Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Parts List
3. Exploded View & Parts List
3-1 PPM42S3QX/XEU
You can search for the updated part code through ITSELF web site.
URL : http://itself.sec.samsung.co.kr No Code No Description;Specification Q'ty S.N.A
M0003 BN96-00135P ASSY COVER P-FRONT;42P3(VMB),EUP,HIPS HB 1
T0003 BN64-00071H CABINET FRONT;42P3 VMB,HIPS,HB,HF-1690H, 1 S.N.A
T0057 BP64-00177A BADGE-BRAND;ALL,AL,T1.5,70,11.3,BLK,SILI 1 S.N.A
T0022 BP64-00045B KNOB CONTROL;P3,ABS,HB,GRY,SVM3012 1 S.N.A
T0001 T0061 BN64-00074B WINDOW-REMOTE;42P3S,PMMA,,,,,,CLEAR 1
T0916 T0098 BN94-00494L ASSY PCB MISC-CONTROL;SPD-42A4H,D55A,ALE 1
T0074 T0268 T0456 BN67-00128A GLASS-FILTER EMI;42V3,Sputter,44%,984*58 1 S.N.A
T0112
T0911 BN61-00244E BRACKET-FILTER TOP ASSY;42P3H,AL5052,1.2 1 S.N.A
T0073
T0912 BN61-00245H BRACKET-FILTER SIDE L;42P3S,AL5052,1.2 1 S.N.A
T0044 T0764 T0913 BN61-00309E BRACKET-FILTER SIDE R;42P3S,AL5052,1.2 1 S.N.A
T0918 T0914 BN61-00246E BRACKET-FILTER BOTTOM ASSY;42P3S,AL5052, 1 S.N.A
T0915 BN61-00141A HOLDER-MODULE;42P3,AL,DIECASTING 4 S.N.A
T0037
T0915 T0918 AA60-00110H SPACER-FILTER;42P3,P/U FROM,960,5,6 1 S.N.A
T0911 T0096 T0918 AA60-00110J SPACER-FILTER;50P3,P/U Form,20.0,2.0,5.0 2 S.N.A
T0912 T0044 BN96-01209A ASSY PDP P-MODULE;M3,S42SD-YD,V3,42INCH, 1
T0456 T0764 BN96-01217A ASSY MISC P-SMPS;SPP4231,PS42D4S,110~240 1
T0073 BN96-00870A ASSY PDP P-X MAIN BOARD;M3,S42SD-YD,D65A 1
M0003
T0145
T0096 BN96-01211A ASSY PDP P-Y MAIN BOARD;M3,S42SD-YD,V3,4 1
T0132
T0008 T0037 BN96-01212A ASSY PDP P-L MAIN BOARD;M3,S42SD-YD,V3,4 1
T0003 T0913 T0918 T0008 BN96-00313C ASSY COVER P-BACK SUB;42P3,DGM5233 T1.2 1 S.N.A
T0914
T0132 BN94-00536C ASSY PCB MISC-DIGITAL;PPM42S3Q,D61B,42P3 1
T0145 BN94-00536B ASSY PCB MISC-ANALOG;PPM42S3Q,D61B,NEWTO 1
T0001 BN96-00314C ASSY COVER P-BACK;PS42P3S,AL5052 T1.2,DG 1
T0112 BN63-00529B COVER-BACK;42P3,DGM5233,T1.2 1 S.N.A
T0555
T0057 T0098 T0916 BN61-00202B BRACKET-HANDLE;42P3,T1.5,DGM5233 2 S.N.A
T0022
T0555 BN96-00286F ASSY MISC P-BRACKET TERMINAL;P3,VMB 1 S.N.A
T0074 BN59-00366A REMOCON;TM76,D61A,42,G6148,PPM42S3,EX 1
T0268 3903-000067 CBF-POWER CORD;DT,GB,GP3/YES(A),I(IEC C1 1
T0061
Samsung Electronics 3-1
