SERVICE BULLETIN
PRODUCT: Microwave Oven
BULLETIN ASC20120216001
NUMBER:
ELECTRONICS BULLETIN DATE: 2/16/2012
MODELS: SMH1816B/XAA
SMH1816S/XAA
SMH1816W/XAA
SUBJECT: Parts Change.
Explanation:
The ventilation motor in the models listed above has been changed to a standardized
design to improve parts interchangeability.
Date of Implementation: Beginning with February 6, 2012 production.
Part Name Old Design Part New Design Part Comments
Number Number
MOTOR Old parts are
VENTILATION;SMV- DE31-00029F DE31-00029H compatible with
460UAL,2800/1950/1 new parts.
You can determine the month and year the microwave oven was manufactured from the
serial number. The production year is coded in the eighth digit of the serial number and the
production month in the ninth digit. See the table below.
Serial Number Lookup table
Digit 8 ( production year) S = 2009
Z= 2010
B= 2011
C= 2012
D = 2013
