Image preview - the first page of the document
>> Download PCB_Diagram documenatation <<
Text preview - extract from the document
33
Parts
No. Part Name Function and Rule
Number
1 CN201 A Terminal for connecting with SMPS Power Supply A Terminal for Connecting with Inrush Relay, Lamp, Louver and SMPS Power Supply
2 CN202 A Terminal for connecting with T/T and Vent A Terminal for Connecting with T/T, Vent and SMPS Power supply
3 CN301 A Terminal for connecting with Gas-Sensor A Terminal for Detecting Gas-Sensor and SMPS Power supply
(This Document can not be used without Samsung's authorization)
4 CN401 A Terminal for connecting with Door A Terminal for Connecting Door and SMPS Power supply
5 CN601 A Terminal for connecting with Connector A Terminal for Connecting with Connector and SMPS Power Supply
6 RY201 Main Relay Power Supply Relay
7 RY202 Inrush Relay Inrush Electric Current Decrease Device
9 RY203 Power-High Relay MWO Control Relay (Power High)
9 RY204 Power-Low Relay MWO Control Relay (Power Low)
10 RY205 Night Relay Lamp Control Relay
11 RY206 Bright Relay Lamp Control Relay
12 RY207 Louver Relay Louver Control Relay
13 RY209 Vent-High Relay Vent Control Relay (Vent high)
6. PCB Diagrams
6-1 PCB Diagrams
6. PCB Diagrams
6-2 PCB Diagrams
(This Document can not be used without Samsung's authorization)
34
