Image preview - the first page of the document



>> Download Disassembly_n_Reassembly documenatation <<

Text preview - extract from the document

3. Disassembly and Reassembly

MAGNETRON, MOTOR ASSEMBLY, VENT BLOWER AND HIGH VOLTAGE TRANSFORMER
Oven must be removed from wall.
REMOVING OVEN FROM WALL (2 PEOPLE REQUIRED)
Oven is hooked on metal tabs at bottom of wall mounting plate and to cabinet by (3) top cabinet bolts.

3-1 Disassembly of Assembly Grille and Panel Outer

          Parts                   Explaination Photo                                 Explaination




                                                                 1.   Disconnect oven power.

                                                                 2.   Remove Grille.
 Grille
                                                                      1) Remove 2 screws
                                                                      2) Slide the Grille to the left, then pull it
                                                                         straght out.




                                                                 1.   Disconnect oven power.
                                                                 2.   Remove Grille.
                                                                 3.   Remove Screw.(7)




 Panel Outer




                                                                 4.   Remove Screw.(4)




                                                       9
3. Disassembly and Reassembly

3-1 Disassembly of Assembly Grille and Panel Outer

     Parts               Explaination Photo                               Explaination




                                                          5.   Remove Screw.(4)




                                                          6.   Remove Screw.(2)




Panel Outer


                                                          7.   Remove Screw.(2)




                                                   Explaination Photo




                                                      Explaination
               8.   Remove Panel Outer.




                                              10
3. Disassembly and Reassembly

3-2 Replacement of High Voltage Transformer and HVC and Base bottom

  Parts        Explaination Photo                          Explaination



                                    1.    Disconnect Oven Power.
                                    2.    Remove Panel Outer.
                                    3.    Discharge The High Voltage Capacitor.

                                         ATTENTION : When discharge must become ground
                                                     terminal of HVC and metal of around.
High
voltage
capacitor


                                    4.    Remove screw.(1)
                                    5.    Disconnect the Lead Wire.




                                                                           1.     Remove
                                                                                  Screw.(5)
                                                                           2.     Disconnect
Base
                                                                                  Lamp
Bottom                                                                            Housing.
                                                                           3.     Remove Base
                                                                                  bottom.




                                                                           1.     Disconnect
                                                                                  Oven Power.
                                                                           2.     Remove the
                                                                                  Base bottom
                                                                                  and Panel
HV Trans                                                                          Outer.
                                                                           3.     Disassembly
                                                                                  the Bracket
                                                                                  Duct upper
                                                                                  after remove
                                                                                  screw.




                                    11
3. Disassembly and Reassembly

3-2 Replacement of High Voltage Transformer and HVC and Base bottom

  Parts        Explaination Photo                         Explaination




                                    4.   Disconnect the Lead Wire.




HV Trans



                                    5.   Remove screw.(3)
                                    6.   Take out the HV Trans.




                                    12
3. Disassembly and Reassembly

3-3 Replacement of Magnetron

       Parts                     Explaination Photo                              Explaination



                                                                Remove the magnetron including the shield
                                                                case, permanent magnet, choke coils and
                                                                capacitors (all of which are contained in one
                                                                assembly).
                                                                1. Disconnect all lead wires from the
                                                                    magnetron.


Magnetron



                                                                2.    Remove nuts (4) securing the magnetron
                                                                      to the wave guide.
                                                                 3.   Take out the magnetron very carefully.




NOTE1: When removing the magnetron, make sure that it antenna does not hit any adjacentparts, or it may be
       damaged.
NOTE2: When replacing the magnetron, be sure to remount the magnetron gasket in the correct position and make
       sure the gasket is in good condition.



        PRECAUTION
  During replacement, be certain R.F. anode gasket is in place around anode stub.
  PERFORM MICROWAVE LEAKAGE TEST




                                                      13
3. Disassembly and Reassembly

3-4 Replacement of Door Assembly
     Parts           Disassembly Photo                                  Explaination




Removal of                                    1.   Open the Assembly Door by degree 90
