underwriter Laboratory's specifications SURFACES
(UL1410, 59.7). 2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC EARTH
ADAPTER PLUG GROUND
AS REQUIRED)
4. A high voltage is maintained within the specified limits using safety parts, calibration and tolerances. When
voltage exceeds the specified limits, check each special part.
5. Warning for Engineering Changes:
Never make any changes or additions to the circuit design or the internal part for this product.
Ex: Do not add any audio or video accessory connectors. This might cause physical damage.
Furthermore, any changes or additions to the original design/engineering will invalidate the warranty.
6. Warning - Hot Chassis:
Some TV chassis are directly connected to one end of the AC power cord for electrical reasons.
Without insulated transformers, the product can only be repaired safely when the chassis is connected to the
earthed end of the AC power source.
To make sure the AC power cord is properly connected, follow the instructions below. Use the voltmeter to
measure the voltage between the chassis and the earthed ground. If the measurement is over 1.0V, unplug the
AC power cord and change the polarity before reinserting it. Measure the voltage between the chassis and the
ground again.
Samsung Electronics 1-1
Precaution
7. Some TV chassis are shipped with an additional secondary grounding system. The secondary system
is adjacent to the AC power line. These two grounding systems are separated in the circuit using an
unbreakable/unchangeable insulation material.
8. When any parts, material or wiring appear overheated or damaged, replace them with new regular ones
immediately. When any damage or overheating is detected, correct this immediately and make a regular check
of possible errors.
9. Check for the original shape of the lead, especially that of the antenna wiring, any sharp edges, the AC power
and the high voltage power. Carefully check if the wiring is too tight, incorrectly placed or loose. Never change
the space between the part and the printed circuit board. Check the AC power cord for possible damages.
Keep the part or the lead away from any heat-emitting materials.
10. Safety Indication:
Some electrical circuits or device related materials require special attention to their safety features, which
cannot be viewed by the naked eye. If an original part is replaced with another irregular one, the safety or
protective features will be lost even if the new one has a higher voltage or more watts.
Critical safety parts should be bracketed with ( , ). Use only regular parts for replacements (in particular,
flame resistance and dielectric strength specifications). Irregular parts or materials may cause electric shock or
fire.
1-2 Samsung Electronics
Precaution
1-2 ServicingPrecautions
Warning 1: First carefully read the "Safety Instruction" in this service manual.
When there is a conflict between the service and the safety instructions, follow the safety instruction
at all times.
Warning 2: Any electrolytic capacitor with the wrong polarity will explode.
1. The service instructions are printed on the cabinet, and should be followed by any service personnel.
2. Make sure to unplug the AC power cord from the power source before starting any repairs.
(a) Remove or re-install parts or assemblies.
(b) Disconnect the electric plug or connector, if any.
(c) Connect the test part in parallel with the electrolytic capacitor.
3. Some parts are placed at a higher position than the printed board. Insulated tubes or tapes are used for this
purpose. The internal wiring is clamped using buckles to avoid contact with heat emitting parts. These parts
are installed back to their original position.
4. After the repair, make sure to check if the screws, parts or cables are properly installed. Make sure no damage
is caused to the repaired part and its surroundings.
5. Check for insulation between the blade of the AC plug and that of any conductive materials (i.e. the metal
panel, input terminal, earphone jack, etc).
6. Insulation Check Process:
Unplug the power cord from the AC source and turn the switch on. Connect the insulating resistance meter
(500V) to the AC plug blade. The insulating resistance between the blade of the AC plug and that of the
conductive material should be more than 1M.
7. Any B+ interlock should not be damaged.
If the metal heat sink is not properly installed, no connection to the AC power should be made.
8. Make sure the grounding lead of the tester is connected to the chassis ground before connecting to the
positive lead. The ground lead of the tester should be removed last.
9. Beware of risks of any current leakage coming into contact with the high-capacity capacitor.
10. The sharp edges of the metal material may cause physical damage, so protect yourself by wearing gloves
during the repair.
11. Due to the nature of plasma display panels, partial after-images may appear if a still picture is displayed on the
screen for a long period of time.
This is caused by brightness deterioration due to the storage effect of the panel, and to prevent this from
happening, we recommend that the brightness and contrast are reduced.
(e.g.) Contrast: 25, Brightness: 50
Samsung Electronics 1-3
Precaution
1-3 StaticElectricityPrecautions
1. Some semi-conductive ("solid state") devices are vulnerable to static electricity. These devices are known as
ESD. ESD includes the integrated circuit and the field effect transistor. To avoid any materials damage from
electrostatic shock, follow the instructions described below.
2. Remove any static electricity from your body by connecting the earth ground before handling any semi-
conductive parts or assemblies. Alternatively, wear a dischargeable wrist-belt.
(Make sure to remove any static electricity before connecting the power source - this is a safety instruction for
avoiding electric shock)
3. Remove the ESD assembly and place it on a conductive surface such as aluminum foil to prevent
accumulating static electricity.
4. Do not use any Freon-based chemicals. Such chemicals will generate static electricity that causes damage to
the ESD.
5. Use only grounded-tip irons for soldering purposes.
6. Use only anti-static solder removal devices.
Most solder removal devices do not support an anti-static feature. A solder removal device without an anti-
static feature can store enough static electricity to cause damage to the ESD.
7. Do not remove the ESD from the protective box until the replacement is ready. Most ESD replacements are
covered with lead, which will cause a short to the entire unit due to the conductive foam, aluminum foil or other
conductive materials.
8. Remove the protective material from the ESD replacement lead immediately after connecting it to the chassis
or circuit assembly.
9. Take extreme caution in handling any uncovered ESD replacements. Actions such as brushing clothes or
lifting your leg from the carpet floor can generate enough static electricity to damage the ESD.
CAUTION
These servicing instructions are for use by
qualified service personnel only.
To reduce the risk of electric shock do not perform
any servicing other than that contained in the
operating instructions unless you are qualified to
do so.
1-4 Samsung Electronics
Precaution
1-4 InstallationPrecautions
1. For safety reasons a minimum of two people are required to
carry this product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric
shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal
temperature may cause fire.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being
exposed to moisture. Otherwise, it may cause a fire or electric shock.
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product.
Also check the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may
cause fire or electric shock.
6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the high-voltage
cable or the antenna falling over may cause fire or electric shock.
7. When connecting the RF antenna, check for a DTV receiving system and install a separate DTV reception
antenna for areas with no DTV signal.
8. When installing the product, leave enough space (4") between the product and the wall for ventilation
purposes. A rise in temperature within the product may cause fire.
9. When moving a PDP with removable speakers, detach the speakers first before moving the main body.
Moving the PDP main body without separating the speakers may cause the speakers to detach, possibly
causing damage or injury.
Samsung Electronics 1-5
MEMO
1-6 Samsung Electronics
