Image preview - the first page of the document
5.Alignment_and_Adjustments


>> Download 5.Alignment_and_Adjustments documenatation <<

Text preview - extract from the document
4. Alignment and Adjustments


            PRECAUTION
     1.   High voltage is present at the high voltage terminals during any cook cycle.
     2.   It is neither necessary nor advisable to attempt measurement of the high voltage.
     3.   Before touching any oven components or wiring, always unplug the oven from its power source and
          discharge the high voltage capacitor.



4-1 High Voltage Transformer
1.   Remove connectors from the transformer terminals and
     check continuity.
2.   Normal resistance readings are as follows:


                        SHV-U1870D
      Secondary
      Filament          Shows Continuity
      Primary



                        SHV-U1850A
      Secondary
      Filament          Shows Continuity
      Primary
