Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Part List
4. Exploded View & Part List
4-1 PS42D5SX/XEC
Yon can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003B SPRING ETC-CS -,SUS304,-,-,OD11.2,N7,OD1 1 S.N.A
M0006 BN63-01634C COVER-REAR SUB 42S5,SECC,T1.0 1 S.N.A
M0006 BN63-01815A COVER-REAR BOTTOM 42D5,HIPS,T3.0,HB,GR50 1 S.N.A
M0013 BN96-01786C ASSY COVER P-REAR SP-R4232,SECC,BLM 5113 1 S.A
M0013 T0555
M0045 BN96-01912B ASSY STAND P-SET 42D5S,XEC,HIPS HB,SV012 1 S.A
M0112 BN63-01822A COVER-FRONT 42D5,SF0507,T3.5,HB,BK23,STE 1 S.N.A
M0145 BN96-02049A ASSY BOARD P-FUNCTION SCHUBERT,CT5000-32 1 S.A
T0074 T0268 M0146 BN96-02050B ASSY BOARD P-POWER & IR SCHUBERT,CT5000- 1 S.N.A
T0003 BN96-01911B ASSY COVER P-FRONT 42D5,XEC,ABS HB,STEAM 1 S.A
T0079
T0023 BN96-01788A ASSY COVER P-KNOB POWER 1 S.N.A
M0006 T0023 BN64-00336A KNOB POWER 42P5,PC,VIOLET 1 S.N.A
T0044 BN96-01887A ASSY PDP MODULE P M1,PS42S5S,D,V4,1002◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
